SolarEdge ZigBee Setting Up page 5

15 Select the Multi-Point Slave option from the Protocol
submenu.
16 Exit setup mode by pressing the ESC button few times.
17 Short press the LCD button to scroll through the
informative screens to show the ZigBee status window and
verify that you see the message ZigBee Ready.
For the master (main) device, select the following:
1 Repeat steps 1 through 7, as described above in the Slave
Configuration section.
For FW versions above 2.250, continue to step 5. For
earlier versions, complete steps 2 through 4 below.
2
Select the Bus submenu. Scroll down and select Zigbee
MP. The device performs a reset immediately after the
selection is made.
Bus Submenu:
Z i g b e e
> Z i g b e e
R S 4 8 5
R S 4 8 5
N o n e
3 Repeat steps 5 through 7 as described above in the Slave
Configuration section to enter Setup mode.
4
Scroll down to the ZigBee Conf submenu and select it.
Communication Submenu:
S e r v e r <
B u s < Z i g
L A N C o n
R S 4 8 5
> Z i g b e e
R S 2 3 2
M o d b u s
For FW versions earlier than 2.250, complete steps 7
through 8 below.
5
Scroll down to the Zigbee Conf submenu and select it.
Zigbee Conf Submenu:
D e v i c e
> P r o t o c o l
P A N I D
S c a n C h a n n e l
L o a d Z B
6
Select the MP Master option from the Protocol submenu.
P 2 P
M P
M a s t e r
S l a v e
L A N >
B e e >
f
C o n f < S >
C o n f < S >
C o n f
C o n f
T y p e < S E
< M P - M >
D e f a u l t s
18 Repeat steps 1 through 7 and 13 through 17 for all slave
devices.
This concludes the setting of the slave devices for FW version
2.250 and above.
7
Select the Slave Detect option and select Yes. The message
Detecting Slaves is displayed during the detection process,
as well as the number of detected slaves.
This procedure may take a few minutes. The master should
report the correct number of slaves on the LCD screen.
8
Press the ESC button repeatedly to exit the Setup menu.
This concludes the multi-device setup using the user
buttons.
NOTE FOR FW VERSIONS EARLIER THAN 2.250:
The master device sets the PAN ID for the detected slaves.Thus,on
FW versions earlier than 2.250, if you try to detect a new slave after a
successful pairing, you must reset the initial PAN ID for all slave
inverters by reconfiguring the slave inverters, as described in steps 1
through 12 in the slave inverter configuration.
The following steps are required if a connection to the
SolarEdge Monitoring Server is necessary (optional).
9 Enter Setup mode by repeating steps 5 through 7, as
described above in the slave configuration section.
10 Select the Server submenu, scroll down to the LAN option
and select it.
Server Submenu:
> L A N
R S 2 3 2
R S 4 8 5
Z i g b e e
N o n e
11 For FW versions above 2.250, press the ESC button
repeatedly to exit the Setup menu.
This concludes the server connection configuration using the
user buttons.
>
5
MAN-01-00027-1.3
