- Page 1 Start up Guide NTEP A-Series Balance Series...
- Page 2 1. CONTENT Models: SAS-224.N | SAS-314.N Balance Weighing pan Draft shield Bottom insert Power adapter Models: SPS-213.N | SPS-363.N | SPS-1003.N Power adapter Balance Weighing pan Draft shield Grounding foot Foot Models: SPS-2102.N | SPS-3502.N | SPS-4502.N Balance Weighing pan Grounding foot Foot Power adapter...
- Page 3 2. WORKROOM AND BASIC OPERATION GUIDELINES Operate the device in a room where the temperature ranges between 10–40 °C +40 C (50–104 °F) and where the relative humidity is below 80%. +104 F Place the balance on a solid surface to ensure stability. To obtain stable and +10 C repeatable weighing results, an anti-vibration table is recommended.
- Page 4 4. ACTIVITIES TO BE DONE PRIOR TO OPERATION 4.1. Remove transport lock Models: SAS-224.N | SAS-314.N Keep the transport lock should a warranty claim or service be required. Models: SPS-213.N | SPS-363.N | SPS-1003.N | SPS-2102.N | SPS-3502.N | SPS-4502.N Keep the transport lock should a warranty claim or...
- Page 5 5. COMPONENTS ASSEMBLY Models: SAS-224.N | SAS-314.N Models: SPS-213.N | SPS-363.N | SPS-1003.N Install the grounding foot in a freely selected opening. Models: SPS-2102.N | SPS-3502.N | SPS-4502.N Install the grounding foot in a freely selected opening.
- Page 6 6. PREPARING FOR WORK 6.1. Balance temperature stabilization time Prior to switching the device on it is necessary Balance temperature stabilization time ranges to ensure that it has reached a temperature between 1 - 8 hours. equal to room temperature. E t h e U S B B U S 1...
- Page 7 7. PANEL AND SCREEN 7.1. Panel keys 7.2. Home screen...
-
Page 8: Basic Operations
8. BASIC OPERATIONS 8.1. Adjustment Wait for the adjustment completion. Press key to start the adjustment 8.2. Zeroing The balance has been zeroed. Unload the weighing pan and press "Zeroing" button. 8.3. Taring When the weighing result has been The balance has been tared. displayed press "Tare"... - Page 9 8.4. Working modes accessibility Using keys select "Working mode" Press to enter "Setup" menu. and press In the "Accessibility" position, press Using keys to select working modes for which accessibility is to be set and press key. Using keys to set accessibility parameter to "Yes"...
- Page 10 8.5. Selecting working mode keys, select working mode and Using Press key to enter working modes menu. key to confirm. press 8.6. Weighing unit accessibility Press to enter "Setup" menu. Using keys, select "Units" and press...
- Page 11 In the "Accessibility" position, press In the "Accessi Using keys to select unit for which accessibility is to be set and press key. Using keys to set accessibility parameter to "Yes" value for a selected working mode and press key to confirm. 8.7.
- Page 12 9. SETTINGS Some balance settings are accessible for Administrator exclusively. Prior balance parameters setup, log in as the Administrator. 9.1. Administrator's login key to enter "Database" menu Press To enter user parameters, press Using keys select "Admin" and press Using keys select "1111"...
-
Page 13: User Settings
9.2. User settings Prior balance users setup, log in as the Administrator. Press Using keys to select "View/Edit" key to enter "Database" menu and press key to confirm To select "Users" parameters, press Using keys select "Admin" and press key to confirm Press key to add new user. - Page 14 Using keys to enter user name and key to add new user. Press press key to confirm Using keys select "Code" and press Using keys enter user code and press key to confirm Using keys select "Password" and press Using keys enter user password and key to confirm press...
- Page 15 Using keys select "Access Level" and Using keys select permissions level and press key to confirm. key to confirm. press Using keys select "Language" and press Using keys to select menu language key to confirm press key to confirm.
- Page 16 10. PERIPHERAL DEVICES CONNECTORS Computer Printer Computer Printer Power adapter Additional Additional Barcode Barcode scanner display scanner display RS 232 RS 232 USB 1 USB 2 Ethernet Ethernet USB-B USB-A RJ45 Keyboard Computer Printer Computer Barcode Printer scanner...
- Page 17 11. DEVICE CLEANING 11.1. General Recommendations Prior to cleaning, it is necessary to Use soft cloths made of microfiber, Apply the cleanser onto the cloth first. disconnect th e balance from the mains. natural fiber or man-made fiber. Avoid Avoid applying the cleanser directly using abrasive cloths or cloths that might onto the device.
