- Page 1 SDCP6 Wallplate Control Panel-6 buttons Program buttons to send TCP/IP and RS232 commands to control projectors, screens and other third-party devices. S h o w i n g t h e W o r l d VER 1.0...
-
Page 2: Table Of Contents
Use of surge protection systems is highly recommended in order to protect and extend the life of your equipment. Table of Contents 1. Introduction ......................... 1 1.1 Introduction to SDCP6 ..................1 1.2 Features ......................1 1.3 Package List ...................... 1 2. Panel Description ......................2 3. -
Page 3: Introduction
1. Introduction 1.1 Introduction to SDCP6 The Wallplate Control Panel has (3) built-in programmable RS232 connectors and (2) Infrared (IR) connectors. The Programmable Control Panel can fully control the compatible switches, as well as third-party devices such as matrix switcher, compact scaler switcher, projectors, screens, etc. Use the device for presentations in showrooms, classrooms, and boardrooms. -
Page 4: Panel Description
2. Panel Description ETHERNET SDCP6-EU SDCP6-UK 2/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 5 Micro USB port for updating firmware. Long-press this button 3 seconds until the power LED goes out to start to the restore factory defaults, and then the LED will light up while the RESET resetting is successful. 3/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 6: System Connection
3. System Connection The SDCP6 can activate different ports at one time. It means every button can send the RS232 commands, IR code at the same time. The demo system diagram as below: IR Emitter RS232 : TCP/IP: IR Remote... -
Page 7: Control Panel Software
You can use Control Panel Software to easily set functions for every button. ① Connect the control PC to the ETHERNET port. ② The default IP of SDCP6 is 192.168.0.178 (modifiable), the control PC should be set its network segment to the same as the SDCP6’s. Same network segment as the... - Page 8 Show IP addresses of Show all key actions, and to set key action all connected devices any action can be in LAN. selected for setting events. Set events for the selected action. Show all events. 6/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
- Page 9 User ID (admin) and Password (123456) → upload update file → Click “Upload” ◆ Click “System” → “Factory Defaults” to restore factory defaults. ◆ Click “Connection” → “TCP/IP” → “Reconnect” to reconnect all SDCP6. ◆ Click “Connection” → “Upload” → to load the MCU information from the selected SDCP6 to control software.
-
Page 10: Panel Set
Total 6 customizable buttons on the front panel can be set via this software. Add a button action to show on the action list, and then add events to make this action execute the events. Here set one button for example: 8/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 11: Action List
Keys 1-6, correspond to the buttons on SDCP6. Click the key 1, it will pop up dialog as below: Key Type: Press: Execute events when pressing the button. Release: Execute events when releasing the button. Toggle: The button can be... -
Page 12: Event Setting
Select the RS232 port. The port must be same as model setting, otherwise the event cannot be added. ④ Confirm and set the baud rate, data bit, stop bit and parity. ⑤ Enter RS232 command in data box, and then press “add” to save setting. 10/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 13 Note: Once set up, please press “Save” to save the editing or “Save as” to save as a file, and then press “OK”. ⑦ There are two delay send: Set and None. When select “Set”, the number of sending strings and the delay time between strings can be set. 11/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 14: Ir Setting
4.4.2 IR Setting This item is used for setting the events for IR (1) ~ IR (2) ports. Click “IR”, it will show as below: 12/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 15 Click “learn” to enter IR learning mode. Put the IR Remote close to the IR sensor of SDCP6 Press any button on the IR Remote to send the IR code to IR sensor, and it will refresh the IR data.
- Page 16 ⑥ There are two delay send options: Set and None. When select “Set”, the number of sending strings and the delay time between strings can be set. 14/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 17: Tcp/Ip Setting
4.4.3 TCP/IP Setting The Ethernet port supports pass-through function. You can set the events for different IP port via commands. Type the IP address of the device need to be set. Type the control command. 15/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 18: Delay Setting
This item is to add a delay between two events; so when one event is finished, it will delay a certain time then start next event. The delay setting is as picture below: Hour: 0~24; Minute: 0~60 Second: 0~60 16/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 19: Compare Setting
4.4.5 Compare Setting This item is used to compare the feedback of RS232 commands. When SDCP6 sends an RS232 command to the controlled device, the device will send back a feedback. If we add the correct feedback in the data, SDCP6 will compare it with the feedback received from controlled device, to verify the command is working or not. -
Page 20: Led Setting
4.4.6 LED setting This item is used for setting the button LEDs in SDCP6 to turn on/off. The setting is as below: On: Turn on the LED of button 1; Off: Turn off the LED of button 1; On/Other Off: Turn on the LED of button 1, and turn off others. -
Page 21: Toggle Setting
The key type can be set as “Toggle”, in this type, the button can be regarded as a composite key. Here is an example to show you the use of this function: Operation procedure: ① Take Key 1 for example, click “1” and select the action type “Toggle”. 19/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 22 ② Add toggle & RS232 events for the Key 1. 20/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
-
Page 23: Event List
The event list shows all events of the selected action. The executing priority abides by the serial number, see the picture below. If there is an event execute incorrectly, all the events behind it will not be executed. Delete the selected event. Adjust the execution order for events. Empty all events. 21/23 Website: www.seada.co.uk E-mail: sales@seada.co.uk... -
Page 24: Specification
3 x 3-Pin Pluggable terminal blocks, Output Connector 2 x 2-Pin Pluggable terminal blocks, 9600 baud, 8 data bits, 1 stop bit, no Baud Rate and Protocol parity Software SDCP6 Power Consumption 1W (Max) 0 ~ +40℃ Operation Temperature -10 ~ +55℃ Storage Temperature... -
Page 25: Panel Drawing
6. Panel Drawing 80 mm 48 mm ETHERNET SDCP6-EU 23/24 Website: www.seada.co.uk E-mail: sales@seada.co.uk... - Page 26 146.00 mm 59.50 mm 3.00 mm 36.80 mm SDCP6-UK 24/24 Website: www.seada.co.uk E-mail: sales@seada.co.uk...
