Welcome to Digatron
This manual covers the operation of your DT-51S instrument.
Both racers and recreational riders can use this instrument. Racers may be interested in recording in time segments, either laps or
sections of the strip or course. Recreational drivers will usually be interested in recording without laps.
This book provides the information you need to quickly set up and use your instrument. It is a great reference guide.
If you are interested in learning more about how your Digatron instrument can help you analyze your engine functions and driving
techniques, please visit our website, www.digatronusa.com, or phone (509) 467-3128.
Note: These instructions cover current versions. If you have an older version, and
find the instructions don't exactly match, please contact Digatron at
support@digatronusa.com
or toll free at 866.344.2876.
Advertisement
Table of Contents
Related Manuals for Diatron DT-51S
Summary of Contents for Diatron DT-51S
-
Page 1: Table Of Contents
Repairs and Warranty ..................8 Welcome to Digatron This manual covers the operation of your DT-51S instrument. Both racers and recreational riders can use this instrument. Racers may be interested in recording in time segments, either laps or sections of the strip or course. Recreational drivers will usually be interested in recording without laps. -
Page 2: Instrument Functions
Instrument Functions A. Power/Record Start Vehicle. Instrument turns on and starts recording automatically when a tach signal is received. Records for 2 hours, then records over oldest data. B. Overall Maximums Press Press and Repeat release to cycle steps 1 & 2 hold. - Page 3 E. Maximums by Lap Select a lap. See D. Lap Times. Displays engine data, Displays lap data. showing maximum Press and hold to values for this lap. view Event number. EVENT Changes lap backward or forward one. Displays flash when your best lap is SET UP LIGHT shown.
-
Page 4: Batteries Not Needed
Batteries Not Needed When your vehicle is running, the DT-50S series instrument gets power from the lighting coil. To use your instrument for an extended time without power from the lighting coil, you can buy a wall adaptor to power your instrument. When your engine is off, the instrument is powered by super caps, which are similar to rechargeable batteries. -
Page 5: Tach Calibration Number (Rpm1)
Tach Calibration Number (RPM1) The Tach limit requires two separate parameters. The first is the maximum revolutions per minute (RPM) for safe engine operation. The second number, the Tach calibration, allows the instrument to display the correct RPM for your engine. The instrument divides the Tach input signal by the Tach calibration number. -
Page 6: Recording
Recording The instrument records in sessions called Events (shown by an E), which start each time the instrument begins recording. Within Events, time segments (Laps, L on the display) are created with infrared beacon receivers and transmitters or with a store switch. To end an Event your engine must be turned off, the Exit button must be pressed, or the Tach must go below 200 RPM (this value can be changed on your PC). -
Page 7: Button Functions
Button Functions Time (top, side button): (2) functions A. Displays lap/segment time and number. B. Press and hold to show best lap/segment time. Engine (bottom, side button) (2) functions A. Cycles between three sets of data. B. Press and hold to show maximums and designators. Power / Exit (2) functions A. -
Page 8: Designators Defined
Designator Definitions The following is a list of designators that can appear in the main part of your display: select this to set your engine limits select this to set your warning lights displayed if the Play button is pressed and there is no recorded data displayed if a warning light is set to not come on displayed when setting the Tach or MPH calibration number displayed if your batteries are low...
