- Page 1 Manual for RockBoard® MOD 7 Audio Interface Patchbay - 1 -...
-
Page 2: Table Of Contents
Contents Introduction ............................3 Precautions ............................. 3 Power Supply ............................ 3 Connections ............................3 Interference with other electrical devices ..................3 Cleaning ............................3 Handling ............................3 FCC certification ..........................3 Main Features ............................4 Mounting ..............................5 Mounting on a RockBoard® Pedalboard .................. -
Page 3: Introduction
Introduction Thank you for purchasing a RockBoard® MOD 7 - the new gateway from your effects rig to your DAW! The RockBoard® MOD 7 Audio Interface Patchbay offers an easy to use audio interface without special driver or software requirements. It also acts as an active DI box and offers a simple solution to organize all of the connections to and from your effects setup. -
Page 4: Main Features
Main Features • USB audio interface • Recording and digital signal processing via DAW plugins • No special drivers or software requirements • Output via USB Type A, 2 x unbalanced 6.3 mm / 1/4" TS jack, balanced XLR • Integrated active DI Box •... -
Page 5: Mounting
Mounting There are multiple options for mounting your new MOD 7 onto a RockBoard® pedalboard. You can either mount it in its MOD slot (available on all RockBoard® pedalboards except DUO 2.0 and 2.1) or detach the MOD’s front plate and mount it on top or underneath your pedalboard. -
Page 6: Detaching The Mod 7'S Front Plate
Detaching the MOD 7’s front plate When mounting the MOD 7 All-in-One Patchbays on top or underneath your pedalboard, you will have to detach the front plate, so it will fit flush onto/under the board surface. Using a PH2 Phillips head screw driver, remove the screws as indicated below to release the front plate from your MOD 7. -
Page 7: Mounting On A Non-Rockboard® Pedalboard
Mounting on a non-RockBoard® pedalboard There are multiple ways of mounting your MOD 7 on a non-RockBoard® pedalboard. You can either mount it directly to the board surface using hook & loop tape or another reclosable fastener. Additionally RockBoard® offers the MOD Rack for mounting your MOD 7 in various ways onto, into, or underneath pedalboards of other manufacturers. -
Page 8: Setup & Operation
Setup & Operation Setup example AMP FOOTSWITCH BYPASS / MUTE FOOTSWITCH FTSW FOH MIXER MONITORS SEND FTSW IN RETURN PC / DAW / MAC Thru-Connections The RockBoard® MOD 7 Audio Interface Patchbay is designed to act as central access point to your effects setup. -
Page 9: Unbalanced Outputs 1 & 2
Unbalanced outputs 1 & 2 The MOD 7’s unbalanced outputs can be used for sending signal to either monitors or other powered speakers as well as amplifiers. Please note, UNBAL OUT 1 will also work without power or in bypass. UNBAL OUT 2 (as well as the active XLR BAL OUT) however, will be deactivated when the connection to power is lost or the unit is in bypass mode. - Page 10 Framus & Warwick Music USA, Inc. • 1922 Air Lane Drive • Nashville, TN • 37210 • info@rockboard.net • 629.202.6790 CHINESE DISTRIBUTION Warwick Music Equipment Trading (Shanghai) Co. Ltd., No. 399 Shanning Road, Jinshan District • 201508 • info@warwick.cn • +86 21 34060110 NORTH Distribution www.rockboard.de...
