- Page 1 3U CompactPCI 64-bit PMC Carrier Board User’s Manual Manual Rev. 2.00 Revision Date: November 1, 2004 Part No: 50-15024-100 Advance Technologies; Automate the World.
- Page 2 Copyright 2004 ADLINK TECHNOLOGY INC. All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design, and function and does not represent a commitment on the part of the manufacturer.
- Page 3 Getting Service from ADLINK Customer Satisfaction is top priority for ADLINK Technology Inc. Please contact us should you require any service or assistance. ADLINK TECHNOLOGY INC. Web Site: http://www.adlinktech.com Sales & Service: Service@adlinktech.com TEL: +886-2-82265877 FAX: +886-2-82265717 Address: 9F, No. 166, Jian Yi Road, Chungho City,...
-
Page 5: Table Of Contents
List of Figures ................ iii 1 Introduction ................ 1 Product Overview ..............1 Unpacking Checklist ............2 cPCI-8301 Mechanical Drawing .......... 3 cPCI-8301 Functional Diagram..........4 cPCI-8301 Placement............4 Number of Boards Supported per PCI Bus......5 2 Connectors ................. 7 PMC Connectors .............. -
Page 6: List Of Tables
List of Tables Table 2-1: P1 and P2 PMC Connector Pin Definitions ....7 Table 2-2: P3 PMC Connector Pin Definitions ......8 Table 2-3: J1 Connector Pin Definitions ........10 Table 2-4: J2 Connector Pin Definitions (64-bit) ...... 11 List of Tables... - Page 7 List of Figures Figure 1-1: cPCI-8301 Carrier Board Layout ....... 3 Figure 1-2: cPCI-8301 Functional Diagram ......... 4 Figure 1-3: cPCI-8301 Top View..........4 Figure 1-4: cPCI-8301 Bottom View ..........5 List of Figures...
-
Page 9: Introduction
33/66MHz PCI buses. It is PICMG 2.0 CompactPCI Specification R2.1 and IEEE 1386.1 PMC Standard compliant. Note: There is no VIO keying on the cPCI-8301. VIO is directly connected to connector J2 and defined by the backplane. Please check your backplane’s VIO before installing your PMC card onto the cPCI-8301. -
Page 10: Unpacking Checklist
Included Items cPCI-8301 carrier board This manual Note: The packaging of the cPCI-8301 OEM version with non-standard configuration, functionality, or package may vary according to different configuration requests. CAUTION: The carrier board must be protected from cPCI-8301 static discharge and physical shock. -
Page 11: Cpci-8301 Mechanical Drawing
1.3 cPCI-8301 Mechanical Drawing Figure 1-1: cPCI-8301 Carrier Board Layout Introduction... -
Page 12: Cpci-8301 Functional Diagram
1.4 cPCI-8301 Functional Diagram Figure 1-2: cPCI-8301 Functional Diagram 1.5 cPCI-8301 Placement Figure 1-3: cPCI-8301 Top View Introduction... -
Page 13: Number Of Boards Supported Per Pci Bus
Figure 1-4: cPCI-8301 Bottom View 1.6 Number of Boards Supported per PCI Bus The maximum number of cPCI-8301 boards that can be supported on one PCI bus is dependant on the frequency of the PMC cards installed. Please refer to the following table:... - Page 14 Introduction...
-
Page 15: Connectors
This chapter will familiarize the user with the connectors on the cPCI-8301. 2.1 PMC Connectors The cPCI-8301 is a single I/O board for 64-bit PMC to cPCI trans- fer. PMC connectors P1-P3 are implemented. The P4 connector (User IO) is not implemented. -
Page 16: Table 2-2: P3 Pmc Connector Pin Definitions
Jn1 (32 Bit) Jn2 (32Bit) Signal Signal Pin Pin Signal Signal LOCK# PERR# +3.3V SERR# C/BE[1]# V(I/O) AD[15] AD[14] AD[13] AD[12] AD[11] M66EN AD[10] AD[09] AD[08] +3.3V C/BE[0]# AD[07] AD[06] AD[05] +3.3V AD[04] PMC-RSVD1 V(I/O) AD[03] PMC-RSVD2 PMC-RSVD3 AD[02] AD[01] PMC-RSVD4 AD[00] ACK64#... - Page 17 Jn3 (64 Bit) Signal Signal AD[59] AD[58] AD[57] V(I/O) AD[56] AD[55] AD[54] AD[53] AD[52] AD[51] AD[50] AD[49] AD[48] AD[47] AD[46] AD[45] V(I/O) AD[44] AD[43] AD[42] AD[41] AD[40] AD[39] AD[38] AD[37] AD[36] AD[35] AD[34] AD[33] V(I/O) AD[32] Table 2-2: P3 PMC Connector Pin Definitions Connectors...
-
Page 18: Compactpci Connectors
2.2 CompactPCI Connectors The J1 and J2 CompactPCI connector definitions are shown in the tables below: J1-25 REQ64# +3.3V J1-24 AD[1] AD[0] ACK64# J1-23 +3.3V AD[4] AD[3] AD[2] J1-22 AD[7] +3.3V AD[6] AD[5] J1-21 +3.3V AD[9] AD[8] C/BE[0]# J1-20 AD[12] AD[11] AD[10] J1-19... -
Page 19: Table 2-4: J2 Connector Pin Definitions (64-Bit)
J2 (64-bit) J2-22 J2-21 J2-20 J2-19 J2-18 J2-17 J2-16 J2-15 J2-14 AD[35] AD[34] AD[33] AD[32] J2-13 AD[38] AD[37] AD[36] J2-12 AD[42] AD[41] AD[40] AD[39] J2-11 AD[45] AD[44] AD[43] J2-10 AD[49] AD[48] AD[47] AD[46] J2-9 AD[52] AD[51] AD[50] J2-8 AD[56] AD[55] AD[54] AD[53] J2-7... - Page 20 Connectors...
-
Page 21: Warranty Policy
Warranty Policy Thank you for choosing ADLINK. To understand your rights and enjoy all the after-sales services we offer, please read the follow- ing carefully. 1. Before using ADLINK’s products please read the user manual and follow the instructions exactly. When sending in damaged products for repair, please attach an RMA application form... - Page 22 3. Our repair service is not covered by ADLINK's two-year guarantee in the following situations: Damage caused by not following instructions in the user's manual. Damage caused by carelessness on the user's part during product transportation. Damage caused by fire, earthquakes, floods, lightening, pollution, other acts of God, and/or incorrect usage of voltage transformers.
