Wall Mount 44-Piece Tool and
Parts Bin Rack
User Guide
Safety
• This unit is not a toy and should be kept out of the reach of children.
• Small parts are included that may pose a choking hazard to children and animals. Keep parts away from children
and pets.
• Before assembly, ensure there are no missing or defective parts. Contact the retailer if any parts are missing or
defective.
• Assemble only as instructed in this guide. Any deviation or shortcut may lead to incorrect assembly or be
considered customer misuse. Improper assembly may cause damage or serious injury.
• Do not mount the unit to a vehicle.
• Do not over-tighten mounting screws or parts during assembly as this may damage the unit.
WARNING
• The unit should only be mounted on a flat, perpendicular and stable surface.
• Do not exceed the maximum load capacity as this may result in damage or serious injury. Load capacity
depends on the mounting surface and number of fasteners used.
• For stability, heavier items should always be placed lower on the racks.
• Do not rest or support items against or on the unit.
CAUTION
• To ensure continued safety, regularly check that the unit is secure and safe to use (every 3 months). Take
appropriate action to rectify any unstable or unsafe units.
• If you do not understand this guide, or have any doubts regarding safety of the assembly, seek advice and
guidance from a qualified person.
• Appropriate protective equipment, such as safety glasses, must be worn and precautions taken when installing this
product.
• It is recommend that two persons install the unit.
• Before installation, ensure the supporting surface will safely support the combined weight of the unit and all stored
items. If unsure, contact a qualified contractor for guidance.
Cleaning and Care
Clean the unit using a damp cloth. Avoid using harsh or abrasive chemicals as this can damage surface finishes.
Included Items
1. Peg Board x2
2. 40mm Hook x6
3. 30mm Hook x4
4. Drill Holder x1
5. Wrench Holder x2
6. Universal Tool Holder x1
7. Small Bin x16
8. Medium Bin x8
9. Large Bin x4
10. Mounting Screw / Wall Plug x16
Note: Tools and accessories not included.
Advertisement
Related Manuals for Baumr-AG STRBRKBMRAW28
Summary of Contents for Baumr-AG STRBRKBMRAW28
- Page 1 Wall Mount 44-Piece Tool and Parts Bin Rack User Guide Safety • This unit is not a toy and should be kept out of the reach of children. • Small parts are included that may pose a choking hazard to children and animals. Keep parts away from children and pets.
- Page 2 Assembly Hold a peg board (1) in position on the wall/mounting surface (A). Ensure that the peg board is level. Using a pencil or other device, mark out the mounting holes on the wall / mounting surface. Alternatively, measure the peg board mounting hole centres and mark out accordingly.
- Page 3 Some experts believe that the incorrect or prolonged use of almost any product may cause serious injury or death. To help reduce your risk of serious injury or death, refer to the information below. For more information, see www.datastreamserver.com/safety ...
