Dual Split-Second Sizer
Instruction Sheet
Getting Started
• To prevent the risk of electrical shock, do not use the Dual Split-
Second Sizer outdoors when weather conditions are wet. Never
operate unit on a wet floor or work area.
• Prior to plugging the Dual Split-Second Sizer into an electrical
out-let, verify the electrical rating, listed on the label on the back of
the Dual Split-Second Sizer, is suitable for outlet.
• If the Dual Split-Second Sizer malfunctions or is damaged in any
way discontinue use and unplug unit from electrical outlet. Contact
an authorized Conwin Service Center for details on how to receive
service.
• Never attempt to repair the Dual Split-Second Sizer yourself.
Opening the Dual Split-Second Sizer case will automatically void
manufacturer warranty. Contact an authorized Conwin Service
Center for all repairs.
• When using helium or nitrogen, always secure the cylinder in a
safety stand or wall bracket.
1
Hand-tighten the primary regulator to a helium
or nitrogen cylinder. Make sure the cylinder is
properly secured in a safety stand or wall bracket
prior to attaching the primary regulator. Note:
Do not open the cylinder valve until Step 6.
4
Plug the foot pedal into the side of the unit.
Dual Split-Second Sizer Includes:
• 1 Dual Split-Second Sizer Inflator
• 1 Helium/Nitrogen Regulator
• 1 Supply Hose & Foot Pedal Control
• 2 Latex Balloon Filling Outlets
• 1 Power Cord
• 1 Double Bubble Outlet
Primary
Regulator
2
Push to connect the supply hose to the back outlet
on the Dual Split-Second Sizer.
5
Hand-tighten the blue inflating outlets.
On/Off
Adjustable Regulator
LED Mode
Indicator
Digital
Timer
Readouts
Foot
Pedal
3
Plug the power cord into the side of the unit
and into an electrical outlet. (A power strip
with surge protector is recommened.) The
digital display will appear when unit has
power.
6
Slowly open the cylinder valve. Make sure the
valve is fully opened. The cylinder pressure will
read on the gauge located on the regulator. The
inlet pressure will read on the second stage
regulator gauge, located on the back of the unit.
