d.gen TELEIOS GRANDE H6 Operator's Manual

Fixation unit textile printer
Hide thumbs Also See for TELEIOS GRANDE H6:

Advertisement

Quick Links

FIXATION UNIT
USER'S MANUAL
TELEIOS GRANDE H6

Advertisement

loading
Need help?

Need help?

Do you have a question about the TELEIOS GRANDE H6 and is the answer not in the manual?

Questions and answers

Related Manuals for d.gen TELEIOS GRANDE H6

Summary of Contents for d.gen TELEIOS GRANDE H6

  • Page 1 FIXATION UNIT USER’S MANUAL TELEIOS GRANDE H6...

  • Page 2: Table Of Contents

    TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com INDEX. 1. Important Safety Instructions ………………………………………………………………………………. 2. Instructions and considerations before installing the fixation unit ………………………………………. 3. Introducing the fixation unit ………………………………………………………………………………….

  • Page 3: Important Safety Instructions

    TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com 1. IMPORTANT SAFETY INSTRUCTIONS.  Improper handling or operation of this unit may result in injury or damage to property.  Read all of these instructions before using the fixation unit. Also, be sure to follow all warnings and instructions marked on the machine When choosing a location for this fixation unit.
  • Page 4 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com When using this fixation unit.  Keep children away from the unit. The machine includes areas and components that pose a hazard to children and may result in injury, blindness, choking, or other serious accident.

  • Page 5: Instructions And Considerations Before Installing The Fixation Unit

    TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com 2. INSTRUCTIONS AND CONSIDERATIONS BEFORE INSTALLING THE FIXATION UNIT.  Improper handling or operation of this unit may result in injury or damage to property.
  • Page 6 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com Suggestions.  Installation of a UPS (uninterruptible power supply) in areas where blackouts are common.  Installation of a voltage stabilizer to avoid electrical instability and noise in the electronic boards.
  • Page 7 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com How to position the fixation unit. The platform links the fixation unit with the printer. Make sure the distance between the printer and the fixation unit is the same at both sides.
  • Page 8 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com Use the unit’s stoppers to level up the fixation unit. Connect the fume buster to the fixation unit. d·gen International, Inc. - COMPANY PRIVATE (LEVEL 1) FOR THE USER NOT TO BE DISCLOSED TO UNAUTHORIZED PERSONS –...
  • Page 9 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com The fume buster is provided with a 5m long 2-inch duct. Connect this duct to the fixation unit. Recommended the use of a hose clamp.

  • Page 10: Introducing The Fixation Unit

    TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com 3. INTRODUCING THE FIXATION UNIT. Introducing the control panel. Green LCD screen. Fixation unit’s menu is displayed here. AUTO/MANUAL button. With this button is possible to select the mode between AUTO and MANUAL. AUTO mode basically turns off the heaters and the fume buster and lowers the up/down roller automatically after a certain adjustable time frame.
  • Page 11 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com Introducing the control panel. Fixation’s unit main switch. Turn clockwise the switch to turn on all the fixation unit. Turn counter-clockwise the switch to turn off all the fixation unit.
  • Page 12 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com Unit’s left side. Duct connection. The fume buster is provided with a 5m long 2-inch duct. Connect this duct to the fixation unit.

  • Page 13: How To Operate The Fixation Unit

    TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com 4. HOW TO OPERATE THE FIXATION UNIT. Turn on the fixation unit by turning clockwise the main switch. The green LCD display will show the welcome screen.
  • Page 14 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com Since this printer doesn’t have the ability to run the fixation unit in AUTO mode, we suggest to change it to MANUAL mode. By pushing the AUTO/MANUAL button is possible to make the fixation unit to work under MANUAL conditions.
  • Page 15 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com HEATER 1 SV. This is the temperature set value. Press ENTER and modify this value using the arrow keys (Left/right to change position and up/down to increase/decrease the value).
  • Page 16 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com Caution Before regulating values, we strongly suggest the user to check first under which conditions is the fixation unit working in. Either in AUTO or MANUAL mode.
  • Page 17 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com Lower the cursor until reaching the TAKE-UP function. Since the take-up unit is currently turned OFF an “X” is displayed next by the percentage RPM.
  • Page 18 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com Note Only possible to change the direction of rotation having the take-up in the OFF position. Turn off the take- up. Change direction and then turn on the take-up again.
  • Page 19 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com When the PV value reached the SV value you may raise the up/down roller. Move the cursor to ROLLER UP/DOWN and then press the ON/OFF button. The X will change to an O when the up/down roller reaches the highest point.

  • Page 20: Maintenance

    TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com 5. MAINTENANCE. To keep the fixation unit in a good condition we strongly recommend the operator to perform the following inspections and cleanings every certain period of time.
  • Page 21 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com Every day (Fixation unit) Machine’s exterior Strongly recommended to keep the machine’s exterior covers always free of dust, fabric line and intrusive objects.
  • Page 22 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com Once a week (Fixation unit) Keep the machine free of waste oil With the help of a wet soft cloth remove all the condensed oil.
  • Page 23 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com Every year (Fixation unit) General inspection and deep cleaning The general yearly cleaning and revision involves: Deep cleaning of the heating rods.

  • Page 24: Troubleshooting

    TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com 6. TROUBLESHOOTING. The fixation unit is not running. Make sure the power cable is securely plugged into the power source. Check the power source is supplying a stable three-phased + neutral 380 V.
  • Page 25 TITLE OPERATOR’S MANUAL PAGE DEVICE FIXATION UNIT (TELEIOS GRANDE H6) VERSION 2017JAN23/1 OUT OF REVISED BY MUNOZ, ANTONIO support@dgen.com When moving the up/down roller loud noises can be heard. Check the worm/endless screw or chain is very well greased. Grease the worm/endless screw or chain immediately.
