VGADVI Broadcaster Pro User Guide
Table 36 Supported Frame Grabber Configuration Keys
Key
gain
hshift
offset
phase
pll
tune_interval
vshift
Broadcast Configuration Keys
The following broadcast configuration settings are supported.
Table 37 Supported Broadcast Configuration Keys
Key
bcast_disabled
rtsp_port
streamport
Values
0...255
-999...999
0...63
0...31
-999...999
0...9999
-20...20
Values
on
empty string ("")
1000...65535,
but not 5557
1000...65535,
but not 5557
7-10 Configuration Keys for Third Party APIs
Description
Specifies ADC gain adjustments.
0 is brightest, 255 is darkest.
Specifies horizontal shift.
For shifts to the left, use positive values.
For shifts to the right, use negative values.
Specifies ADC offset.
0 is brightest, 63 is darkest.
Specifies phase adjustments for VGA signals. Generally not used
unless value is provided by Epiphan support.
Specifies PLL adjustment.
Changes the number of pixels in the line.
Specifies the number of auto-adjustments in the interval.
To disable auto-adjustments, set to 0.
Specifies vertical shift.
For shifts up, use positive values.
For shifts down, use negative values.
Description
Enables or disables the broadcast.
To disable broadcast, set to on.
To enable broadcast, set to empty string ("").
Specifies the port for RTSP streaming. Note port 5557 is used for
network discovery and cannot be used for streaming.
Specifies the port used for streaming. Note port 5557 is used for
network discovery and cannot be used for streaming.
194
