Hurco VTX Series Maintenance And Safety Manual

Machining center
Hide thumbs
Table of Contents

Advertisement

Quick Links

M
S
AINTENANCE AND
AFETY
M
ANUAL
for VTX Series
Machining Centers
704-0211-215
December 2010
Revision A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VTX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hurco VTX Series

Summary of Contents for Hurco VTX Series

  • Page 1 AINTENANCE AND AFETY ANUAL for VTX Series Machining Centers 704-0211-215 December 2010 Revision A...

  • Page 2: Ii - Maintenance And Safety Manual

    MS-DOS, Microsoft, and Windows are registered trademarks of Microsoft Corporation. Many of the designations used by manufacturers and sellers to distinguish their products are claimed as trademarks. Hurco has listed here all trademarks of which it is aware. For more information about Hurco products and services, contact: Hurco Companies, Inc.

  • Page 3: Table Of Contents

    Monthly: Perform a spindle run-in....... 3- 33 704-0211-215 Maintenance Checklist - iii VTX Series Maintenance and Safety Manual...
  • Page 4 Annually: (or after 2000 hours of operation) Replace the rotary-axis oil..3- 30 Annually: (or after 2000 hours of operation) Replace the tilt-axis oil..3- 31 704-0211-215 - iv Maintenance Checklist VTX Series Maintenance and Safety Manual...
  • Page 5 Index ........... . IX - 704-0211-215 Table of Contents — v VTX Series Maintenance and Safety Manual...
  • Page 6 Table 3–11. Troubleshooting: Errors in Dimensions ..... 3 - 40 Table 3–12. Troubleshooting: Environmental Factors ....3 - 41 704-0211-215 vi - List of Figures VTX Series Maintenance and Safety Manual...

  • Page 7: Using This Manual

    The screens are divided into the following areas, in addition to the row of softkeys: Data Entry The data entry area is located on the opposite side of the screen from the softkeys. 704-0211-215 Using This Manual — vii VTX Series Maintenance and Safety Manual...
  • Page 8 Refer to the Getting Started with Your WinMax Mill for information about console buttons and keys, in addition to other information about using softkeys and the pop-up text entry window. 704-0211-215 viii - Using This Manual VTX Series Maintenance and Safety Manual...
  • Page 9 Table of Contents (TOC). You can also access many of the same TOC entries from the Adobe Reader bookmarks located on the left side of the PDF page. 704-0211-215 Using This Manual — ix VTX Series Maintenance and Safety Manual...
  • Page 10 704-0211-215 x - Using This Manual VTX Series Maintenance and Safety Manual...

  • Page 11: Machine Components

    Automatic Tool Changer ........1 - 704-0211-215 Machine Components 1-1 VTX Series Maintenance and Safety Manual...

  • Page 12: Overview

    Overview Before using the machine, you should become familiar with its components. Because of European Committee (CE) requirements, Hurco machines sold in Europe may differ from those sold elsewhere. The location of some components may differ on different models. Hurco machines are available with several hardware and software options.

  • Page 13: Frame

    24.0 x 20.9 in 880 lbs VTXZ 33.6 mm 90 x 26 in 48.7 x 26 in 40.12 x 26 in 6614 lbs Table 1–4. VTX Machine Table Specifications, English 704-0211-215 Machine Components 1-3 VTX Series Maintenance and Safety Manual...
  • Page 14 Limit switches, proximity switches, and electrical sensors monitor machine functions. These devices report their status to the control. If a malfunction is detected, a stop condition will shut off power to the servo systems and spindle. 704-0211-215 1 - 4 Machine Components VTX Series Maintenance and Safety Manual...

  • Page 15: Enclosure

    Enclosure A full chip enclosure is standard in every Hurco machining center. Figure 1–1. Full Chip and Coolant Enclosure—VTXU Figure 1–2. Full Chip and Coolant Enclosure—VTXZ Standard features may include a wash down system, and either a chip conveyor or an auger chip conveyor.

  • Page 16: Spindle And Drive System

    Spindle and Drive System Hurco machines have a cartridge-type spindle. This spindle is precision-balanced, and made of high-grade alloy steel. The spindle shaft (inside the cartridge) is supported by ABEC-7 class angular contact bearings. The bearings are grease packed. The spindle and drive system consists of a spindle, motor with encoder, pulley arrangement, and drive unit.
  • Page 17 704-0211-215 Machine Components 1-7 VTX Series Maintenance and Safety Manual...

  • Page 18: Axes Motion System

    VTXU 31.5 in 27.6 in 20.0 in -30° to +110° ° VTXZ 80.0 in 30.0 in 30.0 in 26.0 in 24.0 in Table 1–9. Axis Maximum Travel, English 704-0211-215 1 - 8 Machine Components VTX Series Maintenance and Safety Manual...

  • Page 19: Table 1-10. Rapid Traverse Rates, Metric

    These signals are required for motor control and accurate positioning. Limit switches mounted on each axis are used to establish reference points for initial machine zeros and for determining end-of-travel. 704-0211-215 Machine Components 1-9 VTX Series Maintenance and Safety Manual...

  • Page 20: Machine Electrical Cabinet

    • After the replacement PCB is properly mounted in the cabinet, place the defective PCB assembly into the static shielding and return it to Hurco. Electrical Cabinet Components The electrical cabinet contains power circuitry and CNC electronics. The cabinet is attached to the machine column and connects to the machine systems via cable and harness assemblies.
  • Page 21 (131º F). If the temperature exceeds the limit, the machine will post an error message for the operator. Hurco machines that are not equipped with the air conditioning option may be operated in ambient temperatures to 35º C (95º F), and in relative humidity (non-condensing) up to 95%.
  • Page 22 Each RMB supports four motors (command and feedback) and one encoder (feedback only). Hurco machines use a single RMB for a 3-axis (XYZ and S) configuration. An additional RMB is required for 4th-axis, 5th-axis, and dual loop linear scale configurations.
  • Page 23 Multiple boards may be used to provide additional I/O. The extension enclosure accepts two of these boards in addition to the I/O interface board; all are connected to the CANbus DC I/O backplane. Expansion for other boards is possible. 704-0211-215 Machine Components 1-13 VTX Series Maintenance and Safety Manual...

  • Page 24: Figure 1-4. Communication Port Assembly

    The connector pin designated for the RS-232C signal is shown below: Figure 1–5. Male 9-Pin D-Type Connector 704-0211-215 1 - 14 Machine Components VTX Series Maintenance and Safety Manual...

  • Page 25: Table 1-13. Rs-232C Signals Available At Serial Port

    Consult the peripheral manual to determine whether the peripheral is a Data Terminal Equipment (DTE) or Data Communication Equipment (DCE) device. The Hurco machine is a DTE device, and in most cases, so is a personal computer. A printer may be either a DTE or DCE device.

  • Page 26: Control Systems

    You can use a jump drive to transfer files. Control Systems Circuit diagrams for electrical, hydraulic, and pneumatic systems are available in the Parts Listings and Wiring Diagram Manual for the machine. 704-0211-215 1 - 16 Machine Components VTX Series Maintenance and Safety Manual...

  • Page 27: Operator Control Console

    Operator Control Console Hurco VTX and series machines come with a dual-screen control console. Contact your full service distributor or Hurco for more information about console features. The dual-screen console sits on a base-mounted pendant. Text is displayed on the left screen, and graphics are displayed on the right.
  • Page 28 DC voltage supplied from the Flat Panel Node. Dual-screen consoles have a brightness control knob under the plastic bezel. Brightness level is fixed on Max console systems. 704-0211-215 1 - 18 Machine Components VTX Series Maintenance and Safety Manual...
  • Page 29 • 100 position MPG Handwheel • Rapid +/- console keys • Rapid Feed control knob • Axis selector switch The Remote Jog Unit may be equipped with an Enable button. 704-0211-215 Machine Components 1-19 VTX Series Maintenance and Safety Manual...

  • Page 30: Flood Coolant And Washdown System

    An optional external QWERTY keyboard with protective cover and mounting provision is available for each dual-screen and Max control. Information about options is available from Hurco or your Hurco full-service distributor. If using a QWERTY keyboard, it must be connected prior to powering on the machine.

  • Page 31: Pneumatic System

    Incoming air pressure can be adjusted using the knob on top of the filter assembly. For information about maintaining the FRL Unit, refer to, on page 3 - 704-0211-215 Machine Components 1-21 VTX Series Maintenance and Safety Manual...

  • Page 32: Trunion Table

    35 Bar during factory installation. Disassembling the trunion table or any component of the table may cause irreparable damage and void your Hurco warranty. Contact a Hurco-certified Service Engineer to service the trunion table.

  • Page 33: Automatic Tool Changer

    Operating the clamping system above 40 Bar may cause buckling of the clamping system and damage to the tilt and rotary axes of the trunion table. Hurco recommends maintaining the hydraulic pressure for the clamping system at 35 Bar. Automatic Tool Changer The ATC for the VTXU and VTXZ machines is a random-pocket tool changer that tracks tools in the magazine using an ATC Map.
  • Page 34 704-0211-215 1 - 24 Machine Components VTX Series Maintenance and Safety Manual...

  • Page 35: Operation Requirements

    Noise Levels..........2 - 704-0211-215 Operation Requirements 2-1 VTX Series Maintenance and Safety Manual...

  • Page 36: Machine Installation

    Inspect the machine to ensure that all parts are included and intact. The owner is responsible for proper site preparation before the machine is installed. A Hurco Field Service Engineer must install the machine in the prepared location. This location must not subject the machine to uncontrolled cabinet temperatures or unfavorable work environment conditions that could cause electronic component failure.
  • Page 37 Follow all requirements below to help ensure personnel safety and to prevent equipment damage. Run electrical power to the machine location, with adequate length to reach the connections in the power cabinet. Final connections MUST be supervised by a Hurco- certified Service Engineer. Connecting Electrical Service Observe the following guidelines when connecting electrical service: •...
  • Page 38 Check the mountings before uncrating the machine to ensure that the machine has been handled properly prior to its arrival. Continue to inspect the mountings on a regular basis. 704-0211-215 2 - 4 Operation Requirements VTX Series Maintenance and Safety Manual...

  • Page 39: Initial Test And Examination

    Follow the instructions below for performing the initial test and examination of the machine and its guarding system. Arrange for a Hurco-certified Service Engineer to perform the final machine setup. Complete these procedures prior to the arrival of the Service Engineer: 1.

  • Page 40: Safety Circuits

    Hurco warranty. If such modifications are discovered, the machine must be immediately shut off and not used.
  • Page 41 At this point, you can shut the door and press Start Cycle to run the program. You may select the Auto console key and access Auto (Conversational) screen to perform Estimated Run Time or Check for Errors regardless of door status. 704-0211-215 Operation Requirements 2-7 VTX Series Maintenance and Safety Manual...
  • Page 42 Select the Interrupt console key and the doors unlock after axis motion is completed. • To resume machine operations with the doors closed, press the Auto console key and then press the Start Cycle button. 704-0211-215 2 - 8 Operation Requirements VTX Series Maintenance and Safety Manual...
  • Page 43 • With control power on, counter motions can be activated using the machine’s console control. In addition, power-piloted valves can be activated by pressing corresponding buttons. 704-0211-215 Operation Requirements 2-9 VTX Series Maintenance and Safety Manual...

  • Page 44: Safe Operation

    Safe Operation This section addresses the safe operation of the machine. The information presented here is not a substitute for operator training, skill, and good judgment. Hurco does not accept any liability for operator error. Training for Operators Hurco or a Hurco-authorized distributor must train all machine operators. Hurco offers classes to demonstrate the programming capabilities of its CNC system.
  • Page 45 • Know how the machine functions, and understand its safety features. 704-0211-215 Operation Requirements 2-11 VTX Series Maintenance and Safety Manual...
  • Page 46 Do not remove chips by hand, or while the spindle is turning. Dispose of chips frequently. 704-0211-215 2 - 12 Operation Requirements VTX Series Maintenance and Safety Manual...

  • Page 47: Noise Levels

    The maximum ambient noise level reading taken for machines is 60 dB. The maximum reading for any Hurco machine will not exceed 85 dB. The following noise levels represent the maximum reading a machine will produce in the vicinity of the console.
  • Page 48 704-0211-215 2 - 14 Operation Requirements VTX Series Maintenance and Safety Manual...

  • Page 49: Machine Maintenance

    Ordering Replacement Parts........3 - 704-0211-215 Machine Maintenance 3-1 VTX Series Maintenance and Safety Manual...

  • Page 50: Daily Operational Checks

    RPM, while observing for proper start, stop, and spindle operation. If the spindle is idle for more than thirty (30) days, please refer to the or the Spindle Run-in or Cycle Procedure, on page 3 - 704-0211-215 3 - 2 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 51: Floppy Disk Drive And Diskettes

    (at the rear of the machine). 2. Rinse the filters with clean water and dry. 3. Reinstall the filter into its mount on the outside of the electrical cabinet door. 704-0211-215 Machine Maintenance 3-3 VTX Series Maintenance and Safety Manual...

  • Page 52: Exterior Wiring

    I.S.O. V.G. 32 exceed half full. Trunion Table Rotary Axis 2.0 liters ISO VG-220 (C-axis) Trunion Table Tilt Axis 2.0 liters I.S.O. VG 220 (A-axis) Table 3–1. Lubrication 704-0211-215 3 - 4 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 53: Figure 3-1. Autolube Pump And Tank Assembly

    The Autolube system automatically lubricates the slideways, guideways, and ballscrews. The HTX and VTX series machines use a digital timer Autolube system. Once adequate pressure is attained, the system cycles on for 30 seconds to send lube oil through the machine, then cycles off for 900 seconds.

  • Page 54: Monthly: Add A Rust Preventative To The Autolube System

    3. Press the F (Feed) key on the Autolube system a third time. The INT light will illuminate. 4. Press the F (Feed) key on the Autolube system a fourth time to initiate the lubrication cycle. 704-0211-215 3 - 6 Machine Maintenance VTX Series Maintenance and Safety Manual...
  • Page 55 3. Press the F (Feed) key on the Autolube system a third time. The INT light will illuminate. 4. Press the + or - key on the Autolube system to increase or decrease the dwell time between lubrication cycles. 704-0211-215 Machine Maintenance 3-7 VTX Series Maintenance and Safety Manual...

  • Page 56: Monthly: Manually Activate The Autolube System

    Monthly: Manually activate the Autolube system if the machining center has been idle for a long time before powering up, or if the oil has just been replaced. 704-0211-215 3 - 8 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 57: Table 3-1. Lubrication

    Every 6 Months or every 1000 hours: Grease the ATC magazine chain assembly. Use a brush to apply grease. Spread a light coating of grease over the chain assembly. Avoid grease build-up. 704-0211-215 Machine Maintenance 3-9 VTX Series Maintenance and Safety Manual...

  • Page 58: Daily: Clean The Tool Lock Pins And Tool Gripper Fingers

    6. Return the ATC to the Home position. Home is defined as ATC Door Closed (if so equipped), Exchange Arm at 0 , Tool Holder at UP (or 0 for HTX ° ° machines), and Magazine in Pos #1. 704-0211-215 3 - 10 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 59: Weekly: (Or After 40 Hours Of Operation) Check The Condition Of Tools

    Check and Clean Tool Holders Weekly: Check each tool holder for damage. Follow these steps to use the Hurco-recommended way to access tools: 1. Cycle the tool from the magazine into the spindle. 2. Remove the tool from the spindle.

  • Page 60: Spindle

    Spindle Most Hurco machines come equipped with a non-motorized spindle. Air blows from the spindle taper hole when the spindle is unclamped. Any moisture in the air system will be detrimental to the taper, especially when the machine is stopped for an extended time.

  • Page 61: Air Filter

    5. Replace contaminated solution. Refer to Flush, Clean Tank, and Refill the Chiller Solution in the Spindle Chiller Tank, on page 3 - 14 for instructions. 704-0211-215 Machine Maintenance 3-13 VTX Series Maintenance and Safety Manual...
  • Page 62 3. Disconnect all pipes between the machine tool and the cooler unit. 4. Extract refrigerant our of the cooler unit according to the relevant regulations of environmental protection. 704-0211-215 3 - 14 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 63: Ambient Temperature

    Turn the machine’s main power switch Off before proceeding. • Avoid flame near any oil (in the form of liquid or gas). • Choose a well-ventilated location if releasing refrigerant. 704-0211-215 Machine Maintenance 3-15 VTX Series Maintenance and Safety Manual...

  • Page 64: Table 3-2. Differential Temperature Cooling Process

    For all machining centers, the spindle chiller should be set for Differential Temperature Control, except for SR models which should be set for Fixed Temperature Control. Hurco recommends the Differential Temperature on the spindle chiller be set to 2 °...

  • Page 65: Figure 3-2. Hwk Spindle Chiller Control Panel

    The Set key on the right side of the panel accesses the chiller parameters. Press the Plus (+) function key to display the room temperature. Press the Minus (-) function key to display the liquid temperature. 704-0211-215 Machine Maintenance 3-17 VTX Series Maintenance and Safety Manual...
  • Page 66 Temperature Setting appears. To change this value, press Set again. Then press the Plus (+) or Minus (-) function key. Hurco recommends setting the value for the Differential Liquid Temperature Setting parameter to -2° The default value is +10° C.

  • Page 67: Figure 3-3. Hwt Spindle Chiller Control Panel

    Liquid Operation Lamp lights to display the liquid temperature. • C—displays the differential temperature between ambient air and ° liquid, the temperature at which the liquid cooling occurs. 704-0211-215 Machine Maintenance 3-19 VTX Series Maintenance and Safety Manual...
  • Page 68 Setting the SV°C Temperature To set the SV°C temperature, press the Up or Down arrows on the spindle chiller control panel for at least 0.5 seconds for each press. Hurco recommends keeping the SV°C set at -2° C for Differential Temperature control.

  • Page 69: Pneumatic System

    To adjust the knob, pull it up and turn. To lock the knob, push it back down. 704-0211-215 Machine Maintenance 3-21 VTX Series Maintenance and Safety Manual...

  • Page 70: Weekly: Check The Auto Moisture Drain On Frl

    2. Turn the auto drain nut at the filter unit bottom counter-clockwise one turn. 3. Using a crescent wrench, turn the auto drain nut at the bottom of the filter unit counterclockwise one turn. 4. Tighten the nut clockwise. 704-0211-215 3 - 22 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 71: Flood Coolant And Washdown System

    No aggressive additives. However, suitable additives can increase cutting capacity. Failure of devices or performance problems related to coolant are not a defect in Hurco’s material or workmanship, and will not be covered by Hurco’s warranty. 704-0211-215 Machine Maintenance 3-23...

  • Page 72: Daily: (Or Every 8 Hours) Check The Coolant Level Every Day

    2. If the flood coolant pump is delivering coolant to the machine, then fill to the MAX mark. If the coolant level drops below the L (Low) level mark on the coolant tank, the coolant system may not operate properly. 704-0211-215 3 - 24 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 73: Weekly: (Or After 40-50 Hours Of Operation) Clean The Coolant Filters

    1. Remove the filter housing unit from the CTS pump assembly. Remove the CTS coolant filter from the housing unit. 2. Rinse the filter with clean, soapy water and dry. If the filter is damaged, replace it. 704-0211-215 Machine Maintenance 3-25 VTX Series Maintenance and Safety Manual...

  • Page 74: Chip Conveyor

    The belt runs on guides with sprockets and chains located on the inside of each side of the chip conveyor. Check the chains for looseness and tighten if necessary. 704-0211-215 3 - 26 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 75: Limit Switches And Dogs

    Machine Level Every 6 Months or every 1000 hours: Verify the machine is sitting level. Place a precision level (resolution 0.0005 in/ft.) parallel and perpendicular to the work table surface. 704-0211-215 Machine Maintenance 3-27 VTX Series Maintenance and Safety Manual...

  • Page 76: Enclosure Windows

    Hurco recommends that the user contact your Hurco representative for application of safety film or replacement glass periodically to ensure the proper corrective action is taken.
  • Page 77 Do not use compressed air to remove chips or dirt from the trunion table. Air-blown water and chips may become lodged underneath and cause damage to the trunion table. 704-0211-215 Machine Maintenance 3-29 VTX Series Maintenance and Safety Manual...

  • Page 78: Daily: (Or After 8 Hours Of Operation) Check The Rotary-Axis Oil Level

    6. Open the oil fill plug located on the back side of the trunion table and add approximately 2. 0 liters of clean oil. See Lubrication, on page 3 - 4 recommended oil types. 7. Close the oil fill plug. 704-0211-215 3 - 30 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 79: Daily: (Or After 8 Hours Of Operation) Check The Tilt-Axis Oil

    2.0 liters (one gallon) of clean oil. See Lubrication, on page 3 - for recommended oil types. 7. Close the oil fill plug. 8. Replace the machine’s inspection plate. 704-0211-215 Machine Maintenance 3-31 VTX Series Maintenance and Safety Manual...

  • Page 80: Machine Warm-Up

    11000 RPM 11000 RPM 2 min 12000 RPM 13000 RPM 2 min 15000 RPM 2 min Table 3–3. Machine Warm-up—Spindle Drive Maximum 8K, 10K, 12K & 15K RPM 704-0211-215 3 - 32 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 81: Spindle Run-In Or Cycle Procedure

    7500 RPM 10,000 RPM 12,000 RPM 15min 7500 RPM 9000 RPM 11,000 RPM 13,500 RPM 30 min 8000 RPM 10,000 RPM 12,000 RPM 15,000 RPM 60 min Table 3–4. Spindle Run-in 704-0211-215 Machine Maintenance 3-33 VTX Series Maintenance and Safety Manual...

  • Page 82: Troubleshooting

    Switch off the control and remove the security device. If the device is damaged, replace it. Reconnect the device and switch on the power. 704-0211-215 3 - 34 Machine Maintenance VTX Series Maintenance and Safety Manual...
  • Page 83 The usual solution for such problems is to restore or delete files. For help solving these problems, contact your local Hurco service representative. Before calling a Hurco service representative for assistance, always switch off the control at the power button, wait a few minutes, and then power on again.
  • Page 84 1. Follow the instructions on the ATC & MACHINE DIAGNOSTICS screen. 2. Once the error status is corrected, exit the ATC & MACHINE DIAGNOSTICS screen. 3. Restart and calibrate the machine. 704-0211-215 3 - 36 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 85: Table 3-5. Troubleshooting: Missing Or Faulty Connections

    Machine stops Power spike • Properly ground equipment. and/or data is lost. • Install surge protection to insulate against lightning strikes. Table 3–6. Troubleshooting: Power Fluctuation 704-0211-215 Machine Maintenance 3-37 VTX Series Maintenance and Safety Manual...

  • Page 86: Table 3-7. Troubleshooting: Coolant System

    Coolant fails to • Incorrect program • Check parameters and correct the setting. stop when head is parameters. up to Z retract level. Table 3–7. Troubleshooting: Coolant System 704-0211-215 3 - 38 Machine Maintenance VTX Series Maintenance and Safety Manual...
  • Page 87 Actual collision or binding occurs Examine the path, parts, and fixtures for evidence of between machine parts and collision or rubbing. product fixtures. Table 3–9. Troubleshooting: Power Off Motion Error 704-0211-215 Machine Maintenance 3-39 VTX Series Maintenance and Safety Manual...

  • Page 88: Table 3-10. Troubleshooting: Machine Chatter

    Refer to the table below if small errors in dimensions show up occasionally. Cause Solution Temperature fluctuates as the Stabilize the temperature of the blank by providing part is machined. enough coolant while machining. Table 3–11. Troubleshooting: Errors in Dimensions 704-0211-215 3 - 40 Machine Maintenance VTX Series Maintenance and Safety Manual...

  • Page 89: Table 3-12. Troubleshooting: Environmental Factors

    Table 3–12. Troubleshooting: Environmental Factors 704-0211-215 Machine Maintenance 3-41 VTX Series Maintenance and Safety Manual...

  • Page 90: Ordering Replacement Parts

    Ordering Replacement Parts Hurco maintains a large inventory of service parts. You may order parts from Hurco by telephone, fax, mail, or from your local Hurco Distributor. Contact information is provided during the installation. In addition, Hurco subsidiary contact information can be found on the Hurco Web site: www.hurco.com...

  • Page 91: Record Of Changes

    Updated ATC Tool Specifications table in Mchine Components chapter with VTXU 96 Station ATC per TEchnical Specifications 757-40002-345 Rev F. • Generated a stand-alone version of VTX Series manual. 704-0211-214, HTX/VTX Maintenance and Safety Manual, November 2010, ECN 16540 Revised by: K.Gross Approved by: D.
  • Page 92 Approved by: P. Baechle, B. Mader, D. Skrzypczak, May, 2008 Changes • Updated information for HTX500 and VTXU machines, per technical specifications: HTX500—757-4002-346, Rev B VTXU—757-4002-345, Rev C 704-0211-215 2 - Record of Changes VTX Series Maintenance and Safety Manual...
  • Page 93 704-0211-211, 05/28/05, ECN 15760 Revised by: K. Gross Approved by: P. Baechle, T. Murden, D. Ornelas, D. Skrzypczak, 5/28/05 Changes New manual release. 704-0211-215 Record of Changes - 3 VTX Series Maintenance and Safety Manual...
  • Page 94 704-0211-215 4 - Record of Changes VTX Series Maintenance and Safety Manual...

  • Page 95: Index

    3 - 29 CE Safety Circuits auto mode 2 - 9 manual mode 2 - 7 chains, chip conveyor 3 - 26 chiller, spindle 3 - 12 704-0211-215 Index — 1 VTX Series Maintenance and Safety Manual...
  • Page 96 3 - 28 pneumatic system 1 - 21 hydraulic pump low pressure cut-off 3 - 23 power-on self test 3 - 37 table 1 - 3 704-0211-215 2 - Index VTX Series Maintenance and Safety Manual...
  • Page 97 1 - 9 2 - 9 RS-232 C serial port 1 - 14 pneumatic system 1 - 21 run-in, spindle 3 - 33 maintenance 3 - 21 requirements 3 - 21 704-0211-215 Index — 3 VTX Series Maintenance and Safety Manual...
  • Page 98 3 - 10 tool lock pins 3 - 10 tooling specifications 1 - 23 touchscreen 1 - 18 controller 1 - 18 training for operators 2 - 10 704-0211-215 4 - Index VTX Series Maintenance and Safety Manual...
