Fig. 4

Camera

Transceiver

PoE

Long Range Ethernet Adapters

Camera

Extends Ethernet approx. 500m

NetWay8G - Front Panel

Ethernet Switch

Configuring NetWayG for Network Connection

Please be sure to visit altronix.com for latest firmware and installation instructions

Factory Default Settings

• IP Address:

• User Name:

• Password:

1 . Set the static IP address for the laptop to be used for programming to the same network IP address as the

NetWayG . The default address of the NetWayG is 192 .168 .168 .168, E .I . 192 .168 .168 .200 .

2 . Connect one end of the network cable to the network jack on the NetWayG and the other to the network

connection of the laptop .

3 . Open a browser on the computer and enter "192 .168 .168 .168" into the address bar . A dialog box

Authentication Required will appear requesting both user name and password .

Enter the default values here . Click on the button labeled Log In .

4 . The status page of the NetWayG will appear . Click on the tab labeled Network Settings . This will open

the Network Setting screen . In this screen the MAC Address of the NetWayG module will be found along

with the Network Settings and Email Settings .

Network Settings:

In the IP Address Method field select the method that the IP Address for the NetWayG will be obtained

(STATIC or DHCP), then follow the appropriate steps .

Static:

A . IP Address: Enter the IP address assigned to the NetWayG by the network administrator .

B . Subnet Mask: Enter the Subnet of the network .

C . Gateway: Enter the TCP/IP gateway of the network access point (router) being used

(gateway configuration is required to properly receive emails from the device) .

D . HTTP Port: Enter the HTTP port number assigned to the NetWayG module by the network

administrator to allow remote access and monitoring . The default inbound port setting is 80 . HTTP

is not encrypted and unsecure . Even though HTTP can be used for remote access, it is recommended

primarily for use with LAN connections .

E . HTTPS Port: Enter the HTTPS port number assigned to the NetWayG module by the network

administrator to allow remote access and monitoring . The default inbound port setting is 443 .

Being encrypted and more secure, HTTPS is highly recommended for remote access .

F . Click the button labeled Submit Network Settings . A dialog box will display "New network settings

will take effect after the server is rebooted" . Click OK .

- 6 -
