This hard disk drive unit is made by Pro-face for use with its panel-type computers,
hereafter referred to as the "PL". This 2.5 inch 20GB hard disk is designed to be
installed inside the PL.
Corresponding PL units: PL-5900/PL-5910/ PL-X900/PL-X920 Series units
(All product names that appear in this guide are the trademarks of their re-
spective companies)
Pro-face: Digital Electronics Corporation (in Japan and other countries)
MS-DOS, Windows: Microsoft Corporation (USA)
• Be sure to check that the PL's power is disconnected before
installing the unit, in order to prevent an electrical shock.
• Do not attempt to modify or open the PL-HD220, since it can
cause a shock or fire.
• When installing the PL-HD220, be sure to read the following "3.
Installation" section's information completely to insure that the
unit is correctly installed.
To Prevent Accidents
• Since the PL-HD220 is a precision instrument, be sure it is neither hit by nor pressed
strongly against another object. After unpacking, be sure the unit is not dropped or
jolted during installation. Also, a PL built in to a larger unit (i.e. operation panel)
should be removed and packed separately prior to shipping.
• Be sure water, liquids or metal particles are not allowed to enter the PL-HD220. Any
of these may cause either a breakdown or an electrical shock.
• Do not place or store this unit in a location where there is direct sunlight, excessive
heat, dust or vibration.
• Do not store or operate this unit near chemicals, or where there are chemical fumes.
• Do not allow anyone other than Pro-face's own service staff to perform mainte-
nance or adjustments to this unit.
• Do not move or shift the PL while the PL-HD220 is installed and the PL unit's power
is ON.
PL-HD220

WARNINGS

WARNINGS
-1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PL-HD220 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-face PL-HD220

Summary of Contents for Pro-face PL-HD220

  • Page 1 • Do not allow anyone other than Pro-face’s own service staff to perform mainte- nance or adjustments to this unit. • Do not move or shift the PL while the PL-HD220 is installed and the PL unit's power is ON.

  • Page 2: Package Contents

    • Do not use the PL-HD220 in locations where corrosive gasses are present, since they can lead to a hard disk breakdown. • To prevent damage to file data, be sure to shut down the PL unit's OS before turning OFF the main power.
  • Page 3 Environment Operating Temperature C to 50 Storage Temperature C to +60 10%RH to 85%RH (no condensation, Ambient Humidity Wet bulb tempertature: 29 C or less) Noise Resistance Noise Voltage: 1500Vp-p Pulse Width: 50ns, 500ns, 1 µ s (via Noise Simulator) Electrostatic Discharge Immunity Vibration Resistance...
  • Page 4 Hard Disk Unit Settings The PL-HD220 is factory set for use as the PL's Slave drive (Second Hard Disk). When using the PL-HD220 as the PL's Master dirve (First Hard Disk), be sure to perform the following setup. • All Pro-face PL units have a built-in hard disk. This hard disk, when shipped, is set as the PL's Master.
  • Page 5 Installation Use the following steps to install the PL-HD220 in the PL. Even though the unit shown below is a PL-X900 Series unit, the PL-5900, PL-5910 and PL-X920 Series installation procedures are the same. WARNINGS WARNING Shock Danger! Be sure to unplug the PL unit from its power supply prior to installing the PL-HD220.

  • Page 6: Hardware Setup

    Hardware Setup • Normally, the factory default settings should be used. • Certain BIOS screen items may differ from those shown here due to new versions. All the following explanation screens use the PL's factory settings (default settings). When using a PL-X900 series unit: Connect a keyboard to the PL.
  • Page 7 4) Confirm that both the C and D drives are set to [Auto]. If [Auto] is not selected, be sure to change this setting to [Auto]. This designates that when the PL is started up, the hard disk's parameters are automatically read out and used. The [Auto] setting is factory set and recommended for most users.

  • Page 8: Software Setup

    Please be aware that Digital Electronics Corporation shall not be held liable by the user for any damages, losses, or third party claims arising from the uses of this product. Digital Electronics Corporation 8-2-52 Nanko Higashi, Suminoe-ku, Osaka 559-0031, Japan URL: http://www.pro-face.com/ © 2000 Digital Electronics Corporation All rights reserved.
