VIDEO INSTALLATION INSTRUCTIONS AVAILABLE AT:
WWW.DIRTYDOG4X4.COM OR WWW.FACEBOOK.COM/DIRTYDOG4X4
Thank you for purchasing a Dirtydog 4x4 netting system.
-
Please read these instructions fully to familiarize yourself with
the installation. You should have 3 main pieces. Right side, left
side, and backside. Set aside 30 minutes for the first time you
install your netting. Installation is done easiest with the hard
Step 1
Start with the back piece first.
Install the short straps on the
side roll bars first. For correct
positioning the fifth strap from
the bottom attaches at the top
of the roll bar. Each additional
strap installs down the roll bar.
The last strap connects to the
rear fender with the strap in
the lower photo. This strap
connect to the under side of
the fender lip using the longer
bolts provided. These will
thread into the hardtop nut if
you have them or you can use
the nut and washer we have
Installation Instructions
Spider Rear Netting
DD-N-JK4-07RS
Jeep JK unlimited 2007-up
Advertisement
Table of Contents
Related Manuals for Dirty Dog 4x4 DD-N-JK4-07RS
Summary of Contents for Dirty Dog 4x4 DD-N-JK4-07RS
-
Page 1: Installation Instructions
Installation Instructions Spider Rear Netting DD-N-JK4-07RS Jeep JK unlimited 2007-up VIDEO INSTALLATION INSTRUCTIONS AVAILABLE AT: WWW.DIRTYDOG4X4.COM OR WWW.FACEBOOK.COM/DIRTYDOG4X4 Thank you for purchasing a Dirtydog 4x4 netting system. Please read these instructions fully to familiarize yourself with the installation. You should have 3 main pieces. Right side, left side, and backside. - Page 2 Slide each half of the aluminum tailgate bar in the last row as shown in the photo. This bar will connect at the center of the net and then the whole bar is clipped into soft-top tailgate clips. (Clips can be purchased form us or your local dealer.) This last row is optional and can be cut off if not needed.
- Page 3 STEP 2 Start with either side. There are 4 rings that attach with straps. 2 rings attach sharing the straps you already installed on the rear section (white arrows) and 2 rings that attach with additional straps provided (black arrows). The bottom Next is to install is the attaching strap with the nut and washer provided.
- Page 4 The last strap at the bottom can now be installed using the loop at the rear strap that you installed at the beginning. Inside view Any excess straps that hang out can be tucked in under itself. Adjust and tighten straps as needed to even out the net so it is positioned properly. Your net comes with a 3 year warranty against manufacturing defects.
- Page 5 Buckle with Buckle with roll bar Wrap roll bar Wrap Buckle with Buckle with grommet grommet...
