Manuale per l'installazione e l'uso
Installation and operation manual
46916.004
Tastiera IP per controllo PTZ
IP keyboard for PTZ control

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELVOX 46916.004 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vimar ELVOX 46916.004

  • Page 1 Manuale per l’installazione e l’uso Installation and operation manual 46916.004 Tastiera IP per controllo PTZ IP keyboard for PTZ control...
  • Page 2 Grazie per aver acquistato questo prodotto. Il manuale potrebbe contenere indicazioni tecniche non corrette ed errori di stampa. Gli aggiornamenti verranno aggiunti alla nuova versione del manuale. I miglioramenti o gli aggiornamenti dei prodotti o delle procedure descritte nel manuale saranno prontamente implementati. I contenuti sono soggetti a modifiche senza preavviso. Nota Il display LCD è...
  • Page 3: Table Of Contents

    4.7 Avvio o interruzione della scansione automatica ....................10 4.8 Attivazione/disattivazione della luce ........................10 4.9 Attivazione/disattivazione del tergicristallo ......................10 4.10 Riproduzione registrazione..........................10 5 Altre funzioni .................................. 12 5.1 Visualizzazione delle informazioni ......................... 12 5.2 Blocco..................................12 6 Specifiche..................................13 Appendice VIMAR group...
  • Page 4: Introduzione

    1 Introduzione 1.1 Introduzione Questa tastiera di rete permette di comandare direttamente fino a 10 PTZ IP tramite connessione Ethernet.. È facile da utilizzare grazie alla visualizzazione dei menu sullo schermo. 1.2 Istruzioni per il pannello posteriore Nome Descrizione PW (Alimentazione) Quando la tastiera di rete è...
  • Page 5 Premere per allungare la messa a fuoco FOCUS- Premere per accorciare la messa a fuoco ZOOM+ Zoom avanti ZOOM- Zoom indietro IRIS+ Aumenta l'apertura del diaframma IRIS- Riduce l'apertura del diaframma WIPER Attiva o disattiva il tergicristallo LIGHT Attiva o disattiva la luce VIMAR group...
  • Page 6: Regole Per L'uso Dei Tasti

    1.4 Regole per l'uso dei tasti Pressione ripetuta del tasto con intervallo inferiore ai 2 secondi tra le pressioni. Si utilizza principalmente per inserire lettere dell'alfabeto. Ad esempio, premere due volte 2 per inserire A, premere tre volte 2 per inserire B. Vedere l'appendice per informazioni dettagliate sull'uso dei tasti.
  • Page 7: Configurazione

    È possibile inserire un valore ID compreso tra 1 e 32. Per impostare l'ID della tastiera, premere i tasti numerici e quindi confermare (ad es. premere 32 e il tasto "Enter" per impostare 32 come numero di identificazione della tastiera). VIMAR group...
  • Page 8: Impostazione Dell'id Della Tastiera

    2.2.3 Configurazione della rete La configurazione della rete comprende l'impostazione dell'IP locale e dell'IP PTZ. L'indirizzo IP locale e l'indirizzo IP PTZ , devono trovarsi nello stesso segmento di rete locale. ➢ Local IP Setup (Impostazione IP locale) Selezionare "Local IP Setup" e prendere "Enter" per accedere all'impostazione dell'IP locale. Qui è possibile impostare l'indirizzo IP locale, la subnet mask, il gateway predefinito, il server DNS, il DNS alternativo e la porta HTTP.
  • Page 9: Modo Ptz

    3.4 Passaggio a un'altra PTZ Selezionare un'altra telecamera PTZ e impostare l'indirizzo IP, la porta, il nome e la password. Per maggiori dettagli, vedere 3.2 Impostazione IP PTZ. Premere "SHIFT" per commutare tra le PTZ di cui è stato impostato l'indirizzo. VIMAR group...
  • Page 10: Controllo Ptz

    4 Controllo PTZ Il comando PTZ ha effetto solo se l''indirizzo IP selezionato è quello di un dispositivo con capacità PTZ (o telecamera speed dome). 4.1 Movimento o arresto La procedura di impostazione è la seguente: 1 - Comandare la telecamera speed dome/PTZ muovendo il joystick. Quando si riporta il joystick nella posizione iniziale, la telecamera speed interrompe il movimento.
  • Page 11: Focus

    Per impostare la messa a fuoco +/- 1 - Premere "FOCUS+" o "FOCUS-". 4.5 Zoom +/- Per impostare lo zoom +/- 1 - Premere "ZOOM+" o "ZOOM-". 4.6 Iris +/- Per impostare l'apertura diaframma +/- 1 - Premere "IRIS+" o "IRIS-". VIMAR group...
  • Page 12: Avvio O Interruzione Della Scansione Automatica

    4.7 Avvio o interruzione della scansione automatica Per avviare o interrompere la scansione automatica 1 - Premere "AUTO" per avviare la scansione automatica: premere di nuovo "AUTO" per interrompere la scansione automatica. 4.8 Attivazione/disattivazione degli IR (modalità Bianco/Nero) Per attivare o disattivare la luce 1 - Premere "LIGHT"...
  • Page 13: Altre Funzioni

    Quando la tastiera è bloccata, tutti i tasti ad eccezione dei tasti numerici della tastiera non sono disponibili fino a quando viene immessa la password per sbloccare la tastiera. Suggerimenti: se si immette la password sbagliata per più di tre volte è possibile resettarla rispondendo alla domanda di sicurezza che era stata impostata dall'utente stesso. VIMAR group...
  • Page 14: Specifiche

    6 Specifiche Display locale Locale Joystick Quadridimensionale RJ45 10/100Mbps×1 Rete Modo comando Porta seriale RS485 Non disponibile Alimentazione 12 Vcc Assorbimento ≤8W Temperatura di esercizio -10°C ~ +60°C Altri Umidità di esercizio 10%--90% Dimensioni 420 (L) x 260 (P) x 170 (H) mm Peso 2,8 kg Appendice...
  • Page 15 - This keyboard should be used in certain range of temperature and humidity, referring the specifications. - Please connect the keyboard correctly as this manual requires. Items Quantity Note Network keyboard 12Vdc power adapter 12Vdc power adapter Included user manual VIMAR group...
  • Page 16 Contents 1 Introduction ...............................15 1.1 Introduction ...............................15 1.2 Rear Panel Instructions ..........................15 1.3 Front Panel Instructions ..........................15 1.4 Rules of Key Press ...........................17 1.5 Joystick Control ............................17 2 Setup..................................18 2.1 Startup the Keyboard ..........................18 2.2 System Setup ............................18 2.2.1 Password Setup ..........................18 2.2.2 Keypad ID Setup ..........................18 2.2.3 Network Setup ..........................19 2.2.4 Default Setup ...........................19...
  • Page 17: Introduction

    1.2 Rear Panel Instructions Name Description When the network keyboard is working, the power indicator turns red. LINK The network status indicator RS232 Unavailable RJ45 RJ45 network port RS485 Unavailable DC-12V DC12V power input WIFI Unavailable Grounding 1.3 Front Panel Instructions VIMAR group...
  • Page 18 Name Functions SETUP Local setup, such as keyboard ID, network setup. INFO Local information, such as ID, model, network parameters. SHIFT Auxiliary key for main interface shift or PTZ shift or security questions shift. LOCK Lock keyboard; press this key to lock the keyboard Set the output (monitor).
  • Page 19: Rules Of Key Press

    Lower left In PTZ control mode: control the speed dome to move towards lower left. Lower right In PTZ control mode: control the speed dome to move towards lower right. Rotate left Zoom in Rotate right Zoom out VIMAR group...
  • Page 20: Setup

    2 Setup 2.1 Startup the Keyboard First connect the network cable to the keyboard and then connect the power. After the device starts, please input the default password (8888) and then press “Enter” key to go to main interface (see left figure). Press “Setup” key to go to the system setup menu (see right two figures).
  • Page 21: Network Setup

    2.5 Test Select it and press “Enter” to test if the button is available. User can also check if the silk-screen on the button and display on the screen is consistent which is not use for operating equipment. VIMAR group...
  • Page 22: Ptz Mode

    3 PTZ Mode 3.1 Mode Setup Platform mode and PTZ mode are optional. Select PTZ mode and press “Enter” to select. 3.2 PTZ IP Setup Go to Network Setup to select “PTZ IP Setup” and press “Enter” to go to select the PTZ. Then set the IP address, port, name, password of the PTZ selected.
  • Page 23: Ptz Control

    For example, input 1 and then press “PRESET” for more than 2 seconds to set the NO.1 preset. To call preset 1 - Select the preset. For example, input 1 and press “Preset”. 4.3 Call or Stop Cruise/Track To call cruise/track . 1 - Select the cruise/track. For example, input 1 and press “CRUISE/TRACK”. VIMAR group...
  • Page 24: Focus

    To stop cruise/track 1 - Select the cruise/track. For example, input 0 and press “CRUISE/TRACK” or press “CRUISE/TRACK” directly. 4.4 Focus +/- To set focus +/- 1 - Press “FOCUS+”or “FOCUS-”. 4.5 Zoom +/- To set zoom +/- 1 - Press “ZOOM+”or “ZOOM -”. 4.6 Iris +/- To set iris +/- .
  • Page 25: Start Or Stop Auto Scan

    1 - Press “LIGHT” to enable light; press “LIGHT” again to disable light. 4.9 Enable/Disable Wiper To enable or disable wiper 1 - Press “WIPER” to enable light; press “WIPER” again to disable light. 4.10 Record Playback Unavailable VIMAR group...
  • Page 26: Others

    5 Others 5.1 View Information You may check the keyboard, model, SN, current mode, version, date, local IP, subnet mask and so on by pressing “INFO” key on the keyboard. Check the next page of the information by moving the joystick down. 5.2 Lock You can lock the keyboard by pressing “LOCK”...
  • Page 27: Specifications

    Digital number/ alphabet input rules are listed in the following table. The relationship between the frequency of key-press and input display once twice three times four times five times six times seven times eight times nine times blank VIMAR group...
  • Page 28 Viale Vicenza, 14 36063 Marostica VI - Italy 49401117A0 00 1610 www.vimar.com...
