Safety
Read and understand this user guide before using the equipment. Retain the user guide for future reference.
Any damage or equipment failure due to incorrect usage is not covered by
• Do not modify or use the tool for any other purpose than that it is designed for.
•
Keep work areas clean, well lit and well ventilated.
•
Do not use tools / electrical appliances in wet or damp conditions. Do not expose tools to water or rain.
•
Do not operate the equipment if it is damaged, malfunctioning or is in an excessively worn state.
•
Do not operate the equipment in flammable or explosive environments, such as in the presence of
flammable liquids, gases or dust.
•
This equipment must be used on flat, level and stable surfaces only. Do not use if it is unsteady.
•
Stay alert and use common sense when operating equipment. Do not overreach. Keep proper footing and
balance at all times. Do not use equipment when tired or under the influence of drugs, alcohol or medication.
This equipment is not intended for use by persons with reduced physical, sensory or mental capabilities.
•
You must wear appropriate protective equipment when operating, servicing, or when in the operating area
of the equipment to help protect from serious injury, including eye injury, inhalation of toxic fumes, burns, and
hearing loss. Always wear eye protection. Protective equipment such as respirators, non-skid safety shoes,
hard hat, hearing protection etc should be used for appropriate conditions. Other people nearby should also
wear appropriate personal protective equipment. Do not wear loose clothing or jewellery, which can be caught
in moving parts. Keep hair and clothing away from the equipment.
•
This equipment is for domestic use only.
Parts Identification
1 Mitre Saw Stand Assembly (1)
2. Length Adjust Lock Knob (4)
3 Height Adjust Lock Knob (2)
4 Work Support (2)
5 Tool Mounting Clamp (Left / Right)
6 Tool Mount Rail (2)
7 Bolt / Nut / Washer (4) [Long]
8 Bolt / Nut / Washer (4) [Short]
Note: Before use, ensure that all parts
have been supplied. • The maximum
mounting hole centre distance for the saw
is 374mm
374mm Max.
6
4
2
3
1
warranty.
2
5
7
8
4
3
5
