Jupiter System Operating Instructions Manual page 8

Operating Instructions Grain Mill Attachment
Messerschmidt system
A
B
C
I J K
R
Disassembly before first use
• Disassemble the milling head before first use for clean-
ing (see section
Cleaning
Unscrew the sealing ring
1
housing N .
Remove the setting unit
2
Remove the grinding cone
3
screw M from the housing
Assembly/disassembly
1 Push the screw M , leading with the plastic connector,
into the housing until it reaches the end stop.
N
Insert the grinding ring
2 L
Important: Note the flattened side of the grinding ring.
The grinding ring must fit precisely into the recess on
the housing.
Place the grinding cone
3
The square shaft of the grinding cone must
Important:
sit in the screw. The square mounting of the screw must
be completely free of residue.
Place the setting unit on the housing
4 J
Important: The notch of the setting unit must point
downwards and sit over the small raised area in the
housing. The flour outlet will then point downwards.
5 Screw the sealing ring I
Attach the filling hopper
6
• It can be disassembled using the same steps in reverse
order.
8 Subject to technical changes without notice; no responsibility is accepted for the accuracy of this information.
A
L M N
).
counter-clockwise from the
I
.
J
, grinding ring
K L
N .
into the housing .
N
on the grinding ring .
K L
.
N
clockwise onto the housing
.
A
Setting the milling grade
• Set the desired milling grade during the milling process
using the knurled knob
Finer
IMPORTANT:
• The square mounting of the screw must be completely
free of residue. Otherwise, it is not possible to set the
milling grade to fine.
• Always select a coarse setting before and after use.
• Do not use force when turning the knurled knob
• Use the finest milling grade for wheat only.
• Avoid an extremely fine setting.
and
N .
(Steel Cone Grinder)
.
R
Coarser
R .
