SilverNet Access 1200 Quick Install Manual

Quick Install Guide
Indoor Wireless Access Point (Access 1200)

1. Network Topology

• A DHCP-enabled network (for the AP to obtain
an IP address as well as for the wireless clients
after deployment)
• For MESH network, MC or Cloud manager running as
a Controller.
After you have powered on the device, please check the LED status
*
Indicator Name
Power LED
WAN LED
LAN LED
Signal Strength Increases from left to right
2 . P a c k a g e C o n t e n t s
Quick Install Guide
•
24V 1A GE Passive PoE Adapter
•
M3x20 Self Tapping
•
Screw (Qty. 3) • M3x20
Screw Anchor (Qty. 3)
M3x30 Flat Head Screw (Qty. 3)
•
M3 Nut with Tooth Washer (Qty. 3)
•

3. Computer Configuration

Set your IP address to 192.168.1.100 and change
the Subnet Mask to 255.255.255.0
* The IP address of the computer can be any IP from
192.168.1.2 to 192.168.1.254
Open the web browser. At the Address bar, enter the
IP address of the access point 192.168.1.1 then
press "Enter" on the keyboard.
Enter the default user name and password
Username: admin
Password: password
* Remember to change your password for security purposes.
Download the User Manual and the latest firmware at:
http://www.silvernet.com
Normal Status
continuously on
continuously on
continuously on/Flashing

4. Mounting

Wall-Mount

Step 1. Align the Wall-Mount Bracket with the Wall Mount text
facing up. There are horizontal and vertical lines on the bracket to
help with orientation.
Step 2. Use a pencil to mark the holes on the wall.
Step 3. Use a 6mm drill bit to drill the holes in the wall.
Step 4. Insert the 3 M3x20 Screw Anchors into the wall.
Step 5. Secure the Wall-Mount Bracket to the wall by inserting the
M3x20 Self Tapping Screws into the anchors.
Step 6. Align the notches on the AP with the notches on the Wall-
Mount Bracket.
Step 7. Turn the AP clockwise until it locks into place.

Ceiling-Mount
