E
1-2-3 Q
S
G
ASY AS
UICK
ETUP
UIDE
This guide will cover all the necessary steps to quickly configure, install and troubleshoot
SilverNet PRO Range equipment. It will be split into 3 sections: Installation, Configuration
and Common Problems.
S
1: I
ECTION
NSTALLATION
Before beginning to install or configure a link, you must ensure all the necessary equipment
is in the box. Below is an attached picture of what a SIL-MICRO-95 box will look like and what
is contained within:
The box should contain the following: 1x Radio, 1x PoE Injector, 1x IEC Power Cable, 1x SIL
MNT3 Mounting Bracket Set and 1x Cable Gland.
Next, you will need to assemble the bracket to mount the radio. When fully assembled and
mounted correctly, the bracket should look like the following:
V1.0
www.silvernet.com
Advertisement
Related Manuals for SilverNet PRO Series
Summary of Contents for SilverNet PRO Series
- Page 1 ASY AS UICK ETUP UIDE This guide will cover all the necessary steps to quickly configure, install and troubleshoot SilverNet PRO Range equipment. It will be split into 3 sections: Installation, Configuration and Common Problems. 1: I ECTION NSTALLATION Before beginning to install or configure a link, you must ensure all the necessary equipment is in the box.
- Page 2 Now you need to run an outdoor shielded grade network cable through the cable gland as shown: And finally, using the PoE Injector, power your radio as shown: Power Cable Cable to Radio Network cable Your radio should now power on and you should notice the Ethernet LED indicator come on and start to blink.
- Page 3 To quickly configure as easy as possible, you will need to download and install SilverView. You can find this on our website under the following link: https://www.silvernet.com/support/downloads-centre/ Once SilverView has been installed, open it and login with the following details:...
- Page 4 You can also double click the unit to open it in a web browser and access it via the web GUI. (note your PC will need to be on the same subnet mask as the radio to view the page). Optimal settings of an Access Point Optimal Settings of a Station Easy as 1-2-3 Quick Setup Guide...
- Page 5 3: C OMMON ROBLEMS Below is a list of some common problems and how to resolve them; a) Line of Sight – The radios work best when they have absolute clear line of sight. If the radios don’t have a clear line of sight then you will experience poor signals and unstable connections, or potentially no connection at all.
- Page 6 d) Interference - Our radios use auto-channel select and should avoid interferences as best as possible. Rebooting the radios will allow a re-scan and re-selection of the channel if there is a better one available. If you are experiencing interference problems when using the radios, then please try each of the channels until you find one that gives you a better link quality.
- Page 7 Upload the 0.228 config onto one radio and the 0.229 config onto the other. k) Manual – Read the manual for detailed explanations of the SilverNet equipment. This can be downloaded from our website.
