Tecnowind Tiger Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Model:
Tiger
SERVICE
Manual
RANGE HOOD
CONTENTS
• Safety precautions
• Distance from the hob
• Technical specifications
• Technical data
• Parts supplied
• Non-return valve - parts supplied
• Aluminium panel / charcoal filter
• Installation
• Control drawing
• Touch control
• Bulbs
• Transformer
• Power board
• Electrical assembly
• Wiring diagram
• Motor
• Condenser
• Exploded view
• Spare parts list
• Troubleshooting

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tiger and is the answer not in the manual?

Questions and answers

Related Manuals for Tecnowind Tiger

Summary of Contents for Tecnowind Tiger

  • Page 1 Model: Tiger SERVICE Manual RANGE HOOD CONTENTS • Safety precautions • Distance from the hob • Technical specifications • Technical data • Parts supplied • Non-return valve - parts supplied • Aluminium panel / charcoal filter • Installation • Control drawing •...

  • Page 3: Table Of Contents

    SUMMARY Safety precautions........................4 Distance from the hob.........................7 Technical specifications........................8 Technical data..........................9 Parts supplied ..........................10 Non-return valve - parts supplied ....................11 Aluminium panel / charcoal filter ....................12 7.1 replacing the aluminum panel 7.2 replacing the charcoal filter Installation......................13 8.1 fixing the appliance to a wall 8.2 fixing the decorative telescopic flue 8.3 installing the charcoal filters and aluminum panels Control drawing..........................19...

  • Page 4: Safety Precautions

    Safety precautions Before connecting the model to the electricity micals when cleaning. network: - Check the data plate (positioned inside the ap- The symbol on the product or on the accom- pliance) to ascertain that the voltage and power panying paperwork indicates that the applian- correspond to the supply circuit.
  • Page 5 Safety precautions • We recommend that the cooker hood is switched frequency with which the appliance is used, the on before any food is cooked. We also recommend type of cooking performed and the regularity with that the appliance is left running for 15 minutes which the anti-grease filters are cleaned.
  • Page 6 Safety precautions WARNING ! • Take care when the cooker hood is operating simultaneously with an open fireplace or burner that depend on the air in the environment and are supplied by other than electrical energy, as the cooker hood removes the air from the environment which a burner or fireplace need for combustion. The ne- gative pressure in the environment must not exceed 4Pa (0.016 WC.).

  • Page 7: Distance From The Hob

    Distance from the hob ��� �� ������ • The minimum distance between the support surfaces of the cooking pots on the cooker top and the lowest part of the cooker hood must be at least 650 mm. If a venting tube composed of two parts is used, the upper part must be placed outside the lower part. Do not connect the cooker hood exhaust to the same conductor used to circulate hot air or for evacuating fumes from other appliances generated by other than an electrical source.

  • Page 8: Technical Specifications

    Technical specifications DUCTS CONTROLS LIGHT ALUMINIUM PANELS MODEL Tiger Size 30’’ Finish St.steel Motor Extracting power (CFM) Voltage 110-120V ~ 60Hz Motor power consumption Product certification Product class Class I Type model PVWT930S1SV Air outlet diameter (mm) Controls Touch Control...

  • Page 9: Technical Data

    Technical data - 9 -...

  • Page 10: Parts Supplied

    Parts supplied CHIMNEY BRACKET NON RETURN VALVE AIR DEVIATOR (air recirculation option only) 2 CHARCOAL FILTERS (air recirculation option only) MOUNTING SCREWS - 10 -...

  • Page 11: Non-Return Valve Parts Supplied

    Non-return valve parts supplied The non-return valve (exhaust damper) is recom- mended when the appliance is installed in the ex- tracting version, to prevent cold air blowing back in from outside. The valve is made up of two parts which must be fixed to the air outlet flange on the motor assembly If the appliance is installed in the recirculation filte- ring version, the non-return valve is not necessary.

  • Page 12: Aluminium Panel Charcoal Filter

    Aluminium panel Charcoal filter Replacing the aluminium panel (a) 7.1 The metal filters and/or aluminium panel are also dishwasher safe. If the filters are made using aluminium, or if an alumi- nium panel is used, after a few washes the colour may chan- ge.

  • Page 13: Installation

    Installation CAUTION! Wear gloves during the installation of the product otherwise injury at fingers could happen by sharp edges. Fixing the appliance to a wall 8.1 Before starting to fix the hood, disconnect the anti-grease filter for easier appliance handing. Before this operation, per- form the following steps: Phase 1 Phase 1...
  • Page 14 Installation Phase 3 Phase 3 - Drill the holes A respecting the distances indicated. Fix the ap- pliance to the wall and align it in horizontal position to the wall units. ��� � Phase 4 Phase 4 - When the appliance has been adjusted, tightly secure the hood using the screws A.

  • Page 15: Fixing The Decorative Telescopic Flue 8.2

    Installation Fixing the decorative telescopic flue 8.2 Phase 1 Phase 1 - Arrange the electrical power supply within the dimensions of the decorative flue. If your appliance is to be installed in the ducting version or in the version with external motor, prepare the air exhaust opening.
  • Page 16 Installation Phase 3 Phase 3 (air recirculation option only) - Take the air deviator D and make two holes as shown in the photographs. Ø 6 - Secure the duct fixing bracket to the air deviator D as shown in the photograph. Phase 4 Phase 4 - Carry out final fixing of the air deflector D to the wall with a...
  • Page 17 Installation Phase 5 Phase 5 (air recirculation option only) - Connect the flexible pipe (not supplied) to the deviator D. - Fix the flexible pipe onto the connector flange G. Phase 6 Phase 6 - Take care not to scratch the duct; wear gloves when remov- ing the protective film.

  • Page 18: Installing The Charcoal Filters And Aluminum Panels 8.3

    Installation Installing the charcoal filters and aluminum panels 8.3 Phase 1 Phase 1 - Take the active charcoal filters and position them in their housings. Phase 2 Phase 2 - Take the aluminum panels and position them in their hou- sings.

  • Page 19: Control Drawing

    Control drawing � � � � � Configuration 9.1 Push-button A = On/off lights switch. Push-button B = On/off cooker hood switch. The appliance switches on at speed level 1, If the cooker hood is on depress the push-button for 2 sec. to switch off the cooker hood. If the cooker hood is at speed level 1 it will not be necessary to depress the push-button to switch the cooker hood off.

  • Page 20: Technical Drawing Of Control Board 9.2

    Control drawing Technical drawing of control board 9.2 - 20 -...

  • Page 21: Touch Control

    Touch Control Before carring out any kind of maintenance work, disconnect the appliance from the domestic electrical supply. Replacing the touch control 10.1 Phase 1 Phase 1 - Disconnect the aluminium panels. Phase 2 - Unscrew the two screws as shown in the picture. - Remove the lamp bracket holder.
  • Page 22 Touch Control Phase 3 Phase 3 - Unscrew the two screws indicated. Phase 4 Phase 4 - Cut the tie. - Unscrew the three screws as shown in the pictures and re- move the toch control support. - 22 -...
  • Page 23 Touch Control Phase 5 Phase 5 - Disconnect the flat cable. - Unscrew the screw and replace the Touch Control. - 23 -...

  • Page 24: Bulbs

    Bulbs Before carring out any kind of maintenance work, disconnect the appliance from the domestic electrical supply. Replacing the halogen bulbs 11.1 Phase 1 - To replace the halogen bulbs B, remove the glass cover C using a screw driver in the slots provided. Replace the bulbs with new ones of the same type.

  • Page 25: Replacing The Halogen Bulbs Socket 11.2

    Bulbs Replacing the halogen bulbs socket 11.2 Phase 1 Phase 1 - Before starting replacing the halogen unit, repeat phases 1 and 2 of the paragraph “Touch Control”. - Unscrew the two screws indicated. Phase 2 Phase 2 - Cut the tie. Phase 3 Phase 3 - Push the halogen bulb socket downwards and replace the...

  • Page 26: Transformer

    Transformer Before carring out any kind of maintenance work, disconnect the appliance from the domestic electrical supply. Replacing the Transformer 12.1 Before proceeding with replacement of the transformer, the following steps must be carried out: - lift up the lower duct A - secure the lower duct adequately with adhesive tape B to the upper duct.
  • Page 27 Transformer Phase 1 Phase 1 - Unscrew the 2 screws as shown in the pictures. Phase 2 Phase 2 - Unscrew the 2 screws as shown in the picture and remove the box. - 27 -...
  • Page 28 Transformer Phase 3 Phase 3 - Unscrew the 2 screws. Now you can replace the transfor- mer. Phase 4 Phase 4 - Unscrew the screw. - 28 -...
  • Page 29 Transformer Phase 5 Phase 5 - Disconnect all the cables and replace the transformer. - 29 -...

  • Page 30: Power Board

    Power board Before carring out any kind of maintenance work, disconnect the appliance from the domestic electrical supply. Replacing the power board 13.1 Before proceeding with replacement of the power board, the following steps must be carried out: - lift up the lower duct A - secure the lower duct adequately with adhesive tape B to the upper duct.
  • Page 31 Power board Phase 1 Phase 1 - Repeat the phases 1 and 2 of the paragraph “Transformer”. - Cut the tie and disconnect the cable. Phase 2 Phase 2 - Disconnect the cables. - Disconnect the plastic pins and replace the Power Board. ATTENTION! during the reassembling phases be carefull because there is only one correct way to connect the cables.

  • Page 32: Electrical Assembly

    Electrical Assembly - 32 -...

  • Page 33: Wiring Diagram

    Wiring Diagram - 33 -...

  • Page 34: Motor

    Motor Before carring out any kind of maintenance work, disconnect the appliance from the domestic electrical supply. Replacing the motor 16.1 Before proceeding with replacement of the motor, the fol- lowing steps must be carried out: - Remove the 2 srews B fixing the upper decorative duct A to the wall fixing bracket C.
  • Page 35 Motor Phase 1 Phase 1 - Unscrew the 6 screws as shown in the picture. Phase 2 Phase 2 - Cut the tie and unscrew the two screws. - 35 -...
  • Page 36 Motor Phase 3 Phase 3 - Take out the motor and unscrew the 4 nuts. Phase 4 Phase 4 - Unscrew the two screws. Open the connector housing and disconnect the connector. - 36 -...
  • Page 37 Motor Phase 5 Phase 5 - Remove all the screws indicated. - 37 -...
  • Page 38 Motor Phase 6 Phase 6 - Separate the RIGHT impeller housing from the LEFT Phase 7 Phase 7 - Remove the plugs from the motor support. Phase 8 Phase 8 - Remove the screws which secure the motor to the impeller housing.

  • Page 39: Condenser

    Condenser Before carring out any kind of maintenance work, disconnect the appliance from the domestic electrical supply. Replacing the condenser 17.1 Before proceeding with replacement of the condenser, the following steps must be carried out: - Remove the 2 srews B fixing the upper decorative duct A to the wall fixing bracket C.
  • Page 40 Condenser Phase 1 Phase 1 - Remove the motor following the steps indicated in the pre- vious paragraph (phases from 1 to 4). Phase 2 Phase 2 - Open the condenser housing. - Disconnect the condenser and replace it. - 40 -...

  • Page 41: Exploded View

    Exploded view Model: Tiger ���������� ��������������� �������� �� ��� �� ��� �� ��� ��� ��� �� ��� ��� ��� ��� ��� �� ��� ��� �� ��� ��� �� ��� ��� �� �� - 41 -...

  • Page 42: Spare Parts List

    Spare parts list Model: Tiger DESCRIPTION CODE POSITION SPL0000 PANEL SPL0072 LOWER CHIMNEY CONVEYOR SPL0728 SPL0733 FAN WHEEL SPL0487 MOTOR SPL0494 BODY SPL0493 CONTROL POWER CIRCUIT SPL0734 SPL0732 MOTOR GROUP SPL0737 STIRRUP SPL0024 UPPER CHIMNEY SPL0731 CAPACITOR SPL0736 CONNECTION BOX...

  • Page 43: Troubleshooting

    Troubleshooting ATTENTION! 1. The appliance has been manufactured as a class I. 2. Before carrying out any kind of maintenance job, disconnect the appliance from the domestic network supply. 3. Assembly and electrical connections must be carried out by specialized personnel. Electrical Malfunction SYMPTOM CAUSE...
  • Page 44 3LIS00__...
