- Page 1 Doc. no.MX*-OMX0004 PRODUCT NAME Compact Cylinder with Linear Guide MODEL / Series / Product Number MXZ12(R,L)-** MXZ16(R,L)-** MXZ20(R,L)-** MXZ25(R,L)-** - 1 -...
-
Page 2: Table Of Contents
Contents Safety Instructions 1. Product Specifications 1-1 Specifications 2. Installation 2-1 Mounting 2-2 Air supply 2-3 Piping 2-4 Operating enviroment 2-5 Lubricating 2-6 Speed adjustment 2-7 Auto switch mounting 3. Maintenance 3-1 Precautions for maintenance 3-2 Replenishment of grease 3-3 Removing the product 3-4 Construction and parts - 2 -... - Page 3 Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
- Page 4 Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
-
Page 5: Product Specifications
1. Product Specifications 1-1 Specifications Model MXZ12 MXZ16 MXZ20 MXZ25 Φ12 Φ16 Φ20 Φ25 Bore size(mm) Pilot port M3x0.5 M5x0.8 Fluid Action Double acting Operating pressure 0.1 to 0.7 MPa Proof pressure 1.05MPa Ambient and fluid tempetature 5 to 60°C Piston speed (Average speed) 50 to 500mm/s maximum piston collision speed... - Page 6 2. Through-hole Mounting Tightening torque (N・m) Model Bolt L(mm) MXZ12 M3x0.5 24.5 MXZ16 M3x0.5 25.5 0.63 MXZ20 M3x0.5 29.7 MXZ25 M3x0.5 32.2 (2) How to mount the workpiece Mounting to the Table Using the Tapped Holes Tightening torque Min. screw-in Max.
- Page 7 (3) Precautions for mounting Caution 1) Do not dent, scratch or cause other damage to thebody, table and end plate mounting surfaces.This may cause unevenness in the mounting surface, play in the guide or an increase in the sliding resistance. 2) Do not dent, scratch or cause other damage to the surface over which the rail and guide will move.
- Page 8 2. For Pressing (Clamping) Caution Pressing work should be performed in line with the center of the guide. If there is an offset in the L2 direction, an eccentric load will be applied to the guide. In this case, pressing operations should not be performed. 3.
- Page 9 3) Place a bracket so that it contacts the machined corner of the surface for mounting or insert a pin into the through hole on the side to prevent sliding. (5) Others Caution Warning 1) Do not place your hands or fingers between the table and the bracket. Hands or fingers could get caught between the table and the bracket when the piston rod retracts.
-
Page 10: Air Supply
2-2 Air supply Warning 1) Use clean air. Do not use compressed air which contains chemicals, synthetic oils containing organic solvents, salts or corrosive gases, etc., as this can cause damage or malfunction. Caution 1) Install an air filter. Install an air filter close to the upstream side of the valve. Choose the filter of 5μm of filtration. 2) Install an aftercooler, air dryer or water droplet separator. -
Page 11: Operating Enviroment
2-4 Operating environment Warning 1) Do not use in environments where there is a danger of corrosion. Refer to the construction drawings regarding cylinder materials. 2) Install a cover over the rod if it is used in an area that is dusty, or in an environment in which water or oil splashes on the cylinder. -
Page 12: Auto Switch Mounting
2-7 Auto Switch Mounting Precautions for mounting Caution 1) Auto switch mounting tool For the tightening of the mounting screws (attached to the auto switch), use a watchmaker's screwdriver with a handle diameter of about 5 to 6 mm. 2) Tightening torque 0.05 to 0.15N･m As a guide, turn an additional 90 degrees from the position where it feels tight. - Page 13 (1) Bottom mounting (2) When mounting an auto switch (3)When mounting the autoswitch into (When mounting an auto switch into the groove from the top the groove through the mounting before holding the product) (When mounting an auto switch surface. into the groove from the top after installation) - 13 -...
- Page 14 - 14 -...
- Page 15 - 15 -...
-
Page 16: Maintenance
3. Maintenance 3-1 Precautions for maintenance Warning 1) Maintenance should be performed according to the procedure indicated in the Operation Manual. Improper handling can cause damage and malfunction of equipment and machinery. 2) Removal of equipment, and supply/exhaust of compressed air When components are removed, first confirm that measures are in place to prevent workpieces from dropping and/or equipment running away, etc. -
Page 17: Construction And Parts
3-3 Construction and parts Mounting screw Basic type/Component parts Description Material Note Heat treatment, Rail Stainless steel Rust proof treatment Guide Stainless steel Heat treatment Retainer Stainless steel Roller stopper A Stainless steel Roller stopper B Stainless steel Table Aluminum alloy Hard anodized Bracket Stainless steel... - Page 18 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2011 SMC Corporation All Rights Reserved - 18 -...
