- Page 1 A V AIL BALLISTIC DOOR PANELS Level III INSTALLATION GUIDE for front driver and passenger-side doors As shown on Dodge Charger Pursuit ® (2011 & NEWER MODELS) angelarmor.com 970 235 2961 sales@angelarmor.com 10696_C...
-
Page 2: Table Of Contents
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Table of Contents Introduction 3–4 Product Description Installation Overview Warnings & Cautions Legal Statements Parts & Tools List 5–7 Installation Kit Contents Personal Protective Equipment Required Tools... -
Page 3: Introduction
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Introduction coating to help resist environmental wear and corrosion. The alloy steel crash bar brackets Congratulations on your and door mounting bracket secure the armor in place to help prevent rattling and shifting within purchase of the Angel Armor™... -
Page 4: Warnings & Cautions
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Warnings and Cautions Do not drop screws or other assembly components inside the door, as they may be Please adhere to the following difficult to retrieve. If possible, use magnetic tools during installation. -
Page 5: Parts & Tools List
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT parts list One Avail Door Mounting Bracket This section lists the parts included in the installation kit and the tools recommended for installation. Installation kit Figure 4. Door Mounting Bracket contents are for one door panel. - Page 6 Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT 2 Door Mounting Bracket Bolts and 2 OEM Hinge Reinforcement Kit Washers NOTE: Each OEM Hinge Kit comes standard with installation hardware for driver and passenger-side doors. If you are not installing passenger-side armor, the extra parts will not be used.
-
Page 7: Personal Protective Equipment
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Personal Protective Equipment Protective Gloves Protective Eyewear Steel-Toe Boots Required Tools Plastic Door Pry Tools Impact Driver or Drill Phillips Screwdriver and Flat-head Figure 16. Cushioned X-Frame Work Stand... -
Page 8: Installation
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT INSTALLATION Important Notes The directions, photographs and illustrations This section provides instructions in this guide depict an installation performed for installing Angel Armor Avail on the driver’s side. The same installation procedure applies to the passenger door. -
Page 9: Procedure
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT PROCEDURE Complete the following steps to properly install Angel Armor Avail Ballistic Door Panels (Level III) for Dodge Charger Pursuit (2011 & Newer Models). Installing OEM Hinge Reinforcements and Check Strap Figure 18. -
Page 10: Preparing For Ballistic Door Panel Installation
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Installing OEM Hinge Reinforcements and Check Strap CONTINUED Place rivets into bracket/door holes (five on upper bracket, four on lower bracket). Use the riveting tool to squeeze and secure the rivets in place. -
Page 11: Removing The Window Weatherstrip
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Removing the Window Weatherstrip Removing the Vehicle Door Panel and Speaker Using a T20 driver, remove the front and back window weatherstrip screws. Using the door pry tools, remove the trim cover behind the interior door handle. - Page 12 Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Removing the Vehicle Door Panel Use a Phillips head screwdriver to remove and Speaker the screw surrounded by a rubber CONTINUED bumper on the outer bottom edge of the door panel.
- Page 13 Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Removing the Vehicle Door Panel Disconnect all wiring harness clips. There and Speaker are four on the driver side and three on CONTINUED the passenger side.
-
Page 14: Removing The Vehicle Window
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Removing the Vehicle Window Open the window regulator access panel at the top rear portion of the inner door panel. Use a screwdriver or needle nose pliers to release the front window clip located behind the speaker. -
Page 15: Removing Inner Door Panel
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Removing Inner Door Panel Use a T25 driver to rotate and disengage Use a 10mm wrench to loosen and the clips around the perimeter of the remove the door lock post. -
Page 16: Inserting And Securing The Ballistic Door Panel
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Inserting and Securing Hold the ballistic door panel so the the Ballistic Door Panel product label faces the interior of the vehicle. Locate the two nylon installation straps. - Page 17 Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Inserting and Securing With the armor lowered of the way the Ballistic Door Panel into the door, loosely install the first crash CONTINUED bar bracket by inserting one 25mm bolt with a washer through the top slotted hole at the front portion of the armor.
- Page 18 Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Inserting and Securing Manipulate the armor so the round part the Ballistic Door Panel of the top crash bar brackets properly CONTINUED hooks onto the crash bar. Refer again to Figures 42 and 43 for proper positioning.
- Page 19 Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Inserting and Securing At the top of the armor, use a 1/2” socket the Ballistic Door Panel to loosely attach the door mounting CONTINUED bracket to the armor, ensuring the bracket presses up against the top of the door frame.
-
Page 20: Replacing Inner Door Panel
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Replacing the Inner Door Panel Use a T25 driver to replace the four Torx T25 speaker screws. Connect the cable to the external door handle and ensure the yellow grommet... -
Page 21: Replacing The Window Weatherstrip
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT Replacing the Speaker Replacing the Window Weatherstrip and Vehicle Door Panel CONTINUED Press down on the front end of the weatherstrip and move backward, Use a Phillips screwdriver to replace the... -
Page 22: Completing Installation
Installation Guide Angel Armor Avail ballistic door panels (Level III) FOR DODGE CHARGER PURSUIT b Allow the door surface to dry Completing Installation completely. Verify that all trim and window c Remove the backing from the brand components are properly re-installed and label.
