CONWIN Dual Split-Second Sizer Instruction Sheet page 4

Air Compressor Recommendations
Most air compressors are factory set to automatically cycle on at 90 PSI
and automatically cycle off at 120 PSI. The Dual Split-Second Sizer must
have a steady supply of air or gas to produce equal size balloons. For
accurate sizing, it is essential to work within the limits of the cubic foot per
minute capacity of the air compressor.
Air Compressor Required Specifications
• Primary Moisture Filter
• 20 Gallon Storage Tank
• Cycle Pressure: 90 PSI On - 120 PSI Off
• Compressed Air Availability: 6.5 Cubic Foot/Minute @ 90 PSI
Shutting Down the Dual Split-Second Sizer
1. Close the cylinder valve and turn the air compressor off.
2. Press down the foot pedal to cycle the system until all the pressure has been released from the unit.
3. Disconnect the supply hose from the back of the sizer. Remove regulator from the cylinder.
4. Unscrew the inflating outlets and place them in the compartment located in the lid of the carrying case.
5. Pack the Dual Sizer, supply hose, power cord, and regulator in carrying case.
Service & Warranty
For assistance with service & repair
issues, or for warranty information,
ConwinOnline.com
please visit
(818)246.9233
or call
04102006
Dual Split-Second Sizer Accessories
The Insider
Balloon Stuffing Tool
The Insider Balloon Stuffing Tool is an
accessory item for Conwin's automatic sizing
inflators. This fast and easy-to-use tool
efficiently fills large balloons with the
maximum number of small balloons. The
Insider can be clamped to any convenient
table or workstation. Conwin # 85900
Add-On Foot Pedal
With the Add-On Foot Pedal, two
people can use the Dual Split-
Second Sizer at the same time!
Conwin # 36330
60/40 Helium-Air Outlet
The 60/40 Helium/Air Outlet enables the
user to inflate 14" or larger balloons
with a mixture of 60% helium and 40%
air. The 60/40 Helium/Air Outlet easily
attaches to the Dual Split-Second Sizer
with a hand-tight connection.
Conwin # 36310
,
Important Guidelines When Using an Air Compressor
• Compressor must build up the tank pressure before inflating balloons.
• The output setting on the air compressor should not exceed 80 PSI. If
the compressor is set higher than 80 PSI, the Dual Split-Second Sizer will
out-perform the compressor's storage tank capacity.
• After each job, blow down the compressor to remove water collected
in the tank during compression. The Dual Sizer will require factory
rework and recalibration if moisture enters its system.
• Power surges will affect the Dual Split-Second Sizer accuracy - line voltage
must be steady at 120 volts.
Online
Projects
Designs
Galleries
...and more!
Air Compressor Hook-Up
The Air Compressor Hook-Up, with quick-
disconnect fittings, allows user to operate Dual
Split-Second Sizer up to 12-ft. away from the
compressor. Hook-Up air line also includes a filter
that prevents dirt and moisture from entering
the inflator.
Conwin # 36340
Helium/ Hi-Float Adapter
Save time by dispensing Hi-Float™ and inflating
balloons right from the pump outlet.
Conwin # 36400
HI-FLOAT Outlet
®
The hand-tight HI-FLOAT Outlet enables the user
®
to inflate balloons filled with HI-FLOAT
This prevents any HI-FLOAT from getting into the
®
Dual Split-Second Sizer.
Conwn # 36320
He/N Quick Switch
2
The He/N2 Quick Switch allows the user to
switch from helium to nitrogen by turning the
knob. Exclusively designed to be used with
Conwin's Duplicator 2 and Dual Split-Second
Sizer models that feature the second stage
regulator separate from the supply line and
primary regulator.
Conwn # 36350
Portable Power Pack
This compact unit provides
power for over 5 hours of
continual use! It features a
built-in consumption meter, a
recharger, and even comes
with its own convenient
soft pack. It's a must for
on-the-job decorating!
Conwn # 86000
neck up.
®
