Summary of Contents for Cycjet ALT382
- Page 1 ALT382 HANDHELD INKJET PRINTER MANUAL SHANGHAI YUCHANG INDUSTRIAL CO., LTD.
-
Page 2: Table Of Contents
2.1.6 “date time’ 2.1.7 “calibrate” 2.1.8 “idle jet” 2.1.9 “counter continue” 2.2 <Parameter> 2.3 <Print> 2.4 <Browse> 2.5 <Edit> Image file Create “bar code” Create “date/time/serial No./ shift group Text&Text Feature Module operation Eliminate Troubles Daily Maintenance Manual of ALT382... -
Page 3: Declare
Our company reserves the right of update at any moment, and unnecessary to notify the users. Copyright reserved by CYCJET. Any unauthorized reproduction, articles picked or other non-approved usages shall bear the legal liability. * NOTE: After 5 minutes non-use, it’ll turn on blank screen saver automatically. -
Page 4: Safety Instruction
6、 Damages caused by incorrect operation of non-approved people . 7、 Damages caused by the Force Majeure. Environmental Protection Dispose of the waste inks & cleaners shall be in accordance with Local Authority Regulation. The wastes are not allowed into the sewer system. Manual of ALT382... -
Page 5: Packing List
Packing List Name Quantity Handheld ink-Jet Printer 1 PC Intellectual Charger 1 PC Touch pen 1 PC Manual 1 Copy Manual of ALT382... -
Page 6: Technical Data
Inks: Porous ink, Non-porous ink, UV anti-counterfeit inks, food grade ink, invisible ink etc. Inks color: red, yellow, blue, green, black, white etc. Through USB interface to import single color bitmap. It can be operated by mouse. Manual of ALT382... -
Page 7: Environment/Electrical Requirement
Environment/Electrical Requirement Electrical requirement：AC100-240V± 10% 50/60Hz,connect the ground cord. Max Power：30W (average﹤15W) Temperature：5-40℃ Humidity：10-90%(non-condensing) Electromagnetic interference: far away from electromagnetic radiation zone Manual of ALT382... -
Page 8: Install & Test
5、 Printhead Installation: 1) put the aluminum stick into the two-hole aluminum stand, and fastened by starlike screw. 2) Screw the printhead on aluminum stick. 3) Connect one side of ink tube to filter and the other side to ink inlet. Manual of ALT382... - Page 9 In principal, the distance between product and print head more closely, the printing result will be better. 10、Production Line adjustment: more details see page10. Manual of ALT382...
-
Page 10: Switch On/Off
Switch off： Press the power button off and cover up the print head cap. Note: Before switch off, ensured the printhead in normal condition. Forbid to purge printhead gap before/after switch off! Just sealed by cap! Manual of ALT382... -
Page 11: Operation
●The switch of modes is located in the top part of the screen and contains 5 buttons. <System> - The basic management in printer <Param> - Management in parameters of current printing content; <Print> - Carry on printing task <Browse> - select the saved printing files <Edit> - Edit printing content Manual of ALT382... -
Page 12: Authority
<Edit> mode will be locked. “High”- the second level protection – at activation of the admin function, without password, just can operate<Print> mode. Final value should be confirmed with button “OK”or the reference value is returned by button “Cancel”. Manual of ALT382... -
Page 13: Date Time
<Residual Frames> - Shows can print How many times of current printing content with one liter ink. 2.1.4 “Date Time” – click the button<Date Time> to open screen as photo7 Photo 7 Adjust Date Time by <Year,Month,Day,Hour,Minute,Second >. Perform Idle-Jet Final value should be confirmed with button “Adjust”or returned by button “Close” Manual of ALT382... -
Page 14: Idle Jet
Counter Continue - see photo3. When printing serial number, it can be changed along with printing times. No matter the printer is switch off or printing other documents at the moment, the serial number will be continuing. Manual of ALT382... -
Page 15: Print
Select filename on your request and click the OK key to complete files replacement. Delete useless files to enlarge the storage space. If you do not want to replace printing files, please click the Cancel key to exit system. Note：The deleted files are unrecoverable, please be cautious before delete files. Manual of ALT382... -
Page 16: Edit
If you want to print with a picture, please click "Image File" firstly. Then choose an image file which is saved in the printer from the dialog box. Then click OK. Pic 16 Note: Image file can only be single color BMP file. Manual of ALT382... - Page 17 Please select the bar code type and input content; otherwise it will select CODE128 automatically. Input spaces respectively:Prefix,variable values 1;infix,variable values 2,suffix.The remaining parameters setting mode like with the fixed bar code Manual of ALT382...
- Page 18 If you want to generate a Serial No, click select format of Serial No in the dialog box, click OK for certain. Click ,choose font in the dialog box, then you can edit the font of the serial no. Manual of ALT382...
- Page 19 Pic 25 If you need to generate a text, please click icon ,then a dialogue box of property will shown up. Click the edit box to input the content that you want to print with the keyboard. Manual of ALT382...
-
Page 20: Module Operation
If you need to create a negative print result, please click “revert” icon and confirm with button “OK”. Pic 28 Module operation Module operation can work together with "Edit" to work out with perfect printing result. 、location adjustment 、 、 、 、Setting 、 5 main items：Select 。 delete Manual of ALT382... - Page 21 3.“Property”：Choose the text you want to print firstly and then click to change the property of the text. Pic 30 2、 “Delete”：Choose the text you want to print firstly and then click to delete the text. Pic 32 Manual of ALT382...
- Page 22 Operation 5.“Rotate”：Choose the text you want to print firstly and then click，to 90 degree counterclockwise rotate the text Pic 33 Note: Module operation can work together with "Edit" to create perfect printing quality and superior anti-counterfeiting performance. Manual of ALT382...
- Page 23 Purge or replace the blocked part. cartridge; injector, filter printhead is blocked. Ink cartridge is too thick or Replace a new ink cartridge and useless squeeze it Working condition temperature The working condition temp, should be higher than 5℃ is too low Manual of ALT382...
- Page 24 The normal value of speed rate is small around in 8, the value is smaller, the printed file is shorter. Product moving speed is too Slow down the moving speed. The fast. Manual of ALT382...
- Page 25 2.After purged printhead, please press the ink cartridge and clean up the leaking ink by soft napkin or lint free cloth. The dried ink can protect the printhead, however the dried cleaner cannot! Please do not purge printhead after power off. Just covered by cap!!! Manual of ALT382...
-
Page 26: Daily Maintenance
6. Replace the filter each two years as per inks usage. The maintenance terms stipulated in contract is base on this manual. Please read it carefully. Thanks for reading. If you have any questions or problems cannot solve, please consult supplier immediately!!! Manual of ALT382...
