  • Page 1 R-Class Owner's Manual Nur für internen Gebrauch / For internal use only...
  • Page 2 Symbols In this Owner's Manual, you will find the fol- lowing symbols: WARNING Warning notices draw your attention to haz- ards that may endanger your health or life, or the health or life of others. Environmental note Environmental notes provide you with infor- mation on environmentally aware actions or disposal.
  • Page 3 Welcome to the world of Mercedes-Benz The technical documentation team at Daimler AG wishes you safe and pleasant Before you first drive off, read this Owner's motoring. Manual carefully and familiarise yourself with your vehicle. For your own safety and a longer vehicle life, follow the instructions and warn- ing notices in this manual.

  • Page 5: Contents

    Contents Index ............4 At a glance ........... 27 Introduction ......... 21 Safety ........... 39 Opening and closing ......69 Seats, steering wheel and mirrors ..91 Lights and windscreen wipers ..109 Climate control ......... 123 Driving and parking ......143 On-board computer and displays ..

  • Page 6: Table Of Contents

    Index Air pressure 1, 2, 3 ... see Tyre pressure 12 V socket Air vents see Socket Important safety notes ....139 4ETS Rear ..........140 see ETS/4ETS (Electronic Trac- Setting ........... 139 tion System) Setting the centre air vents ... 140 4MATIC (permanent four-wheel Setting the side air vents ....
  • Page 7 Index Engaging neutral ......151 Battery (vehicle) Engaging reverse gear ....151 Charging ........303 Engaging the park position .... 151 Display message ......219 Kickdown ........152 Important safety notes ....301 Overview ........150 Jump starting ......... 304 Problem (fault) .......
  • Page 8 Index Overview of bulb types ....116 Parking lamps (front) ..... 118 Calling up a fault Removing/replacing the cover see Display messages (front wheel arch) ......117 Reversing lamps ......119 see Vehicle Standing lamps ......118 Care Turn signals (front) ......118 Automatic car wash .......
  • Page 9 Index Setting the air vents ...... 139 Crash-responsive emergency light- Setting the temperature ....131 ing ............115 Switching air-recirculation mode Cruise control on/off ..........133 Activating ........164 Switching on/off ......128 Activation conditions ..... 164 Switching residual heat on/off ..134 Cruise control lever .......
  • Page 10 Index Dipped-beam headlamps Emergency locking ......78 Changing bulbs ......117 Emergency unlocking ....... 77 Display message ......215 Important safety notes ....76 Setting for driving abroad (sym- Opening (from the inside) ....76 metrical) ........110 Doors Switching on/off ......111 Overview ..........
  • Page 11 Index Driving in winter ......162 Emergency spare wheel Driving on flooded roads ....162 Important safety notes ....328 Driving on wet roads ...... 162 Inflating the collapsible spare Fuel ..........160 wheel ..........330 General .......... 160 Points to remember ....... 329 Icy road surfaces ......
  • Page 12 Index ETS/4ETS (Electronic Traction Sys- Fuel tem) ............63 Additives ........340 Exhaust tail pipe (cleaning instruc- Calling up the range ....... 208 tions) ..........287 Consumption information ....342 Exterior lighting Consumption statistics ....207 Displaying the current consump- see Lights Exterior mirrors tion ..........
  • Page 13 Opening/closing the garage door .. 268 Inspection Programming (button in the rear- see ASSYST PLUS view mirror) ........267 Instrument cluster Genuine Mercedes-Benz parts ..336 Overview .......... 30 Glove compartment ......247 Selecting the language (on-board computer) ........201 Settings ......... 200 Warning and indicator lamps ...
  • Page 14 Index Problem (malfunction) ..... 75 Main-beam headlamps ....113 Starting the engine ......146 Parking lamps ........ 111 KEYLESS-GO Rear foglamp ......... 112 Convenience closing ......84 Side lamps ........111 Display message ......232 Switching the daytime driving Locking ..........71 lights on/off (on-board computer) .
  • Page 15 Matt finish (cleaning instructions) . . 285 see Trip meter Memory card (audio) ......198 Off-road system Memory function ....... 108 4MATIC .......... 176 Mercedes-Benz Service Centre see Engine oil see Qualified specialist workshop On-board computer Messages Additional functions menu ..... 207 see Display messages AIRMATIC/compass menu ....
  • Page 16 Index Outside temperature display ... 195 Petrol ..........340 Overhead control panel ...... 36 Plastic trim (cleaning instructions) . 288 Override feature Power windows Rear side windows ......61 see Side windows ® PRE-SAFE (preventive occupant safety system) Display message ......214 Paint code ..........
  • Page 17 Index Rear lamps Roof lining and carpets (cleaning see Lights instructions) ........289 Rear seat Roof load (maximum) ......346 Adjusting ......... 98 Route (navigation) Rear-view mirror see Route guidance (navigation) Route guidance (navigation) .... 199 Anti-dazzle mode (automatic) ..107 Dipping (manual) ......
  • Page 18 Index Folding the rear bench seat for- Problem (malfunction) ..... 89 wards/back ........250 Rain closing feature ......86 Important safety notes ....93 Resetting ......... 86 Overview .......... 93 see Panorama sliding sunroof Seat heating problem ....102 Snow chains Seat ventilation problem ....
  • Page 19 Index Steering wheel Opening/closing (automatically Adjusting (electrically) ....104 from outside) ........79 Adjusting (manually) ...... 103 Opening/closing (from outside) ..79 Button overview ....... 33 Opening dimensions ...... 346 Buttons (on-board computer) ..195 Tail lamps Cleaning ......... 289 Display message ......
  • Page 20 Index Towing a trailer Axle load, permissible ....349 Operating (on-board computer) ..198 see Separate operating instructions ® (Electronic Stability Pro- Two-way radio gram) ..........64 Frequencies ........337 Towing away Installation ........337 Fitting the towing eye ....307 Transmission output (maximum) ..
  • Page 21 Index ® ..........237 ® OFF ........238 Vanity mirror (in sun visor) ....262 LIM (cruise control) ......163 Variable SPEEDTRONIC LIM (DISTRONIC) ......169 see SPEEDTRONIC LIM (variable SPEEDTRONIC) ..166 Vehicle Overview .......... 32 Correct use ........24 PASSENGER AIRBAG OFF ....
  • Page 22 Index Replacing the wiper blades .... 121 Switching on/off ......120 Winter driving General notes ........ 314 Winter operation Overview ........314 Radiator cover ....... 279 Slippery road surfaces ....162 Snow chains ........315 Winter tyres Limiting the speed (on-board com- puter) ..........

  • Page 23: Returning An End-Of-Life Vehicle

    Mercedes-Benz will take back your planet to be used sparingly and in a manner Mercedes-Benz to dispose of it in an environ- which takes the requirements of both nature mentally responsible manner, in accordance and humanity into account.

  • Page 24: Equipment

    The use of non-approved parts could affect vehicle. your vehicle's operating safety. Mercedes-Benz therefore recommends that Operating safety you use genuine Mercedes-Benz parts, con- version parts and accessories that have been Important safety notes approved for the type of vehicle. WARNING...

  • Page 25: Diagnostics Connection

    This could compromise the work on electronic components operating safety of your vehicle while driving. Mercedes-Benz recommends that you use a There is a risk of an accident. Mercedes-Benz Service Centre. Do not connect any equipment to a diagnos- tics connection.

  • Page 26: Correct Use

    Mercedes-Benz implied warranty or by the Mercedes-Benz can only inform you about New or Used-Vehicle Warranty. vehicle checks if it has your registration data.
  • Page 27 Introduction FOR ANY DIRECT, INDIRECT, INCIDENTAL, Copyright information SPECIAL, EXEMPLARY, OR CONSEQUENTIAL FreeType DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS © Portions of this software are copyright 2005 OR SERVICES; LOSS OF USE, DATA, OR The FreeType Project (www.freetype.org). All PROFITS;...
  • Page 29 Cockpit ..........28 Instrument cluster ......30 Multifunction steering wheel ..... 33 Centre console ........34 Overhead control panel ...... 36 Door control panel ......37...

  • Page 30: Wheel

    Cockpit Cockpit Function Page Function Page Steering wheel gearshift Adjusting the steering paddles wheel manually Cruise control lever Adjusting the steering wheel electrically Instrument cluster Steering wheel heating Horn Parking brake DIRECT SELECT lever Diagnostics connection PARKTRONIC warning dis- Opening the bonnet play Releasing the parking brake Overhead control panel...

  • Page 31: Wheel

    Cockpit Function Page Function Page Overhead control panel Diagnostics connection PARKTRONIC warning dis- Ignition lock play Start/Stop button Cruise control lever Adjusting the steering wheel manually Horn Adjusting the steering Instrument cluster wheel electrically DIRECT SELECT lever Steering wheel heating Steering wheel gearshift Parking brake paddles...

  • Page 32: Fuel Gauge

    Instrument cluster Instrument cluster Displays and controls Instrument cluster: kilometres Function Page Function Page To adjust the instrument cluster lighting: brighter Speedometer with seg- ments Rev counter Unit of measurement for Fuel gauge the speedometer Multifunction display To adjust the instrument Time cluster lighting: dimmer Reset button...
  • Page 33 Instrument cluster Instrument cluster: miles Function Page Function Page To adjust the instrument cluster lighting: brighter Speedometer with seg- ments Rev counter Unit of measurement for Fuel gauge the speedometer Multifunction display To adjust the instrument Time cluster lighting: dimmer Reset button...

  • Page 34: Warning And Indicator Lamps

    Instrument cluster Warning and indicator lamps Function Page Function Page ! ABS ü Seat belt È LIM % Diesel engine: pre- glow ® ÷ ESP + SRS · Distance warning L Dipped-beam head- On vehicles without DIS- lamps TRONIC, the lamp lights up briefly but has no function.
  • Page 35 Multifunction steering wheel Multifunction steering wheel Function Page Function Page Multifunction display Switches on LINGUA- Audio system/COMAND TRONIC; see the separate APS; see the separate oper- operating instructions ating instructions Selects a menu: scrolls Rejecting or ending a call backward and forward Exits telephone book/ redial memory Switches off LINGUA-...

  • Page 36: Upper Section

    Centre console Centre console Centre console, upper section Function Page Function Page Audio system/COMAND £ Hazard warning APS; see the separate oper- lamps ating instructions ATA indicator lamp c Seat heating c PARKTRONIC s Seat ventilation ® å ESP & Auxiliary heating e Adaptive Damping Á...

  • Page 37: Lower Section

    Centre console Centre console, lower section Function Page Function Page Stowage compartment Stowage compartment Ashtray Stowage tray Cigarette lighter Stowage compartment Cup holders...

  • Page 38: Overhead Control Panel

    Overhead control panel Overhead control panel Function Page Function Page p Switches the left- 2 Opens/closes the hand reading lamp on/off sliding sunroof 2 Opens/closes the u Switches the rear panorama sliding sunroof interior lighting on/off with roller sunblinds | Switches the auto- Rear-view mirror matic interior lighting con- trol on/off...

  • Page 39: Control Panel

    Door control panel Door control panel Function Page Function Page Opens the door n Activates/deacti- vates the override feature %& Unlocks/locks for the side windows in the the vehicle rear compartment 7 Adjusts the exterior ± Opens/closes the mirrors hinged power side windows Zö\ Selects the q Opens/closes the exterior mirror, electrically...
  • Page 41 Useful information ......40 Panic alarm .......... 40 Occupant safety ........40 Children in the vehicle ......51 Driving safety systems ....... 61 Anti-theft systems ......66...

  • Page 42: Useful Information

    Occupant safety Useful information Occupant safety Important safety notes This Owner's Manual describes all mod- els, series and optional equipment for your WARNING vehicle that were available at the time of If service work is not carried out correctly, the going to press.

  • Page 43: Occupant Safety

    Occupant safety To ensure that the restraint systems can SRS reduces the risk of occupants coming deliver their full potential protection, make into contact with the vehicle's interior in the sure that: event of an accident. It can also reduce the forces to which occupants are subjected dur- the seat and head restraint are adjusted ing an accident.
  • Page 44 Occupant safety If there is an even higher rate of vehicle decel- The front belt tensioners can only be trig- eration or acceleration in a longitudinal direc- gered if the seat belt tongues on the front tion, the front airbags are also deployed. seats are correctly engaged in the seat belt buckles.
  • Page 45 Occupant safety move the front-passenger seat as far back make sure that there are no people, ani- as possible. This is especially important if mals or objects between the vehicle occu- you have secured a child in a child restraint pants and the area where the airbags are system on the front-passenger seat.

  • Page 46: Sidebag

    Have restraint systems that have been trig- Sidebags gered replaced. WARNING If you wish to use seat covers, Mercedes-Benz recommends that, for safety reasons, you only use seat covers that have been approved for Mercedes-Benz vehicles. The seat covers must have a special tear seam for sidebags.

  • Page 47: Windowbag

    Occupant safety Front sidebags : and sidebags in the 2nd The windowbags are integrated into the side of the roof frame and deploy in the area row of seats ; inflate next to the outer seat extending from the front door (A-pillar) to the cushion.
  • Page 48 PRO luxury head restraints Important safety notes WARNING Only use head restraint covers which have been tested and approved by Mercedes-Benz for your vehicle model. The use of non-approved head restraint cov- ers may prevent NECK-PRO head restraints/ NECK-PRO luxury head restraints from trig- gering properly.
  • Page 49 Occupant safety Firmly push the NECK-PRO head restraint Seat belts cushion back in the direction of arrow = Important safety notes until the cushion engages. Repeat this procedure for the second WARNING NECK-PRO head restraint. A seat belt which is not worn correctly, or which has not been engaged in the seat belt Resetting the NECK-PRO head restraints buckle correctly, cannot provide the intended...

  • Page 50: Fastening

    For safety reasons, Mercedes-Benz recom- page 49). mends that you only use seat belts which have If necessary, adjust the seat belt to the been approved by Mercedes-Benz for your appropriate height ( page 49). vehicle. If necessary, pull upwards on the shoulder...

  • Page 51: Releasing

    Occupant safety For more information about releasing the seat To raise: slide the belt sash guide upwards. belt with release button ?, see "Releasing The belt sash guide engages in various posi- tions. seat belts" ( page 49). To lower: press and hold belt sash guide Seat belt adjustment release :.

  • Page 52: Belt Force Limiter

    The belt tensioners on the outside seats in the Comply with safety regulations when dispos- second row and on the seats in the third row ing of belt tensioners. Any Mercedes-Benz are triggered independently of the lock status Service Centre can provide details of these of the seat belts.

  • Page 53: Children In The Vehicle

    Mercedes-Benz recommends that you use children must never travel sitting on the lap the listed child restraint systems of another occupant. Due to the forces...

  • Page 54: On The Front-Passenger Seat

    Information about recommended child tem from any Mercedes-Benz Service Centre. restraint systems is available at any Mercedes-Benz Service Centre. It is advisable to use Mercedes-Benz care products to clean child restraint systems. You can obtain information about this at any Mercedes-Benz Service Centre.
  • Page 55 Mercedes-Benz child seat with a ted, and the front-passenger front airbag will transponder for automatic child seat recog- not deploy during an accident.

  • Page 56: Isofix

    ISOFIX child seat securing system, which are spe- on the seat cushions of the outer seats in cially tested and approved for Mercedes-Benz the second row vehicles. on the backrests of the seats in the third An incorrectly fitted child restraint system row of seats.

  • Page 57: Top Tether

    Children in the vehicle Top Tether Move the rear seat backrests in the second row to an upright position ( page 98). Top Tether anchorages Slide the upholstered lining over retaining Top Tether provides an additional connection loop : to one side. between the child restraint system secured Install the ISOFIX child restraint system.
  • Page 58 Children in the vehicle Ensure that: Top Tether hook = is hooked into Top Tether anchorage ; as shown. Top Tether belt ? is not twisted. Top Tether belt ? is routed between the rear seat backrest and luggage compart- ment cover if the luggage compartment cover is fitted.

  • Page 59: Suitable Positions

    Problem Possible causes/consequences and M Solutions The 4 PASSENGER A special Mercedes-Benz child seat with a transponder for auto- matic child seat recognition has been fitted to the front-passenger AIRBAG OFF indicator seat. The front-passenger front airbag has therefore been disabled lamp on the centre con- as desired.
  • Page 60 Children in the vehicle versal" category child restraint system with a Key to the letters used in the following table: transponder for automatic child seat recog- ISOFIX position that is not suitable for nition must be fitted when the front- ISOFIX child restraint systems in this passenger airbag is disabled.
  • Page 61 Children in the vehicle Weight category I: 9 to 18 kg, approx- Order number 970 10 00 imately 9 months to 4 years (A 000 ...) Size cat- Equip- Rear Third Automatic child egory ment seat, row of seat recognition left and seats, right...
  • Page 62 Children in the vehicle Carry-cot weight category Category I: 9 to 18 kg Size categories Size categories F, G D, C, B, A Manufacturer – Manufacturer – Type Type – – Approval number – Approval number – (E1 ...) (E1 ...) Order number –...

  • Page 63: Driving Safety Systems

    Driving safety systems Override feature for the rear side win- Do not expose the child restraint system to dows direct sunlight. Parts of the child restraint sys- tem could heat up and the child could burn herself/himself on them. If a child opens a door, the child or other per- sons could be injured as a result.

  • Page 64: Important Safety Notes

    Driving safety systems and for braking in good time. Always adapt tions. ABS works on slippery surfaces, even your driving style to suit the prevailing road when you only brake gently. and weather conditions and maintain a safe The yellow ! ABS warning lamp in the distance from the vehicle in front.

  • Page 65: Ets/4Ets (Electronic Traction System)

    Driving safety systems traffic travelling behind you is warned in an Do not tow vehicles with 4MATIC with the even more noticeable manner. front or rear axle raised. If you brake sharply from a speed of more ® is deactivated if the å warning lamp than 70 km/h to a standstill, the hazard warn- in the instrument cluster lights up continu- ing lamps are activated automatically.
  • Page 66 Driving safety systems Traction control remains active if you deacti- ® still provides support when you ® vate ESP brake. engine torque is not limited and the drive ® Deactivating/activating ESP wheels are able to spin. The spinning of the wheels results in a cutting action for better WARNING traction.
  • Page 67 Driving safety systems Function You should therefore adapt your driving style to the different handling characteristics. Have To activate/deactivate: activate or deac- the brake system checked at a qualified spe- tivate the distance warning function in the cialist workshop. on-board computer ( page 207).

  • Page 68: Function

    Anti-theft systems stationary obstacles, for example, stopped or ATA (Anti-Theft Alarm system) parked vehicles. If you approach an obstacle and the distance warning function detects a risk of a collision, the system will initially alert you both visually and acoustically. In particular, the detection of obstacles can be impaired if there is: dirt on the sensors or anything else cover-...

  • Page 69: Anti-Theft Systems

    Anti-theft systems To stop the alarm using KEYLESS-GO: To switch off with KEYLESS-GO: unlock grasp the outside door handle. The key the vehicle using KEYLESS-GO. must be outside the vehicle. The alarm is switched off. Press the Start/Stop button on the dash- board.

  • Page 70: Interior Motion Sensor

    Anti-theft systems To switch off with KEYLESS-GO: unlock Interior motion sensor the vehicle using KEYLESS-GO. Function When the interior motion sensor is primed, a Press the Start/Stop button on the dash- visual and audible alarm is triggered if move- board. The key must be inside the vehicle. ment is detected in the vehicle interior.
  • Page 71 Useful information ......70 Key ............70 Doors ............ 76 Luggage compartment ....... 78 Side windows ........81 Sliding sunroof ........85...

  • Page 72: Useful Information

    Useful information attach any heavy or large key rings to the key that is inserted in the ignition. This Owner's Manual describes all mod- Do not keep the key: els, series and optional equipment for your with electronic devices, e.g. a mobile vehicle that were available at the time of phone or another key going to press.

  • Page 73: Locking

    The key centrally locks/unlocks: instance, and lock it using the & button on the key. the doors When locking or unlocking with KEYLESS-GO, the tailgate the distance between the key and the corre- the fuel filler flap sponding door handle must not be greater When unlocking, the turn signals flash once.
  • Page 74 the battery check lamp flashes twice There are several ways to turn off the alarm: page 73). To turn the alarm off with the key: press If the setting of the locking system is the % or & button on the key. changed within the signal range of the vehi- cle, pressing the &...

  • Page 75: Replacing

    Mercedes-Benz recommends that you have the batteries replaced at a qualified specialist workshop. Checking the battery Press emergency key element ; into the...
  • Page 76 Repeatedly tap the key against your palm until battery = falls out. Insert the new battery with the positive ter- minal facing upwards. Use a lint-free cloth to do so. Make sure that the surface of the battery is free from lint, grease and all other forms of contamination.

  • Page 77: Loss

    Problems with the key Problem Possible causes/consequences and M Solutions You cannot lock or The key battery is discharged or nearly discharged. unlock the vehicle Try again to lock/unlock the vehicle using the remote control using the key. function of the key. Point the tip of the key at the driver's door handle from close range and press the % or &...

  • Page 78: Important Safety Notes

    Doors Problem Possible causes/consequences and M Solutions You have lost the emer- Report the loss immediately to the vehicle insurers. gency key element. If necessary, have the locks changed as well. The engine cannot be The on-board voltage is too low. started using the key.

  • Page 79: Doors

    Doors Pull door handle ;. If the vehicle has been locked using the lock- ing button for the central locking, or has been If the door is locked, locking knob : pops locked automatically, and a door is opened up. The door is unlocked and can be from the inside: opened.
  • Page 80 Luggage compartment Press down the locking knob of the driver's door by reaching in through the open rear door. Make sure that you have the key on your person and that it has not been left in the vehicle. Close the rear door on the driver’s side. Make sure that the doors and the tailgate are locked.

  • Page 81: Luggage Compartment

    Luggage compartment open the tailgate manually from inside Pull the tailgate down using recess :. limit the opening angle of the tailgate Allow the tailgate to drop into the lock. Lock the vehicle if necessary with the & button on the key or with KEY- Opening/closing from the outside LESS-GO.
  • Page 82 Luggage compartment Closing the tailgate automatically ing procedure, press or pull the tailgate's remote operating button from the driver's seat again. The tailgate swings upwards and to the rear when opened. Therefore, make sure that there is sufficient clearance above and behind the tailgate.

  • Page 83: Side Windows

    Side windows To open the tailgate: pull the handle on Tailgate opening dimensions the tailgate. page 346). To stop the opening procedure at the To open desired position: press the closing button page 79) in the tailgate or pull the handle on the outside of the tailgate again.

  • Page 84: Hinged Side Windows

    Side windows Rear right the vehicle, even if you are only leaving it for a short time. Rear left Turn the key to position 1 or 2 in the ignition WARNING lock. Do not leave children unsupervised in the To open: press the corresponding switch. vehicle, even if they are secured in a child To close: pull the corresponding switch.

  • Page 85: Convenience Closing Feature

    Side windows Convenience opening feature Point the tip of the key at the driver's door handle. Press and hold the % button until the side windows and the sliding sunroof or the panorama sliding sunroof are in the desired position. If the roller sunblinds of the panorama slid- ing sunroof are closed, the roller sunblinds are opened first.

  • Page 86: Resetting

    Side windows When you lock the vehicle, you can simulta- ing sunroof or panorama sliding sunroof are neously: fully closed. Make sure that all the side windows and the close the side windows sliding sunroof or panorama sliding sunroof close the hinged side windows are closed.

  • Page 87: Sliding Sunroof

    Sliding sunroof Problems with the side windows WARNING Closing the side windows with increased force or without the anti-entrapment feature could lead to serious or even fatal injury. Make sure that nobody can become trapped when closing the side windows. Problem Possible causes/consequences and M Solutions A side window cannot...

  • Page 88: Sliding Sunroof

    Sliding sunroof To reduce or eliminate these noises: removing the key. This function remains active for five minutes or until the driver's change the position of the sliding sun- or front-passenger door is opened. roof. open a side window. Rain-closing feature open the panorama sliding sunroof to the The sliding sunroof closes automatically: comfort setting.

  • Page 89: Opening/Closing

    Sliding sunroof Rain-closing feature Keep the 2 switch pressed for another second. If the key is in position 0 in the ignition lock Make sure that the sliding sunroof can be or if it is removed, the panorama sliding sun- fully opened and closed again ( page 86).

  • Page 90: Resetting

    Sliding sunroof Opening and closing the roller sun- Keep the 2 switch pulled for an addi- blinds tional second. Pull the 2 switch repeatedly to the point of resistance in the direction of arrow = until the roller sunblinds are fully closed. Keep the 2 switch pulled for an addi- tional second.
  • Page 91 Sliding sunroof Problems with the sliding sunroof WARNING You could be severely or even fatally injured when closing the sliding sunroof with increased closing force or if the anti-entrapment feature is deactivated. Make sure that nobody can become trapped when closing the sliding sunroof. Your vehicle may be fitted with a sliding sunroof or a panorama sliding sunroof.
  • Page 93 Useful information ......92 Correct driver's seat position .... 92 Seats ............ 93 Steering wheel ........103 Mirrors ..........105 Memory function ......108...

  • Page 94: Useful Information

    Correct driver's seat position you can fasten the seat belt properly. Useful information you have moved the backrest to an almost vertical position. This Owner's Manual describes all mod- els, series and optional equipment for your you have set the seat angle so that your vehicle that were available at the time of thighs are gently supported.

  • Page 95: Seats

    Seats settings with the memory function head restraint. If your head is not supported page 108). correctly by the head restraint, you could suf- fer a severe neck injury in the event of an accident. Never drive if the head restraints are Seats not engaged and set correctly.
  • Page 96 Seats For more information, contact a qualified Adjusting the seats electrically specialist workshop. Further related subjects: Luggage compartment enlargement (folding down the 2nd and 3rd row of seats) ( page 250) Adjusting the seats manually and electrically Head restraint height Seat cushion angle Seat height Seat fore-and-aft adjustment...
  • Page 97 Seats Adjusting the head restraints electri- Adjusting the head restraints cally Adjusting the head restraints manually To adjust the head restraint height: slide the switch for head restraint adjustment Adjusting the head restraint height page 94) up or down in the direction of the arrow.
  • Page 98 Seats Rear seat head restraints The angle of the centre seat head restraint in the 2nd row of seats and the head restraints Adjusting the head restraint height (2nd in the 3rd row of seats cannot be adjusted. and 3rd row of seats) Removing and fitting the rear seat head restraints WARNING...
  • Page 99 Seats Rear seats (2nd and 3rd row) and the indicator area is barely visible (see the "EASY-ENTRY/EXIT feature for the 3rd row of Important safety notes seats" section). If the backrests are not locked in position: WARNING Never travel with the backrest reclined too far sharp braking back, as this can be dangerous.

  • Page 100: Adjusting The Armrest (2Nd Row Of Seats)

    Seats Adjusting the backrest angle Seat fore-and-aft adjustment (2nd row of seats) Outer seats, second row Seat fore-and-aft adjustment of the outer seats in the 2nd row is only possible for vehi- cles with a 3rd row of seats. Pull lever : in the direction of the arrow to the pressure point and hold it in this posi- tion.
  • Page 101 Seats Pull release loop : in the direction of the the outer seats in the 2nd row are locked arrow and hold it in this position. in position Fold backrest ; forwards until it is resting the outer seat backrests in the 2nd row of on seat cushion = in the armrest position.
  • Page 102 Seats Entry position If you wish to exit the 3rd row of seats, fold down the outer seat on the right-hand side as The release handle for the EASY-ENTRY fea- follows. ture is located on the entry side on the back The release loop for the EASY-EXIT feature is of each outer seat in the 2nd row of seats.
  • Page 103 Seats Moving the outer seats back to the normal Adjusting the multicontour seat position (2nd row of seats) Make sure that the key is in position 1 in Seat unlocked the ignition lock. When the seat is unlocked, lock status indi- Use switch ? to move the thigh cushion cator : is folded out and indicator area ;...
  • Page 104 Seats You can adjust the contour of the front seat The system automatically switches down backrests individually to provide optimum from level 2 to level 1 after approximately ten support for your back. minutes. The system automatically switches off approximately 35 minutes after it is set to Switching the seat heating on/off level 1.

  • Page 105: Steering Wheel

    Steering wheel Switching the seat ventilation on/off Steering wheel Switching on/off Important safety notes WARNING Do not adjust the steering wheel while driving. Adjusting the steering wheel while driving, or driving without the steering wheel adjustment feature locked could cause the driver to lose control of the vehicle.
  • Page 106 Steering wheel wheel up or down or try to move it in the Vehicles without KEYLESS-GO: when you fore-and-aft direction. remove the key from the ignition lock, the steering wheel heating is switched off. Vehicles with KEYLESS-GO: when you switch Adjusting the steering wheel electri- off the ignition and open the driver's door, the cally...

  • Page 107: Mirrors

    Mirrors The EASY-ENTRY/EXIT feature makes getting it easier to exit the vehicle and rescue the in and out of your vehicle easier. occupants. You can activate and deactivate the EASY- The crash-responsive EASY-EXIT feature is ENTRY/EXIT feature in the on-board com- only operational if the EASY-EXIT/ENTRY fea- puter ( page 206).
  • Page 108 Mirrors Make sure that the key is in position 1 or 2 in the ignition lock. Briefly press button :. Both exterior mirrors fold in or out. Make sure that the exterior mirrors are always folded out fully while driving. They could otherwise vibrate.

  • Page 109: Parking Position

    Mirrors folding the mirrors : until you hear a click Parking position of the exterior mirror and then the mirror engage in position. on the front-passenger side The mirror housing is engaged again and Setting and storing the parking position you can adjust the exterior mirrors as usual page 105).

  • Page 110: Memory Function

    Memory function Calling up a stored parking position set- trapped when adjusting the seat or the steer- ting ing wheel. With the memory function, you can store up to three different settings, e.g. for three dif- ferent people. The following settings are stored as a single memory preset: position of the seat, backrest and head restraint...
  • Page 111 Useful information ......110 Exterior lighting ........ 110 Interior lighting ......... 114 Replacing bulbs ......... 115 Windscreen wipers ......120...

  • Page 112: Useful Information

    ( page 23). Exterior lighting Important safety notes For reasons of safety, Mercedes-Benz recom- mends that you drive with the lights switched on even during the daytime. In some coun- tries, operation of the headlamps varies due Left-hand parking lamps...

  • Page 113: Exterior Lighting

    Exterior lighting The exterior lighting (except the side lamps/ When the dipped-beam headlamps are parking lamps) switches off automatically if switched on, the L indicator lamp in the you: instrument cluster lights up. remove the key from the ignition lock Automatic headlamp mode open the driver's door with the key in posi- tion 0...

  • Page 114: Adjusting The Headlamp Range

    Exterior lighting To switch on the foglamps: turn the key Pull the light switch out to the stop. in the ignition lock to position 2 or start the The yellow R indicator lamp on the light engine. switch lights up. Turn the light switch to L or T.

  • Page 115: Combination Switch

    Exterior lighting Combination switch Turn signals Headlamp range control (vehicles with steel sus- pension) Driver's seat occupied/driver's seat and front-passenger seat occupied Main-beam headlamps Driver's seat, front-passenger seat and all Turn signal, right rearmost seats occupied/all seats occu- Headlamp flasher pied Turn signal, left All seats occupied and luggage compart-...

  • Page 116: Interior Lighting

    Interior lighting Headlamp flasher Headlamps misted up on the inside To switch on: turn the key in the ignition The headlamps may mist up on the inside if lock to position 1 or 2, or start the engine. there is high atmospheric humidity. Pull the combination switch in the direction Switch on the lights and drive off.

  • Page 117: Replacing Bulbs

    Replacing bulbs The interior lighting automatically switches on if you: unlock the vehicle open a door remove the key from the ignition lock The interior lighting is activated for a short time when the key is removed from the igni- tion lock.

  • Page 118: Other Bulbs

    Replacing bulbs If your vehicle is equipped with xenon bulbs, If the new bulb still does not light up, consult you can recognise this by the following: the a qualified specialist workshop. cone of light from the xenon bulbs moves Bulbs and lamps are an important aspect of from the top to the bottom and back again vehicle safety.
  • Page 119 Replacing bulbs To remove: switch off the lights. Turn the front wheels inwards. Turn rotary catch : 90° anti-clockwise. Pull away the cover and lift it off. To fit: re-insert the cover. Turn rotary catch : 90° clockwise. Dipped-beam headlamps (halogen headlamps) Tail lamps Reversing lamp: W 16 W...

  • Page 120: Main-Beam Headlamps

    Replacing bulbs Main-beam headlamps (halogen head- Turn housing cover : anti-clockwise and lamps) pull it out. Pull out bulb holder ;. Take the bulb out of bulb holder ;. Insert the new bulb into bulb holder ;. Insert bulb holder ;. Align housing cover : and turn it clock- wise until it engages.

  • Page 121: Licence Plate Lighting

    Replacing bulbs Reversing lamp Replacing the rear bulbs Opening and closing the side trim pan- Reversing lamp Switch off the lights. Open the luggage compartment. Left-hand side trim panel Open the side trim panel ( page 119). Turn the bulb holder anti-clockwise and remove it.
  • Page 122 Windscreen wipers Windscreen wipers Switching the windscreen wipers on/ WARNING The windscreen will not longer be wiped prop- erly if the wiper blades are worn. This could prevent you from observing the traffic condi- tions, thereby causing an accident. Replace the wiper blades twice a year, ideally in spring and autumn.

  • Page 123: Windscreen Wipers

    Switching the rear window wiper on/ blade and it falls onto the windscreen, the windscreen may be damaged by the force of the impact. Mercedes-Benz recommends that you have the wiper blades changed at a qualified specialist workshop. To avoid damaging the windscreen wiper blades, make sure that you touch only the wiper arm of the windscreen wiper.
  • Page 124 Windscreen wipers Position new wiper blade : with Fitting the wiper blade recess B on lug A. Place new wiper blade ; onto wiper arm :. Fold wiper blade : in the direction of arrow = onto the wiper arm, until retaining Hold wiper arm : and press wiper clips ;...

  • Page 125: Climate Control

    Useful information ......124 Overview of climate control sys- tems ........... 124 Operating the climate control sys- tem ............. 128 Adjusting the air vents ..... 139...

  • Page 126: Useful Information

    Overview of climate control systems interval for replacing the filter, which is Useful information specified in the Service Booklet. As it depends on environmental conditions, e.g. This Owner's Manual describes all mod- heavy air pollution, the interval may be els, series and optional equipment for your shorter than stated in the Service Booklet.

  • Page 127: Overview Of Climate Control Systems

    Overview of climate control systems Control panel for THERMATIC automatic climate control (2-zone) Sets the temperature, left ( page 131) Sets climate control to automatic mode ( page 130) Demists the windscreen ( page 132) Increases the airflow ( page 132) Directs the airflow through the demister vents ( page 131) Switches cooling with air dehumidification on/off (...

  • Page 128: Matic Climate Control

    Overview of climate control systems Control panel for THERMOTRONIC automatic climate control (3-zone) Front control panel Sets the temperature, left ( page 131) Sets climate control to automatic ( page 130) Directs the airflow through the demister vents, left ( page 131) Demists the windscreen ( page 132)
  • Page 129 Overview of climate control systems Rear control panel Increases the airflow ( page 132) Sets the temperature ( page 131) Sets the rear-compartment climate control to automatic ( page 130) Directs the airflow through the rear air vents ( page 131) Directs the airflow through the footwell vents ( page 131) Switches rear-compartment climate control on/off (...

  • Page 130: Mate Control

    Operating the climate control system Display Reduces the airflow ( page 132) Activates/deactivates air-recirculation mode ( page 133) Directs the airflow through the centre and side air vents, left ( page 131) Directs the airflow to the footwell and side air vents, left ( page 131) Interior temperature sensor Switches the MONO function on/off (...

  • Page 131: Operating The Climate Control System

    Operating the climate control system Switching the front climate control on/ To switch off: press the Y button. off using the front control panel MODE appears in the display behind the Y symbol. Turn the key to position 2 in the ignition Press button ^.

  • Page 132: Indicator Lamp

    Operating the climate control system Controlling the front climate control is normal and not a sign that there is a mal- using the front control panel function. The cooling with air dehumidification Turn the key to position 2 in the ignition function uses refrigerant R134a.

  • Page 133: Setting The Air Distribution

    Operating the climate control system set. Automatic air distribution remains acti- and E clockwise or anti-clockwise vated. page 126). Only change the temperature setting in small increments. Start at 22 †. Press either M or O. Automatic air distribution is deactivated. To increase/reduce the temperature in Air distribution is controlled according to the rear compartment via the front con-...

  • Page 134: Demisting The Windscreen

    Operating the climate control system c Directs the airflow through the foot- Switching the MONO function on/off well and side air vents The MONO function is only available with O Directs the airflow through the foot- THERMOTRONIC automatic climate control well and side air vents You can use the MONO function to adopt the \ Directs the airflow through the centre...

  • Page 135: Culation Mode

    Operating the climate control system Press the à button. switches off automatically after several minutes. The indicator lamp in the ¬ button goes out. Airflow and air distribution are set to If the battery voltage is too low, the rear win- automatic mode.
  • Page 136 Operating the climate control system Turn the key to position 2 in the ignition and closed. If there is a risk of entrapment, lock. operate the 2 switch to move the pano- To activate: press the d button. rama sliding sunroof in the opposite direction. The indicator lamp in the d button lights Convenience closing feature: press and hold the d button until the side win-...

  • Page 137: Important Safety Notes

    Operating the climate control system will be activated. The blower runs at The auxiliary heating heats the air in the vehi- medium speed. cle interior to the set temperature without using the heat of the running engine. The aux- To deactivate: press the Á button. iliary heating is operated directly using the The indicator lamp in the Á...

  • Page 138: Remote Control

    Operating the climate control system Switching the auxiliary heating/venti- The remote control has a maximum range of lation on/off using the centre console approximately 300 metres. This range is button reduced by: sources of radio interference The colours of the indicator lamps on the but- ton have the following meanings: solid objects between the remote control and the vehicle...

  • Page 139: Heater Booster Function

    Operating the climate control system Heater booster function on vehicles Checking the status of the auxiliary heat- ing/ventilation with a diesel engine The heater booster function helps the engine reach its operating temperature faster during its warm-up phase as well as helps to heat the vehicle interior faster.
  • Page 140 Operating the climate control system One 6 V pin battery, type 2CR11108 is required. Prise apart the side arms of battery cover ; and pull off battery cover ;. Remove old battery :. Insert the new battery. Observe the polarity signs on the back of the remote control when doing so.

  • Page 141: Adjusting The Air Vents

    Adjusting the air vents Problems with the auxiliary heating/ventilation Display messages Possible causes/consequences and M Solutions The signal transmission between the transmitter and the vehicle is faulty. FAIL Change your position in relation to the vehicle, moving closer if necessary. Make another attempt to switch the auxiliary heating on or off using the remote control.

  • Page 142: Rear

    Adjusting the air vents Setting the centre air vents Setting the rear-compartment air vents Setting the centre vents in the rear com- partment : Centre air vent, left ; Centre air vent, right = Centre vent thumbwheel, right ? Centre vent thumbwheel, left Rear control panel, only with THERMOTRONIC automatic climate con- To open/close: turn thumbwheels =...
  • Page 143 Adjusting the air vents To open/close: turn thumbwheel ; to the left or right. Third row of seats Rear-compartment side air vent Rear-compartment side air vent Thumbwheel for rear-compartment side air vent To open/close: turn thumbwheel ; up or down.
  • Page 145 Useful information ......144 Running-in notes ....... 144 Driving ..........144 Automatic transmission ....150 Refuelling ........... 155 Parking ..........158 Driving tips ........160 Driving systems ........ 163 Towing a trailer ......... 184...

  • Page 146: Useful Information

    Driving After 1,500 km, you may gradually accelerate Useful information the vehicle to full road and engine speeds. This Owner's Manual describes all mod- You should also observe these notes on els, series and optional equipment for your running in if the engine or parts of the drive vehicle that were available at the time of train on your vehicle have been replaced.

  • Page 147: Start/Stop Button

    Driving KEYLESS-GO WARNING If the parking brake has not been fully General notes released when driving, the parking brake can: Do not keep the KEYLESS-GO key together overheat and cause a fire with: lose its hold function. with electronic devices, e.g. a mobile There is a risk of fire and an accident.

  • Page 148: Starting The Engine

    Driving Switching on the power supply When you insert Start/Stop button : into ignition lock ;, the system needs If Start/Stop button : has not yet been approximately two seconds recognition pressed, this corresponds to the key being time. You can then use Start/Stop but- removed from the ignition.

  • Page 149: Pulling Away

    Driving page 145) and release it as soon as the Pulling away engine is running. Automatic transmission To start a diesel engine: turn the key to position 2 in the ignition lock WARNING page 145). If the engine speed is above the idling speed The % preglow indicator lamp in the and you engage transmission position D or instrument cluster lights up.
  • Page 150 Driving Take your foot off the brake pedal. The vehicle is then held for about a second. Pull away. Hill start assist helps you when pulling away forwards or in reverse on an uphill gradient. It holds the vehicle for a short time after you have removed your foot from the brake pedal.
  • Page 151 Driving Problems with the engine Problem Possible causes/consequences and M Solutions The engine does not There is a malfunction in the engine electronics. start. The starter motor There is a malfunction in the fuel supply. can be heard. Before attempting to start the engine again, turn the key in the ignition back to position 0 or press the Start/Stop button repeatedly until all indicator lamps in the instrument cluster go out.

  • Page 152: Direct Select Lever

    Automatic transmission Problem Possible causes/consequences and M Solutions The coolant tempera- The coolant level is too low. The coolant is too hot and the engine ture display is showing is no longer being cooled sufficiently. more than 120 †. A Stop as soon as possible and allow the engine and the coolant warning tone will also to cool down.

  • Page 153: Automatic Transmission

    Automatic transmission In order to shift from park position P The DIRECT SELECT lever always returns directly into R or D: to its original position. The current trans- mission position P, R, N or D appears in the depress the brake pedal and transmission position display push the DIRECT SELECT lever up or page 151) in the multifunction display.

  • Page 154: Accelerator Pedal Position

    Automatic transmission Transmission positions Changing gear The automatic transmission shifts to the indi- Park position vidual gears automatically when it is in trans- This prevents the vehicle from roll- mission position D. Gearshifting is deter- ing away when stopped. Do not mined by: shift the transmission into position a shift range restriction, if selected...

  • Page 155: Automatic Drive Program

    Automatic transmission Program selector button Steering wheel gearshift paddles General notes Left-hand steering wheel gearshift paddle Right-hand steering wheel gearshift pad- Program selector button Press program selector button : repeat- You can restrict or derestrict the shift range edly until the letter for the desired gearshift by using the steering wheel gearshift paddles.

  • Page 156: Shift Ranges

    Automatic transmission the automatic transmission shifting up If the maximum engine speed for the shift later range is reached and you continue to accel- erate, the automatic transmission shifts up, as a result of the later automatic transmis- even if the shift range is restricted. sion shift points, the fuel consumption pos- sibly being higher Clearing the shift range restriction...

  • Page 157: Refuelling

    Refuelling Problems with the transmission Problem Possible causes/consequences and M Solutions The transmission has The transmission is losing oil. problems shifting gear. Have the transmission checked at a qualified specialist work- shop immediately. The acceleration ability The transmission is in emergency mode. is deteriorating.

  • Page 158: Fuel Filler Flap

    Refuelling Completely insert the filler neck of the fuel Refuelling pump nozzle into the tank and refuel. Opening/closing the fuel filler flap Only fill the tank until the pump nozzle switches off. Do not add any more fuel after the pump stops filling for the first time.
  • Page 159 Refuelling Problems with the fuel and fuel tank Problem Possible causes/consequences and M Solutions Fuel is leaking from the Risk of explosion or fire vehicle. The fuel line or the fuel tank is faulty. Turn the key to position 0 in the ignition lock immediately and remove it ( page 145).

  • Page 160: Parking

    Parking To ensure that the vehicle is secured against Parking rolling away unintentionally: Important safety notes the parking brake must be applied WARNING the transmission must be in position P and the key must be removed from the ignition If flammable materials such as leaves, grass lock or twigs are exposed to prolonged contact to parts of the exhaust system that heat up, they...

  • Page 161: Parking

    Parking If you shift the automatic transmission to When leaving the vehicle, always take the key N before switching off the engine, the auto- with you and lock the vehicle. Never leave matic transmission remains in N even if a children unsupervised in the vehicle.

  • Page 162: Driving Tips

    Driving tips Driving tips Brakes General notes Important safety notes Important safety notes WARNING If you shift down on a slippery road surface in WARNING an attempt to increase the engine's braking If you switch off the ignition while driving, effect, the drive wheels could lose their grip.

  • Page 163: Driving Tips

    This improves the grip of the which correspond to an equivalent quality brakes. standard. Brake pads/linings which have not been approved for Mercedes-Benz vehicles or Wet road surfaces which are not of an equivalent quality could affect your vehicle's operating safety.

  • Page 164: Aquaplaning

    Driving tips Driving on wet roads such as carbon monoxide (CO) may enter the vehicle. This is the case, e.g. if the vehicle Aquaplaning becomes trapped in snow. There is a risk of fatal injury. If water has accumulated to a certain depth on the road surface, there is a danger of aqua- If you leave the engine or the auxiliary heating planing occurring, even if:...

  • Page 165: Driving Systems

    Driving systems General notes Driving systems Cruise control maintains a constant road Cruise control speed for you. It brakes automatically in order Important safety notes to avoid exceeding the set speed. On long and steep downhill gradients, especially if the WARNING vehicle is laden or towing a trailer, you must Do not change down for additional engine...

  • Page 166: Activation Conditions

    Driving systems LIM indicator lamp ; on the cruise control Storing or calling up the speed lever indicates which function you have selec- WARNING ted: Only call up a stored speed if you know what LIM indicator lamp ; off: cruise control that speed is and if it is suitable for the current is selected.

  • Page 167: Deactivating

    Driving systems Deactivating cruise control WARNING SPEEDTRONIC is only an aid designed to There are several ways to deactivate cruise assist driving. You are responsible for the control: vehicle's speed and for braking in good time. Briefly press the cruise control lever for- wards 6.

  • Page 168: Variable Speedtronic

    Driving systems brake pedal repeatedly rather than continu- LIM indicator lamp ; on the cruise control ously. lever indicates which function you have selec- ted: You can set a variable or permanent limit speed: LIM indicator lamp ; off: cruise control variable for speed limits, e.g.

  • Page 169: Important Safety Notes

    Driving systems up : for a higher speed or down ? for a 160 km/h(e.g. for driving on winter tyres) and the maximum speed ( page 204). lower speed. Shortly before the stored speed is reached, it To adjust the set speed in 1 km/h incre- appears in the multifunction display.
  • Page 170 Driving systems DISTRONIC may not detect narrow vehicles vehicle's maximum braking power. You must driving in front, e.g. motorcycles, or vehicles also apply the brakes yourself if this braking driving on a different line. Therefore, always power is not sufficient. pay attention to traffic conditions even when If DISTRONIC detects a risk of collision with a DISTRONIC is activated.

  • Page 171: Selecting

    Driving systems Cruise control lever Switching on DISTRONIC, storing and maintaining the current speed Important safety notes WARNING The vehicle can be braked when Distronic is activated. For this reason, deactivate Dis- tronic if the vehicle is to be set in motion by other means (e.g.
  • Page 172 Driving systems Activating while driving Depending on the specified minimum dis- tance, your vehicle will come to a standstill Briefly pull the cruise control lever towards at a sufficient distance behind the vehicle you ? or press it up : or down A to the in front.
  • Page 173 Driving systems vehicle's speed to the last speed stored To increase: turn control ; in direction after you have finished overtaking. DISTRONIC then maintains a greater dis- Storing the current speed or calling up tance between your vehicle and the vehicle the last stored speed in front.

  • Page 174: Distronic

    Driving systems Display when DISTRONIC is deactivated There are several ways to deactivate DIS- TRONIC: Briefly press the cruise control lever for- wards :. Brake Briefly press the cruise control lever in the Vehicle in front, if detected direction of arrow =. Distance indicator, displaying current dis- Variable SPEEDTRONIC is selected.
  • Page 175 Driving systems Cornering, going into and coming out of a DISTRONIC has not yet detected the vehicle bend cutting in. The distance to this vehicle will be too short. Narrow vehicles The ability of DISTRONIC to detect vehicles when cornering is limited. Your vehicle may brake unexpectedly or late.

  • Page 176: Ads (Adaptive Damping System)

    Driving systems Crossing vehicles This depends on: your driving style the road surface conditions the ADS setting the vehicle level setting Your selection remains stored even if you remove the key from the ignition lock. DISTRONIC may detect vehicles that are crossing your lane by mistake.
  • Page 177 Driving systems The individual vehicle levels differ from high- Adapt your driving style to suit the vehicle way level as follows: ® level. ESP cannot reduce the risk of an acci- ® dent if you drive too fast. ESP cannot over- raised level: +50 mm ride the laws of physics.
  • Page 178 If indicator lamp ; is lit: Damage of this sort is not covered by the Press button :. Mercedes-Benz implied warranty. All Indicator lamp ; flashes. The vehicle is wheels must remain either on the ground lowered to highway level.

  • Page 179: Parktronic

    Driving systems mometer. Before you operate the vehicle PARKTRONIC monitors the area around your on such a dynamometer, please consult a vehicle using six sensors in the front bumper qualified workshop. You could otherwise and four sensors in the rear bumper. damage the drive train or the brake system.

  • Page 180: Warning Display

    Driving systems the minimum, the distance may no longer be shown. Warning displays Side view Warning display for the front area Segments on the left-hand side of the vehicle Segments on the right-hand side of the vehicle Segments showing operational readiness The warning displays show the distance Top view between the sensors and the obstacle.

  • Page 181: Deactivating/Activating

    Driving systems One or more segments light up as the vehicle approaches an obstacle, depending on the vehicle's distance from the obstacle. From the: sixth segment onwards, you will hear an intermittent warning tone for approx- imately two seconds. seventh segment onwards, you will hear a warning tone for approximately two sec- onds.

  • Page 182: Reversing Camera

    Driving systems Problems with PARKTRONIC Problem Possible causes/consequences and M Solutions Only the red segments PARKTRONIC has malfunctioned and has switched off. in the PARKTRONIC If problems persist, have PARKTRONIC checked at a qualified warning displays are lit. specialist workshop. You also hear a warning tone for approximately two seconds.
  • Page 183 Therefore, you should never pass the red line Mercedes-Benz recommends that you use when approaching an obstacle. You could oth- a Mercedes-Benz Service Centre for this erwise cause an accident and injure yourself purpose. and others.

  • Page 184: Blind Spot Assist

    Driving systems mirrors are yellow. Vehicles in the monitoring range are then not indicated. Always pay attention to traffic conditions and your surroundings. Otherwise, you may fail to recognise dangers in time, cause an accident and injure yourself and others. General notes Blind Spot Assist uses a radar sensor system to monitor the areas on both sides of your...

  • Page 185: Collision Warning

    Driving systems Indicator and warning display Yellow indicator lamp/red warning lamp If Blind Spot Assist is switched on, indicator lamp : in the exterior mirrors lights up yel- low up to a speed of 30 km/h. At speeds Blind Spot Assist monitors the area up to above 30 km/h, the indicator lamp goes out 3.0 m behind your vehicle and directly next to and Blind Spot Assist is operational.

  • Page 186: Towing A Trailer

    Towing a trailer Switching on Blind Spot Assist between the vehicle body and tyres, or under- neath the vehicle. This poses a risk of injury. Make sure that the radar sensor system When coupling up or uncoupling, make sure page 204) and Blind Spot Assist that no-one: page 207) are activated in the on-board computer.

  • Page 187: Towing A Trailer

    Towing a trailer The vehicle/trailer combination: WARNING is heavier If the ball coupling is not correctly engaged, the trailer can detach. There is a risk of an is restricted in its acceleration and gradi- accident. ent-climbing capability Always engage the ball coupling as described. has an increased braking distance is affected more by strong crosswinds Depressing the brake pedal constantly...

  • Page 188: Fitting The Ball Coupling

    Avoid braking abruptly. If possible, brake country. gently at first to allow the trailer to run on. For certain Mercedes-Benz vehicles, the max- Then, increase the braking force rapidly. imum permissible rear axle load is increased The values given for gradient-climbing when towing a trailer.
  • Page 189 Make a note of the ball coupling key num- ber. You can use this number to obtain a replacement key from a Mercedes-Benz Service Centre. Pull protective cap ; off the lock in the handwheel.

  • Page 190: Coupling Up A Trailer

    Towing a trailer Steel-sprung vehicles Make sure that the transmission is in posi- tion P. Engage the electric parking brake. Position the trailer level behind the vehicle. Couple up the trailer. Establish the electrical connection between the vehicle and the trailer. Check that the trailer lighting system is working.

  • Page 191: Removing

    Towing a trailer Vehicles with rear axle level control high-speed level even if you are travelling at higher speeds. Make sure that the transmission is in posi- This also applies when using accessories tion P. that are plugged into the socket of the Engage the parking brake.

  • Page 192: Storing

    Towing a trailer To switch the connected power supply Storing the ball coupling on or off: turn the key in the ignition lock WARNING to position 2 or 0 respectively Never transport an unsecured ball coupling in page 145). the interior of the vehicle. Otherwise, vehicle occupants could be Trailer with 7-pin connector injured by the ball coupling being thrown if...
  • Page 193 Towing a trailer Problems with trailer towing Problem Possible causes/consequences and M Solutions The ball coupling can- Risk of accident not be locked. The ball coupling is dirty. The key cannot be The trailer tow hitch is damaged. removed from the ball Remove the ball coupling and clean it ( page 287).
  • Page 195 Useful information ......194 Important safety notes ....194 Displays and operation ....194 Menus and submenus ...... 196 Display messages ......210 Warning and indicator lamps in the instrument cluster ......233...

  • Page 196: Useful Information

    Displays and operation Useful information WARNING The operating safety of your vehicle could be This Owner's Manual describes all mod- impaired if maintenance work is carried out els, series and optional equipment for your incorrectly. This could cause you to lose con- vehicle that were available at the time of trol of your vehicle and cause an accident.

  • Page 197: Displays And Operation

    Displays and operation Outside temperature display Operating the on-board computer Overview WARNING At temperatures just above freezing point, the street may be icy, especially in wooded areas or on bridges. If you do not adapt your driving style to the conditions, the vehicle could skid. For this reason, adapt your driving style and speed to the weather conditions.

  • Page 198: Multifunction Display

    Menus and submenus Multifunction display Set‐ Selects submenus in the tings menu Changes values Adjusts the volume Switches on LINGUATRONIC; see the separate operating instructions Right control panel Selects a menu: scrolls back- Description field ward and forward Transmission position ( page 151) Press briefly: &...

  • Page 199: Menus And Submenus

    Menus and submenus Depending on the audio system fitted, the Press the V or U button on the steer- display messages in the Audio, Navigation ing wheel to select the standard display. and Telephone menus differ slightly. The Press the & or * button to select the examples given in this Owner's Manual apply coolant temperature.

  • Page 200: Audio Menu

    Menus and submenus Audio player or audio media operation Audio menu Selecting a radio station Example: CD/DVD changer display Current CD in the CD/DVD changer Waveband Current track Channel frequency with memory position Audio data from various audio devices or Station ;...

  • Page 201: Airmatic/Compass Menu

    Menus and submenus Route guidance not active To select a stored station: briefly press the & or * button. To select a station from the station list: press and briefly hold the & or * button. To select a station using station search : press and briefly hold the &...

  • Page 202: Settings

    Menus and submenus compass menu depends on the optional Press the . reset button again. equipment in your vehicle. The settings of most functions are restored to the factory settings. Settings menu If you want to retain the settings, do not press the .

  • Page 203: Selecting The Language

    Menus and submenus The selected unit of measurement for dis- Selecting the status line display tance applies to: Vehicles for the United Kingdom: this func- tion is not available. analogue speedometers Press the V or U button on the steer- total distance recorder and the trip meter Settings ing wheel to select the...

  • Page 204: Activating/Deactivating The Exte Rior Lighting Delayed Switch-Off

    Menus and submenus Daytime driving To set the time: press the & button to Press & to select Clock, set hour Clock, set lamps. select minute. Press W or X to set daytime driving or Off. lights to To set the date: press & to select Press the &, V or U button to Date, Set day,...

  • Page 205: Interior Lighting

    Menus and submenus If the engine is switched off and no doors are Press the V or U button on the steer- opened, or if an open door is not closed, the Settings ing wheel to select the menu. exterior lighting goes out after 60seconds. Press the &...
  • Page 206 Menus and submenus Setting permanent SPEEDTRONIC Activating/deactivating the acoustic locking confirmation Press the V or U button on the steer- Acoustic Lock feed‐ Settings If you switch on the ing wheel to select the menu. back: function, an acoustic signal sounds Press the &...

  • Page 207: Setting

    Menus and submenus Heating You can switch off the auxiliary heating by using the remote control or the auxiliary heat- Auxiliary heating departure time ing button on the centre console. WARNING Switch the auxiliary heating on regularly Exhaust fumes are produced when the auxili- once a month for about ten minutes.

  • Page 208: Activating/Deactivating

    Menus and submenus Depar‐ Press the & button to select Press the W or X button to activate ture time X Set hour. EASY-ENTRY system. or deactivate the Press the &, V or U button to Press the W or X button to set the hour.

  • Page 209: Trip Computer Menu

    Menus and submenus Fold in Priming/deactivating tow-away protec- Press the & button to select tion mirrors when locking. Press the W or X button to activate Tow-away protection, If you deactivate Fold in mirrors when or deactivate the tow-away protection ( page 67) will not be locking feature.

  • Page 210: Calling Up The Range

    Menus and submenus the fuel tank, the display shows a vehicle Average speed being refuelled C instead of the range. Average fuel consumption Press the V or U button on the steer- Displaying the current fuel consump- ing wheel to select the trip computer tion menu.

  • Page 211: Number From The Phone Book

    Bluetooth from any Mercedes Benz Service Centre To exit the telephone book: press ~. on the Internet at: http:// www.mercedes-benz.com/connect Redialling The on-board computer saves the last names Accepting a call or numbers dialled in the redial memory.

  • Page 212: Display Messages

    Display messages Display messages Introduction General notes Display messages appear in the multifunction display. Display messages with graphic symbols are simplified in the Owner's Manual and may differ from the symbols in the multifunction display. Please respond in accordance with the display messages and follow the additional notes in this Owner's Manual.

  • Page 213: Display Message

    Display messages Safety systems Display messages Possible causes/consequences and M Solutions !÷ ® ABS (Anti-lock Braking System), ESP (Electronic Stability Pro- ® ® gram), BAS (Brake Assist), PRE-SAFE , hill start assist and ESP unavailable See trailer stabilisation are temporarily not available. Owner's Manual The adaptive brake lights may also have failed.
  • Page 214 Display messages Display messages Possible causes/consequences and M Solutions ® ® If ESP is not operational, ESP is unable to stabilise the vehicle. The danger of skidding and having an accident increases. Drive on carefully. Visit a qualified specialist workshop immediately. ÷...
  • Page 215 Display messages Display messages Possible causes/consequences and M Solutions If the display message is shown while the vehicle is in motion and the ÷ warning lamp flashes, the electronic traction system is deactivated. Otherwise, the brakes on the drive wheels could overheat.

  • Page 216: Lights

    Display messages Display messages Possible causes/consequences and M Solutions You are driving with the parking brake applied. A warning tone also sounds. Release parking Release the parking brake. brake There is insufficient brake fluid in the brake fluid reservoir. In addi- tion, the J warning lamp in the instrument cluster lights up and Check brake fluid a warning tone sounds.
  • Page 217 Display messages Display messages Possible causes/consequences and M Solutions The left or right-hand dipped-beam headlamp is faulty. Check whether you are permitted to replace the bulb yourself Left-hand dipped page 116). beamorRight-hand dipped beam Visit a qualified specialist workshop. The left or right-hand trailer tail lamp is faulty. Check whether you are permitted to replace the bulb yourself.
  • Page 218 Display messages Display messages Possible causes/consequences and M Solutions The third brake lamp is faulty. Check whether you are permitted to replace the bulb yourself 3rd brake lamp page 116). Visit a qualified specialist workshop. The left or right-hand brake lamp is faulty. Check whether you are permitted to replace the bulb yourself Left-hand brake page 116).
  • Page 219 Display messages Display messages Possible causes/consequences and M Solutions The left or right-hand reversing lamp is faulty. Check whether you are permitted to replace the bulb yourself Reversing lamp, page 116). leftorReversing lamp, right Visit a qualified specialist workshop. The left or right-hand tail lamp is faulty. Check whether you are permitted to replace the bulb yourself Left-hand tail page 116).

  • Page 220: Display Message

    Display messages Engine Display messages Possible causes/consequences and M Solutions The coolant level is too low. Avoid making long journeys with too little coolant in the engine Top up coolant See cooling system. The engine will otherwise be damaged. Owner's Manual Top up the coolant, observing the warning notes before doing so ( page 281).
  • Page 221 Display messages Display messages Possible causes/consequences and M Solutions The battery is not being charged. A warning tone also sounds. Possible causes: faulty alternator torn poly-V-belt a malfunction in the electronics Stop the vehicle immediately, paying attention to road and traf- fic conditions, and switch off the engine.
  • Page 222 Display messages Display messages Possible causes/consequences and M Solutions There is only a very small amount of fuel in the fuel tank. The auxiliary heating cannot be operated. Refuel at the nearest filling station without fail. Vehicles with a diesel engine: the engine air filter is dirty and must ¸...

  • Page 223: Driving Systems

    Display messages Driving systems Display messages Possible causes/consequences and M Solutions The vehicle level is too low when the vehicle is stationary. ° Do not pull away. Vehicle rising The vehicle level is set when the display message disappears. Wait briefly You have pulled away while the vehicle level is still too low, or the °...
  • Page 224 Display messages Display messages Possible causes/consequences and M Solutions ° Rear axle level control or AIRMATIC is malfunctioning. Vehicles with rear axle level control: do not exceed 80 km/h. Malfunction Vehicles with AIRMATIC: drive as appropriate for the current vehicle level, but do not exceed 80 km/h. Make sure that there is sufficient ground clearance.
  • Page 225 Display messages Display messages Possible causes/consequences and M Solutions Blind Spot Assist is temporarily inoperative. Possible causes: the sensors are dirty. the function is impaired due to heavy rain or snow. the radar sensor system is outside the operating temperature range.

  • Page 226: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions 120 km/h! Only for certain countries: the maximum speed has been excee- ded. Maximum speed exceeded km/h!. In addition, the multifunction display shows Drive more slowly. DISTRONIC An activation condition for DISTRONIC is not fulfilled. --- km/h Check the activation conditions for DISTRONIC ( page 167).

  • Page 227: Tyres

    Display messages Tyres Display messages Possible causes/consequences and M Solutions Tyre pressure The tyre pressure loss warning system has detected a significant Check tyres loss in pressure. A warning tone also sounds. WARNING With tyre pressures which are too low, there is a risk of the fol- lowing hazards: they may burst, especially as the load and vehicle speed increase.
  • Page 228 Display messages Display messages Possible causes/consequences and M Solutions Tyre press. moni‐ The wheels fitted do not have a suitable tyre pressure sensor. The tor inoperative No tyre pressure monitor is deactivated. wheel sensors Fit wheels with suitable tyre pressure sensors. The tyre pressure monitor is activated automatically after driv- ing for a few minutes.
  • Page 229 Display messages Display messages Possible causes/consequences and M Solutions Caution, tyre The tyre pressure in one or more tyres has dropped suddenly. The defect wheel position is displayed in the multifunction display. WARNING If you drive with a flat tyre, there is a risk of the following hazards: A flat tyre affects the ability to steer or brake the vehicle.
  • Page 230 Display messages Display messages Possible causes/consequences and M Solutions The tyre pressure in one or more tyres has dropped suddenly. A warning tone also sounds. Tyre pressure Cau‐ tion, tyre malf. WARNING If you drive with a flat tyre, there is a risk of the following hazards: A flat tyre affects the ability to steer or brake the vehicle.
  • Page 231 Display messages Vehicle Display messages Possible causes/consequences and M Solutions To start the You have attempted to start the engine with the transmission in engine, shift to position R or D. either P or N Shift the transmission to position P or N. Auxiliary battery The auxiliary battery for the automatic transmission is no longer malfunction...

  • Page 232: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions Compass The compass is malfunctioning due to external interference. As soon as the source of the interference has been removed: Turn the key to position 0 in the ignition lock and remove it. Wait until the trip meter is no longer shown in the multifunction display.

  • Page 233: Display Message

    Display messages Display messages Possible causes/consequences and M Solutions The on-board voltage is too low. The auxiliary heating has switched & itself off or cannot be switched on ( page 135). inoperative Bat‐ Drive for a longer distance. tery weak The battery is being charged.

  • Page 234: Keyless-Go

    Display messages Display messages Possible causes/consequences and M Solutions You have put the wrong key in the ignition lock. Use the correct key. Key does not belong to vehicle The key needs to be replaced. Visit a qualified specialist workshop. You need a new key The batteries of the KEYLESS-GO key are discharged.

  • Page 235: Warning And Indicator Lamps In The Instrument Cluster

    Warning and indicator lamps in the instrument cluster Display messages Possible causes/consequences and M Solutions The KEYLESS-GO key has been detected inside the vehicle during locking. Key detected in Remove the KEYLESS-GO key from the vehicle. vehicle The KEYLESS-GO key is not continually detected. Insert the key into the ignition lock and turn it to the desired Pull starting but‐...
  • Page 236 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions The driver or front passenger has not fastened their seat belt. At ü the same time, you are driving faster than 25 km/h or have briefly The red seat belt warn- driven faster than 25 km/h.

  • Page 237: Warning Lamp

    Warning and indicator lamps in the instrument cluster Safety systems Problem Possible causes/consequences and M Solutions There is insufficient brake fluid in the fluid reservoir. The red brake system WARNING warning lamp comes on The braking efficiency may be impaired. while the engine is run- There is a risk of an accident.
  • Page 238 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions ® ABS is temporarily unavailable. BAS, ESP , EBD (electronic brake ® force distribution), PRE-SAFE , the adaptive brake lights and The yellow ABS warning lamp is lit while the ®...

  • Page 239: Warning Lamp

    Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions ® EBD is faulty. Therefore, ABS, BAS, PRE-SAFE , hill start assist, ® the adaptive brake lights and ESP trailer stabilisation, for exam- The yellow ABS warning ple, are not available either.
  • Page 240 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions ® ÷ or traction control has intervened because there is a risk of skidding or at least one wheel has started to spin. ® The yellow ESP warn- ing lamp flashes while Cruise control or DISTRONIC is deactivated.
  • Page 241 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions ® ® ÷å , BAS, PRE-SAFE , hill start assist, the adaptive brake lights ® and ESP trailer stabilisation are not available due to a malfunc- ®...
  • Page 242 Warning and indicator lamps in the instrument cluster Problem Possible causes/consequences and M Solutions You are driving with the parking brake applied. The red brake system Release the parking brake. warning lamp comes on The warning lamp goes out and the warning tone ceases. while the vehicle is moving.

  • Page 243: Fuel Tank

    Warning and indicator lamps in the instrument cluster Engine Problem Possible causes/consequences and M Solutions There may be a fault, for example: The yellow engine diag- in the engine management nostics warning lamp in the fuel injection system lights up while the in the exhaust system engine is running.

  • Page 244: Warning Lamp

    Warning and indicator lamps in the instrument cluster Driving systems Problem Possible causes/consequences and M Solutions The distance to the vehicle in front is too small for the speed · selected. The red distance warn- ing function warning Increase the distance. lamp comes on while the vehicle is moving.

  • Page 245: Warning Lamp

    Warning and indicator lamps in the instrument cluster Tyres Problem Possible causes/consequences and M Solutions The tyre pressure monitor has detected a loss of pressure in at least one of the tyres. The yellow tyre pres- sure monitor warning WARNING lamp is on.
  • Page 247 Useful information ......246 Stowage areas ........246 Features ..........260...

  • Page 248: Loading Guidelines

    Stowage areas or the permissible axle loads for the vehicle Useful information (including occupants). position heavy loads as far forwards as pos- This Owner's Manual describes all mod- sible and as low down in the load compart- els, series and optional equipment for your ment as possible.

  • Page 249: Glove Compartment

    Stowage areas Glove compartment Stowage compartments under the arm- rest To open: pull handle : and open glove compartment flap ;. To close: fold glove compartment flap ; upwards until it engages. Depending on the vehicle's equipment, you will find an AUX-IN jack or a Media Interface installed in the glove compart- ment.

  • Page 250: Centre Console

    Stowage areas Stowage compartments in the centre Stowage compartments above the console centre air vents, 2nd row of seats Front stowage compartment Depending on the equipment in the vehicle, a control panel may be installed instead of the Briefly press trim ; in the direction of the upper stowage compartment, e.g.

  • Page 251: Nd Row Of Seats

    Stowage areas Stowage compartments in the 3rd row brake sharply of seats change direction suddenly are involved in an accident Stowage compartment There is a stowage compartment in the side trim on both sides. In vehicles with rear-com- partment air conditioning (2nd and 3rd row of seats), a swivelling side air vent is installed instead of the stowage compartment.

  • Page 252: Important Safety Notes

    Stowage areas B engage in securing rings : (position 1) At the same time, reach into recess ;. or ; (position 0). Lift centre console : by recess ; upwards in the direction of the arrow to The stowage compartment and cup release centre console : from anchoring holder will only be illuminated if the centre points =.

  • Page 253: Partial

    Stowage areas Partially enlarging the luggage com- Fully enlarging the luggage compart- partment (folding the seats in the 3rd ment (folding the seats in the 2nd and row forward) 3rd rows forward) Move the head restraint of the correspond- Important safety notes ing seat down fully ( page 96).

  • Page 254: Completely

    Stowage areas Lower the head restraint on the centre seat in the 2nd row of seats fully ( page 96). Luggage compartment floor position Folding down the outer seats in the 2nd row of seats Pull release loop : in the direction of the If you want to fold the outer seats down arrow.
  • Page 255 Stowage areas Place the head restraints on the seat cush- Clamp the seat belt behind retainer ;. ion of the corresponding seat. Pull release handle : of backrest = Relieve the pressure on backrest : and upwards in the direction of the arrow. pull release lever ;...
  • Page 256 Stowage areas Moving the seats back into the driving Grip loop = and pull seat backrest ; into position an upright position. Pull release handle ? and move back- Important safety notes rest ; to the desired position. WARNING Place seat cushion : in a vertical position. Ensure that the seats are locked and the Fold seat cushion : towards backrest ;...

  • Page 257: Lashing Eyelets

    Stowage areas When the seat is unlocked, lock status indi- Securing a load cator : is folded out and indicator area ; Lashing eyelets is clearly visible. When the seat is unlocked, fold the back- General notes rest back until you hear the seat engage. WARNING Distribute the load on the lashing eyelets evenly.

  • Page 258: Securing Hooks

    Stowage areas Footwell of the 3rd row of seats Luggage compartment cover Important safety notes WARNING The luggage compartment cover is not a restraint system. Secure the load under the luggage compartment cover by suitable means. Make sure that the luggage compart- ment cover is engaged securely.
  • Page 259 Stowage areas To extend: pull the luggage compartment partment cover ; behind the 2nd row of cover back by grab handle : and clip it seats ( page 258). into retainers ; on the left and right. If fitted, remove the protective caps from the side panels of the 3rd row of seats if To retract: unhook the luggage compart- you wish to install luggage compartment...
  • Page 260 Stowage areas Extending the luggage compartment Safety net cover Important safety notes WARNING You must make sure that the safety net is correctly secured at the top and bottom. Do not use a damaged safety net. The safety net cannot restrain heavy loads. For this reason, you should always secure the load.

  • Page 261: Roof Carrier

    Stowage areas Releasing the safety net The corresponding lashing eyelets to tighten the net are located in the footwell of the 3rd row of seats ( page 255). Attaching the safety net Seat belt reel holder behind the front seats Pull belt adjuster : upwards in the direc- tion of the arrow to reduce the tension on the tensioning strap.

  • Page 262: Important Safety Notes

    Mercedes-Benz recommends that you only use roof carriers that have been tested WARNING and approved for Mercedes-Benz vehicles. Keep the cup holder closed while the vehicle This helps to prevent damage to the vehi- is in motion. Otherwise, vehicle occupants cle.

  • Page 263: Second Row Of Seats

    Features Drink containers placed in the cup holder on the driver's side can be secured so that they are held firmly in the cup holder. To secure a drink container: place a drink container in the cup holder on the driver's side.

  • Page 264: Third Row Of Seats

    Features Cup holder in front of the armrest of the second row of seats Mirror light Bracket Vanity mirror Cup holders Retaining clip, e.g. for a car park ticket Cup holder in the third row of seats Mirror cover Vanity mirror in the sun visor Mirror light : only functions if the sun visor is clipped into retainer ;...

  • Page 265: Ashtray

    Features Sunblinds on the rear side windows Always guide the roller sunblind by hand. Do not let it snap back suddenly as this would damage the automatic roller mech- anism. Do not drive the vehicle with the roller sunblind hooked in and the side windows opened simultaneously.

  • Page 266: Cigarette Lighter

    Features To remove the insert: press insert : in Turn the key to position 2 in the ignition lock. the direction of the arrow. To open: open cover : ( page 248). Pull insert : upwards and remove it. Press in cigarette lighter ;. To refit the insert: replace insert : into Cigarette lighter ;...

  • Page 267: Nd Row Of Seats

    Features Socket in the front centre console Socket in the luggage compartment If accessories are connected, make sure The socket is not intended for operating that a maximum current draw of 15 A is not the tyre inflation compressor. exceeded. Otherwise, you will overload the fuse.
  • Page 268 247). electromagnetic fields. Place the mobile phone bracket into the Mercedes-Benz recommends the use of an pre-installed fitting (see the separate approved exterior aerial. This ensures: installation instructions for the mobile phone fitting).

  • Page 269: Important Safety Notes

    Features Garage door remote control A is not part of Garage door opener the integrated garage door opener. Important safety notes Before programming for the first time, clear ® the memory of the integrated garage door The HomeLink garage door opener integra- opener ( page 269).
  • Page 270 Features gramming, you must synchronise the 30 cm or at the same angle but at varying garage door opener integrated in the rear- distances. view mirror with the receiver of the garage If there is another remote control for the door system.

  • Page 271: Garage Door Opener

    Features Clearing the memory Country Radio type approval num- Turn the key to position 2 in the ignition lock. Frequency range (MHz) Press buttons ; and ?. CZ (Czech General Licence GL-30/R/ The indicator lamp lights up yellow. Republic) 2000 Reg. No. 844 13 May Press and hold buttons ;...
  • Page 272 Features Country Radio type approval num- Country Radio type approval num- Frequency range (MHz) Frequency range (MHz) GR (Greece) Article 6 of Directive IT (Italy) DGPGSR/II/347487/ 1999/5/EC FOR/15347 R&TTE11409/18/4/2005 DGPGSR/II/347487/ 18 May 05 FOR/15348 MHz: 27, 40, 433, 868 DGPGSR/II/347487/ FOR/15350 HR (Croatia) SDR 224/06 DGPGSR/II/347487/...
  • Page 273 Features Country Radio type approval num- Country Radio type approval num- Frequency range (MHz) Frequency range (MHz) MT (Malta) Article 6 of Directive SK (Slova- Article 6 of Directive 1999/5/EC R&TTE 18 May kia) 1999/5/EC R&TTE Slovak MHz: 27, 40, 433, 868 206/11/2005 4 May 05 MHz: 27, 40, 433, 868 NL (Nether-...
  • Page 274 Features Australia Country Radio type approval num- Country Radio type approval num- Frequency range (MHz) Frequency range (MHz) GP (Guade- Article 6 of Directive loupe) 1999/5/EC R&TTE10668 AU (Aus- 28 June 13 May 05 tralia) MHz: 27, 30, 40, 433, 868 MHz: 27, 30, 40, 433, 868 NZ (New 20 March 06...

  • Page 275: Setting

    Features Setting the compass Zone map Use the zone map to determine your geographical location. Vehicle Use W or X on the multifunction steering wheel to select the submenu. Compass setting Zone Keep pressing & or * until the message appears. The selection marker highlights the current setting.

  • Page 276: Floormat

    Features Please drive a full circle. Drive the vehicle in a full circle at approx- imately 5 – 10 km/h. When the calibration is completed, you will Compass calibration Comple‐ see the ted successfully message in the multi- function display. Compass calibration If you do not see the Completed successfully...

  • Page 277: Anti-Glare Film

    Features Retrofitted anti-glare film Retrofitted anti-glare film on the inside of the windows can interfere with radio/mobile telephone reception. This is particularly the case for conductive or metallic-coated films. You can obtain information about anti-glare film from a qualified specialist workshop.
  • Page 279 Useful information ......278 Engine compartment ......278 Service ..........282 Care ............ 283...

  • Page 280: Useful Information

    Engine compartment Useful information Vehicles with a petrol engine: The elec- tronic ignition system uses high voltage. For This Owner's Manual describes all mod- this reason, you must never touch ignition els, series and optional equipment for your system components (ignition coil, ignition vehicle that were available at the time of cables, spark plug connectors or test socket) going to press.

  • Page 281: Engine Compartment

    Engine compartment Radiator Vehicles with a diesel engine: do not cover the radiator. Do not use thermal mats, insect protection covers or anything similar. Doing so can cause the Onboard Diagnostics Sys- tem to display inaccurate values. Some of these values are legally required and must always be correct.

  • Page 282: Dipstick

    You can obtain a list of the engine oils and oil filters tested and approved in accordance with the Mercedes-Benz Specifications for Service Products at any Mercedes-Benz Service Centre. Example: vehicles with a petrol engine Damage to the engine or exhaust system is...

  • Page 283: Topping Up

    Engine compartment Replace cap : on the filler neck and turn Slowly turn cap : half a turn anti-clock- clockwise. wise to allow excess pressure to escape. Make sure that the cap locks securely into Turn cap : further anti-clockwise and place.

  • Page 284: Service

    A qualified specialist workshop, e.g. a Mercedes-Benz Service Centre, will reset the ASSYST PLUS service interval display after the service work has been carried out. You can also obtain further information on main-...

  • Page 285: Care

    Before a longer stay and check the wheels often. Further informa- outside of Europe, consult a qualified special- tion can be obtained at a qualified specialist ist workshop. workshop, e.g. a Mercedes-Benz Service ® Centre. Observe the notes on AdBlue page 342).

  • Page 286: Automatic Car Wash

    Use care products and cleaning agents rec- Turn the key to position 2 ( page 145) in ommended and approved by Mercedes-Benz. the ignition lock. Use the key instead of the Start/Stop but- ton on vehicles with KEYLESS-GO.

  • Page 287: High-Pressure Cleaner

    Care Cleaning the paintwork Use plenty of water and rinse out the sponge frequently. Do not affix: Rinse the vehicle with clean water and dry stickers thoroughly with a chamois. films Do not let the cleaning agent dry on the magnetic plates or similar items paintwork.

  • Page 288: Wheels

    Use only insect remover and car shampoo to electronic components. from the range of recommended and Clean the inside and outside of the win- approved Mercedes-Benz care products. dows with a damp cloth and a cleaning agent that is recommended and approved by Mercedes-Benz.

  • Page 289: Exterior Lighting

    Clean the plastic lenses of the exterior lighting using a wet sponge and a mild Clean sensors : of the driving systems cleaning agent, e.g. Mercedes-Benz car with water, car shampoo and a soft cloth. shampoo or cleaning cloths. Cleaning the exhaust pipe...

  • Page 290: Display

    Interior care Heavy soiling: use car care and cleaning products recommended and approved by Cleaning the display Mercedes-Benz. For cleaning, do not use any of the fol- The surface may change colour tempora- lowing: rily. Wait until the surface is dry again.

  • Page 291: Carpets

    DINAMICA leather care agents that have been recom- covers. If used often, these can damage the mended and approved by Mercedes-Benz. cover. Cleaning wooden trim and trim ele- Note that regular care is essential to...
  • Page 293 Useful information ......292 Where will I find...? ......292 Flat tyre ..........295 Battery (vehicle) ........ 301 Jump-starting ........304 Towing and tow-starting ....306 Electrical fuses ......... 309...

  • Page 294: Useful Information

    Where will I find...? Open the tailgate. Useful information Lift the luggage compartment floor up page 293). This Owner's Manual describes all mod- els, series and optional equipment for your Vehicles with a TIREFIT kit: remove warn- vehicle that were available at the time of ing triangle going to press.

  • Page 295: Where Will I Find

    Where will I find...? may differ slightly from that shown in the information on which tools are required to example illustration. perform a wheel change on your vehicle, consult a qualified specialist workshop. Open the tailgate. Necessary wheel-changing tools can Lift the luggage compartment floor up include, for example: page 293).
  • Page 296 Where will I find...? Vehicles with BlueTEC Attach hook = to the luggage compart- Tyre inflation compressor ment's upper seal ?. First-aid kit Ball coupling of the trailer tow hitch Vehicles with a TIREFIT kit Tyre sealant filler bottle Towing eye Centring pin Jack Warning triangle...

  • Page 297: Flat Tyre

    Flat tyre Vehicles with KEYLESS-GO: open the Instructions on the installation position of driver's door. the vehicle tool kit holder The on-board electronics have status 0, Fuse allocation chart which is the same as the key having been Jack, ratchet ring spanner removed.

  • Page 298: Tirefit Kit

    Flat tyre Vehicles with MOExtended tyres are not holes, off-road). This applies in particular to a equipped with a TIREFIT kit at the factory. laden vehicle. It is therefore recommended that you addi- Stop driving in emergency mode if: tionally equip your vehicle with a TIREFIT kit you hear banging noises.
  • Page 299 Flat tyre Insert plug ? into a 12 V socket of the cig- If tyre sealant is swallowed, immediately arette lighter in your vehicle. rinse your mouth out thoroughly and drink plenty of water. Do not induce vomiting, Observe the notes on sockets and seek medical attention immediately.
  • Page 300 Flat tyre Make sure pressure release screw F on pressure gauge G is fully closed. Screw filler hose D onto valve E. Insert plug A into the socket in the foot- well of the second row of seats page 265). Turn the key to position 1( page 145) in the ignition lock.
  • Page 301 Flat tyre First, tyre sealant is pumped into the tyre. The pressure can briefly rise to approx- imately 500 kPa (5 bar/73 psi). Do not switch off the tyre inflation com- pressor during this phase. Let the tyre inflation compressor run for five minutes.
  • Page 302 Flat tyre Tyre pressure reached icantly impair the vehicle's braking and driv- ing characteristics. There is a risk of accident. WARNING Do not continue driving. Contact a qualified A tyre temporarily sealed with tyre sealant specialist workshop. impairs the driving characteristics and is not suitable for higher speeds.

  • Page 303: Important Safety Notes

    If ABS malfunctions, the wheels can lock during braking. This limits the steerability WARNING of the vehicle when braking and the braking For safety reasons, Mercedes-Benz recom- distance may increase. There is a risk of mends that you only use batteries which have accident.
  • Page 304 You can also charge the battery with a environmentally responsible charger recommended by Mercedes-Benz. recycling system. For more information, please contact a quali- Dispose of batteries in an fied specialist workshop.

  • Page 305: Battery (Vehicle)

    Only charge the installed battery with a battery charger which has been tested and approved by Mercedes-Benz. These battery chargers allow the battery to be charged while still installed in the vehicle. Only use battery chargers with a maxi- mum charging voltage of 14.8 V.

  • Page 306: Jump-Starting

    Jump-starting Jump-starting WARNING There is a risk of acid burns when jump-starting a vehicle due to the gases which escape from the battery. Do not lean over the battery while the engine is being jump-started. WARNING Gases escaping from the battery during jump-starting may cause minor explosions. Avoid cre- ating sparks.
  • Page 307 Jump-starting Position number C identifies the charged battery of the other vehicle or an equivalent jump- starting device. Lift up cover : of positive terminal ; in the direction of the arrow. Connect positive terminal ; on your vehicle to positive terminal = of donor battery C using the jump lead.

  • Page 308: Function

    Towing and tow-starting Do not use the towing eye for recovery, Towing and tow-starting this could damage the vehicle. If in doubt, Important safety notes recover the vehicle with a crane. WARNING When towing, pull away slowly and smoothly. If the tractive power is too high, If you tow the vehicle, you must use a rigid the vehicles could be damaged.

  • Page 309: Towing And Tow-Starting

    Towing and tow-starting Removing the towing eye Deactivate tow-away protection page 67) before the vehicle is towed. Loosen the towing eye and unscrew it. Position cover : on the bumper and press it until it engages. Fitting/removing the towing eye Place the towing eye in the vehicle tool kit.

  • Page 310: Transporting The Vehicle

    Towing and tow-starting In order to ensure that the automatic trans- As soon as the vehicle is loaded: mission stays in position N when towing the Prevent the vehicle from rolling away by vehicle, you must observe the following applying the parking brake. points: Shift the automatic transmission to posi- Make sure that the vehicle is stationary and...

  • Page 311: Electrical Fuses

    Only use fuses that have been approved for fuse box in the engine compartment on the Mercedes-Benz vehicles and which have the right-hand side of the vehicle, when viewed correct fuse rating for the systems con- in the direction of travel cerned.

  • Page 312: Ment

    Electrical fuses To open: pull cover : upwards in the When closing the cover, make sure that it is lying correctly on the fuse box. Moisture direction of the arrow and remove it. seeping in or dirt could otherwise impair To close: clip in cover : on top of the the operation of the fuses.
  • Page 313 Useful information ......312 Important safety notes ....312 Operation ........... 312 Winter operation ....... 314 Tyre pressure ........315 Changing a wheel ......320 Wheel and tyre combinations ..325 Emergency spare wheel ....328...

  • Page 314: Useful Information

    Accessories that are not approved for your damage. Hidden tyre damage could also be vehicle by Mercedes-Benz or are not being causing the unusual handling characteristics. used correctly can impair the operating If you find no signs of damage, have the tyres safety.

  • Page 315: Checking

    Only fit tyres of the correct size onto the ard valve cap or other valve caps approved by wheels. Mercedes-Benz for your vehicle. Do not fit any Run in new tyres at moderate speeds for other valve caps or systems, e.g. tyre pres- the first 100 km.

  • Page 316: Winter Operation

    Restart the tyre pressure loss warning sys- thereby damaging the tyres permanently. tem ( page 317). Mercedes-Benz cannot accept responsibility For more information on driving with the for this type of damage. emergency spare wheel, see ( page 328).

  • Page 317: Tyre Pressure

    Mercedes-Benz, or that are of a corre- at least every two weeks sponding standard of quality. if the load changes...
  • Page 318 Tyre pressure Only screw standard valve caps or valve caps specifically provided by Mercedes-Benz for your vehicle onto the tyre valve. WARNING If the tyre pressure drops repeatedly, the wheel, valve or tyre may be damaged. Tyre pressure that is too low may result in a tyre blow-out.

  • Page 319: Restarting

    Tyre pressure you are towing a very heavy or large trailer. The tyre pressure values given for low loads are minimum values which offer you you are driving with a heavy load (in the good ride comfort characteristics. vehicle or on the roof). However, you can also use the values given for higher loads.
  • Page 320 Tyre pressure After a teach-in period, the tyre pressure the corresponding sensors are fitted to all loss warning system will monitor the set wheels. tyre pressures of all four tyres. Information on tyre pressures is displayed in the multifunction display. After a few minutes If you wish to cancel the restart: of driving, the current tyre pressure of each Press the X button.
  • Page 321 The tyre pressure monitor then pressure monitor can be found online at: monitors the new tyre pressure values. http://www.mercedes-benz.de/ Use the table on the inside of the fuel filler betriebsanleitung. flap to ensure that the tyre pressure is set...

  • Page 322: Changing A Wheel

    Changing a wheel Tyre-fitting tools should not be applied in Country Radio type approval number the area of the valve, as this could damage Morocco MR5527 ANRT 2010/ 27. April the electronic components. 2010 Only have tyres changed at a qualified spe- MR5526 ANRT 2010/ 27.

  • Page 323: Changing A Wheel

    Do not use high-pressure cleaners with circu- change on your vehicle, consult a lar-jet nozzles to clean the vehicle. Have dam- Mercedes-Benz Service Centre. aged tyres or chassis components replaced Required tyre-changing tools could be, for immediately.

  • Page 324: Raising The Vehicle

    Mercedes-Benz. If the jack is used incorrectly, it could tip over while the vehicle is raised. the jack is designed only to raise and hold the vehicle for a short time while a wheel is being changed.

  • Page 325: Removing A Wheel

    Changing a wheel Jacking points Using wheel wrench :, loosen the bolts on jack the wheel you wish to change by about one full turn. Do not unscrew the bolts com- Crank pletely. Position jack = at jacking point ;. The jacking points are located just behind the Example front wheel arches and just in front of the rear...

  • Page 326: Fitting A New Wheel

    Changing a wheel approved for Mercedes-Benz vehicles and the respective wheel. Always use wheel bolts ; to fit 17" wheels or the 18" collapsible emergency spare wheel. Using other wheel bolts when fitting 17" wheels or the 18" collapsible emergency spare wheel could damage the brake system.

  • Page 327: Wheel And Tyre Combinations

    MO = Mercedes-Benz Original MOE = Mercedes-Benz Original Extended (tyres featuring run-flat characteristics) MO1 = Mercedes-Benz Original (only cer- tain AMG tyres) Mercedes-Benz Original Extended tyres Place the ratchet ring spanner onto the may only be used on wheels that have been hexagon nut of the jack so that the letters specifically approved by Mercedes-Benz.
  • Page 328 V1, V2 etc.: Retreaded tyres are neither tested nor recommended by Mercedes-Benz, since V1 R 300, R 350, R 350 4MATIC, R 350 previous damage cannot always be detec- 4MATIC , R 350 CDI 4MATIC ted on retreaded tyres.

  • Page 329: Summer Tyres

    Wheel and tyre combinations Tyres Summer tyres Tyres Light-alloy wheels BA: 255/55 R18 105 W BA: 8.0 J x 18 H2 ET 67 — Tyres Light-alloy wheels BA: 255/50 R19 103 W BA: 8.0 J x 19 H2 ET 67 BA: 255/50 R19 103 W BA: 8.0 J x 19 H2 ET 67 MOExtended...
  • Page 330 Emergency spare wheel All-weather tyres Tyres Light-alloy wheels BA: 7.5 J x 17 H2 ET 56 — — BA: 235/65 R17 104 H M+S Winter tyres Tyres Light-alloy wheels BA: 235/65 R17 104 H BA: 7.5 J x 17 H2 ET 56 —...

  • Page 331: Emergency Spare Wheel

    Emergency spare wheel sure of the removed wheel for a few To prevent hazardous situations: minutes. The value displayed for the moun- Adapt your driving style accordingly and ted emergency spare wheel is not the same drive carefully. as the current tyre pressure of the emer- Never fit more than one spare wheel/emer- gency spare wheel.
  • Page 332 Emergency spare wheel The tyre inflation compressors differ as fol- Inflating the collapsible emergency lows: spare wheel Version 1: tyre inflation compressor with Inflate the collapsible emergency spare a pressure gauge on the air hose wheel using the tyre inflation compressor Version 2: tyre inflation compressor with before lowering the vehicle.

  • Page 333: Stowing

    Mercedes-Benz recommends that you have compressor to I. this work performed at a qualified specialist The tyre inflation compressor is switched workshop, e.g. at a Mercedes-Benz Service on. The tyre is inflated. The tyre pressure is Centre. shown on pressure gauge ?.
  • Page 334 Emergency spare wheel Lay collapsible emergency spare wheel ; in the emergency spare wheel well. Make sure that collapsible emergency spare wheel ; is positioned on guides : precisely. Lay the warning triangle in the emergency spare wheel well. Lay the tool holder in collapsible emer- gency spare wheel ;...

  • Page 335: Technical Data

    Emergency spare wheel Technical data All vehicles (except R 350 BlueTEC 4MATIC and R 500 4MATIC) Collapsible emergency spare wheel Tyres Light-alloy wheels 195/75 – 18 106 P 6.5 B x 18 H2 ET 40 Tyre pressure: 300 kPa (3.0 bar/44 psi) 185/65 –...

  • Page 337: Technical Data

    Useful information ......336 Information on technical data ..336 Genuine Mercedes-Benz parts ..336 Vehicle electronics ......337 Identification plates ......338 Service products and capacities ..339 Vehicle data ........346 Trailer tow hitch ........ 347 24 GHz radar sensor system ... 349...

  • Page 338: Useful Information

    Mercedes-Benz parts meet the approval For this reason, Mercedes-Benz recommends requirements. The use of non-approved parts that you use genuine Mercedes-Benz parts or may invalidate the vehicle's general operating parts of equal quality. Only use tyres, wheels permit.

  • Page 339: Vehicle Electronics

    (VIN) ( page 338) and the engine num- cialist workshop. ber ( page 339) when ordering genuine Mercedes-Benz parts. The operating permit may be invalidated if the instructions for installation and use of RF transmitters are not observed. Vehicle electronics...

  • Page 340: Identification Plates

    Be sure to observe the manufacturer's additional instructions when installing. Deviations with respect to wavebands, maxi- mum transmission outputs or aerial positions must be approved by Mercedes-Benz. The maximum transmission output (PEAK) at the base of the aerial must not exceed the following values: Open the front right-hand door.

  • Page 341: Service Products And Capacities

    Mercedes-Benz recommends that you use products tested and approved by Slide right-hand seat : of the second row Mercedes-Benz. They are listed in this to its rearmost position. Mercedes-Benz Owner's Manual in the appro- Fold floor covering = upwards.

  • Page 342: Additives

    Switch off the engine and the auxiliary heating and prevention of residue build-up. Only before refuelling. cleaning additives recommended by Mercedes-Benz should be added to petrol, WARNING see "Additives". You can obtain further Avoid contact with fuels. information from any Mercedes-Benz It is hazardous to your health if your skin Service Centre.

  • Page 343: Diesel

    Do not mix such fuels with diesel fuel and build up. In this case, Mercedes-Benz recom- do not use any special additives. This can mends the use of additives that have been otherwise lead to engine damage.

  • Page 344: Notes

    COC documents Only use flow improvers tested and approved (EU CERTIFICATE OF CONFORMITY). These by Mercedes-Benz. During use, please documents are delivered with your vehicle. observe the information on operation. The consumption figures were in each case...

  • Page 345: Engine Oil

    Additives Therefore, only Mercedes-Benz approved ® Only use AdBlue in accordance with ISO engine oils may be used in Mercedes-Benz ® 22241. Do not use additives with AdBlue engines. ® and do not dilute AdBlue with water. This...

  • Page 346: Viscosity

    Service products and capacities Engine oil viscosity Diesel engines without MB Approval diesel particle filter R 300 CDI BlueEFFI- 228.3, 228.5, CIENCY 228.51, 229.3, 229.31, 229.5, C 300 CDI 4MATIC 229.51 BlueEFFICIENCY R 350 CDI 4MATIC If the engine oils listed in the table are not available, you may add the following engine oils until the next oil change: Viscosity describes the flow characteristics...

  • Page 347: Important Safety Notes

    MB Specifica- Further information on coolants can be tions for Service Products 310.1. found in the Mercedes-Benz Specifications The coolant is checked at every maintenance for Service Products, MB Specifications for interval at a qualified specialist workshop.

  • Page 348: Vehicle Data

    Vehicle data MB WinterFit. Unsuitable washer fluid Vehicle data could damage the plastic lenses of the General notes headlamps. Please note that for the specified vehicle Do not use distilled or de-ionised water in data: the washer fluid reservoir. Otherwise, the level sensor may be damaged.

  • Page 349: Trailer Tow Hitch

    Trailer tow hitch Model : Open- R 500 4MATIC ing height Maximum Vehicle height 1666 mm headroom Unladen weight 2265 kg All models 2047 mm – 1901 mm – 2074 mm 1927 mm R 300 CDI BlueEFFI- CIENCY All models R 300 CDI 4MATIC Blue- EFFICIENCY Vehicle length, short...
  • Page 350 Trailer tow hitch Example: anchorage points for the trailer tow hitch Anchorage points Overhang dimension Rear axle centre line For trailer tow hitches fitted at the factory, the overhang dimension including protective cov- ering is 1,134 mm.

  • Page 351: 24 Ghz Radar Sensor System

    ( page 204). The current country overview can be obtained from a Mercedes-Benz Service Centre or on the Internet at: http://www.mercedes-benz.de/betriebsanleitung. Vehicles with a navigation system: the radar sensor system is deactivated automatically near radio telescope facilities.
  • Page 355 Publication details Internet Further information about Mercedes-Benz vehicles and about Daimler AG can be found on the following websites: http://www.mercedes-benz.com http://www.daimler.com Editorial office You are welcome to forward any queries or suggestions you may have regarding this Owner's Manual to the technical documenta-...
  • Page 356 É2515845982Z102)ËÍ 2515845982Z102 Order no. 6515 1850 02 Part no. 251 584 59 82 Z102 Edition ÄJ 2012-1a Nur für internen Gebrauch / For internal use only...

Table of Contents

Save PDF
