The PSA-HD20 is made by Pro-face for use with PS-3700A Series (hereafter referred
as the "PS-A") units. This 2.5 inch 20GB hard disk is designed to be installed inside
the PS-A unit.
Corresponding units: PS-3700A Series units
(All product names that appear in this guide are the trademarks of their re-
spective companies)
Pro-face: Digital Electronics Corporation (in Japan and other countries)
MS-DOS
®
, Windows
• Be sure to check that the PS-A unit's power is disconnected
before installing the unit, in order to prevent an electrical shock.
• Do not attempt to modify or open the PSA-HD20, since it can
cause a shock or fire.
• When installing the PSA-HD20, be sure to read this guide's "2.
Installation" section's information completely to ensure that the
unit is correctly installed.
To Prevent Accidents
• Since the PSA-HD20 is a precision instrument, be sure it is neither hit by nor pressed
strongly against another object. After unpacking, be sure the unit is not dropped or
jolted during installation. Also, a PS-A unit built in to a larger piece of equipment (i.e.
operation panel) should be removed and packed separately prior to shipping.
• Be sure water, liquids or metal particles are not allowed to enter the PSA-HD20. Any of
these may cause either a breakdown or an electrical shock.
• Do not place or store this unit in a location where there is direct sunlight, excessive heat,
dust or vibration.
• Do not store or operate the PSA-HD20 near chemicals, or where there are chemical
fumes.
• Do not allow anyone other than Pro-face's own service staff to perform maintenance or
adjustments to the PSA-HD20.
• Do not move or shift the PS-A unit while the PSA-HD20 is installed and the PS-A unit's
power is ON.
• Do not use the PSA-HD20 in locations where corrosive gasses are present, since they
can lead to a hard disk breakdown.
• To prevent damage to file data, be sure to shut down the PS-A unit's OS before turning
OFF the main power.
• To prevent HDD memory leaks, restart the OS periodically.
• In order to extend the lifetime of the hard disk, Pro-face recommends you set the Win-
dows [Control panel]-[Power Management option]-[Turn off hard disks] selection to
turn the hard disk off when the unit is not being operated. A setting of 5 minutes is
recommended.
Preface
®
: Microsoft Corporation (USA)
WARNINGS
WARNINGS
E-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSA-HD20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-face PSA-HD20

Summary of Contents for Pro-face PSA-HD20

  • Page 1 • Do not allow anyone other than Pro-face’s own service staff to perform maintenance or adjustments to the PSA-HD20. • Do not move or shift the PS-A unit while the PSA-HD20 is installed and the PS-A unit's power is ON.

  • Page 2: Package Contents

    Installation Guide (this guide) Installation Guide Pro-face has taken the utmost care to insure the quality of this product when it was shipped, however, should for any reason problems or damage have occurred during shipping, please contact your Pro-face representative immediately for service.
  • Page 3 HDD data to either a floppy disk, or other type of suitable magnetic media is strongly recommended. • The PSA-HD20 has a finite usage lifetime. The lifetime figure given in this document is for reference, and the periodic replacement of the current HDD unit with a new HDD unit is strongly advised.
  • Page 4 Installation Be sure to use the following installation procedures to insure that the PSA-HD20 is correctly installed. Installation location will differ depending on the type of PS-A unit you are using. WARNINGS WARNING Shock Danger! Be sure to unplug the PS-A unit from its power supply prior to installing the PSA-HD20.
  • Page 5 A unit. IDE I/F 3) Insert the PSA-HD20 cable connector completely into IDE I/F. 4) Attach the PSA-HD20 using the four (4) attachment screws. (See diagram) The torque should be 0.5 to 0.6 N•m. 5) Replace the PS-A unit's Rear Cover and reattach eight (8) attachment screws.

  • Page 6: Hardware Setup

    Hardware Setup • Normally, the factory default settings should be used. • Certain BIOS screen items may differ from those shown here due to new versions or the PS-A unit you are using. All the following explanation screens use the PS-A unit's factory settings (default settings).

  • Page 7: Software Setup

    Software Setup After completing the hardware setup, in order to save data and application(s) to the ® ® HDD, use your OS (MS-DOS or Windows ) to create partitions and format (initial- ize) the unit. Please consult your OS’s operation manual for details about these proce- dures.
  • Page 8 Please be aware that Digital Electronics Corporation shall not be held liable by the user for any damages, losses, or third party claims arising from the uses of this product. Digital Electronics Corporation 8-2-52 Nanko Higashi, Suminoe-ku, Osaka 559-0031, Japan URL: http://www.pro-face.com/ © 2003 Digital Electronics Corporation All rights reserved.
