ASME A112.18.1 / CSA B125.1
ICC/ANSI A117.1
NSF-61
751 Model/Modelo/Modèle
Dryden™ Series/Series/Seria
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
T E FLO N
For easy installation of your Delta
faucet you will need:
• To READ ALL the instructions completely
before beginning.
• To READ ALL warnings, care, and maintenance
information.
• To purchase the correct water supply hook-up.
Para instalación fácil de su llave Delta
usted necesitará:
• LEER TODAS las instrucciones completamente
antes de empezar.
• LEER TODOS los avisos, cuidados, e
información de mantenimiento.
• Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet Delta
facilement, vous devez:
• LIRE TOUTES les instructions avant de
débuter;
• LIRE TOUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
• Acheter le bon nécessaire de raccordement.
U P
C
®
You may need/Usted puede necesitar/
Articles dont vous pouvez avoir besoin:
US. Pat. 4,043,359, 3,786,995, 4,562,960, 4,593,430, 4,089,347, 4,218,785, 4,765,365, 4,696,322
SINGLE HANDLE LAVATORY
VESSEL FAUCET
LLAVE DE AGUA DE RECIPIENTE PARA
LAVAMANOS DE UNA MANIJA
ROBINET À UNE MANETTE POUR
BASSIN DE COMPTOIR
T E FLO N
1
7/10/08 Rev. B
