skewer can be closed tightly (press lever in, not around in a circle). Make sure wheels are very secure.
Wheel Reflectors
Install the wheel reflectors (if not already installed) into the wheels near the valve but with enough space to add air easily to the
tires.
Seat Post Hitch
Attach the hitch to the seat post with the bevel facing upward at a height which
allows the trailer to be as parallel to the ground as possible. Open, then re-tighten
the hitch's collar evenly on both sides of the seat post by screwing each bolt in part
way, and rotating between bolts as you tighten. Tighten the hitch to the seat post
so that it cannot move.
The ball joint is at the tip of the tow bar. Feed the ball joint, top to bottom, through
the hitch. The ball joint should rotate freely in the hitch.
Attaching Trailer to Seat Post Hitch
Spin the hitch nut onto the ball joint's threads, with the teeth pressing against the hitch. Hand tighten firmly.
Rear Reflectors
Install the rear reflector on the mount at the rear center of the trailer. The optional Blinky light can be mounted here instead.
Safety Strap
Wrap the safety strap around the seat post and attach, keeping it loose enough to avoid binding while cornering.
Safety Flag
Join the two pieces of the flagpole to make a 6' long pole. Insert the safety flag into the tube at the left rear of the trailer. The
movement of the flag draws drivers attention and makes the trailer more visible.
Loading Your Trailer
Distribute the load evenly across the struts. We recommend strapping a board or hard plastic sheet to the floor of the trailer, or
using large plastic totes.
Owner's Manual
Please read and understand your Owner's Manual.
Tow bar (tongue)
Seat post hitch –various
sizes
Hitch nut
Rack hitch
Hex key 3/16
Safety flag
Tow Bar
Safety Strap
Red set screws
Ball joint
Safety Strap
Ball Joint
Hitch Nut
Hitch
SMALL
TRAILER
2
