AERF WIRELESSBAND 1.0 SLIM Instruction Manual

EN
IP55 2 yrs
100m 1 Ch
Output
Battery

1. GENERAL

One channel wireless system communication for either resistive, mechanical and pneumatical safety edges.
Important:
- Insert battery 1 first and then battery 2! Unless this order is observed, correct function is not guaranteed. The batteries must be suitable for use at
temperatures of -20°C and above

1.1 SAFETY INSTRUCTIONS

- Reaction time < 60ms (according TÜV test report AV86368T Certificate nº M6A 14 12 90800 001)
- EN13849-1 Cat2 PL-C with TEST.
- Device with SELV/PELV Power Supply

2.1 TRANSMITTER

4
4
3 3
7
7
6
6
5
5

2.1.1 TRANSMITTER REGULAR CONNECTIONS

1 2 3
1 2
Safety
Common Inhibitor
Edge
Safety
Common
Edge
Select from 8K2 or mechanical safety
Resistive Safety Edge 8K2 or
edge in transmitter options (option 1)
Mechanical Safety Edge
(Choose in transmitter options (Option 1))

2.1.1 OTHER TRANSMITTER CONNECTIONS

1 2 3
1 2 3 4
Safety
Common Inhibitor
Edge
Safety
Com Com Inhibitor
Edge
Resistive Safety Edge 8K2 or
Select from 8K2 or mechanical safety
Mechanical Safety Edge
edge in transmitter options (option 1)
(Choose in transmitter options (Option 1))

2.1.3 TRANSMITTER OPTION SELECTOR

ON
Resistive safety edge
SAFETY EDGE 1
1 2
TYPE ON
Contact safety edge
1 2
ON
869,85 Mhz (setting MUST match that of receiver)
2
TRANSMITTER
1 2
ON
FREQUENCY
868,95 Mhz (setting MUST match that of receiver)
1 2
WIRELESSBAND 1.0 SLIM
Instruction Manual
(WIRELESSBAND 1.0 SLIM) (WIRELESSBAND 1.0)
14 tx
1
1
1- Terminals
2- Battery1 CR2032
3- Battery 2 CR2032
2 2
4- LED
5- DIP - Switch
6- Push button
7- Antenna
Contact Inhibition
Contact Inhibition
TÜV Certificate nºM6A 14 12 90800 001

2.2 RECEIVER

3
6
4
2
7
5

2.2.1 RECEIVER CONNECTIONS

1 2 3 4 5 6
VCC1 VCC2 C B S TEST
~ -
~
+/ /
12/24V
AC/DC
OUTPUT TYPE
- Contact (3-5)
- Resistive safety edge 8k2 (3-4)
System safety
Fail / Sensor active /
Sensor not memorized

2.2.2 LED INDICATOR

LED ON - Security OK
LED OFF - Obstacle detected

2.2.3 RECEIVER OPTION SELECTOR

ON
Enabled (Normative UNE-EN 13849-2)
1
CLASS 2
1 2 3 4
ON
Disabled (Stock configuration)
1 2 3 4
ON
869,85 Mhz (must be in accordance with transmitter)
2
TRANSMITTER
1 2 3 4
ON
FREQUENCY
868,95 Mhz (must be in accordance with transmitter)
1 2 3 4
ON
N.O. contact
3
RECEIVER
1 2 3 4
TYPE TEST
ON
N.C. contact
1 2 3 4
ON
Enabled
AUTOMATIC
4
1 2 3 4
FREQUENCY
ON
Disabled
AGILITY
1 2 3 4
Translation of the original instructions
1- Terminals
2- LED 1
3- Push button
4- DIP - Switch
1
5- LED 2
6- Buzzer
7- Antenna
7
TEST RELAY
(Choose transmitter
option 3 for contact
NO or NC)
8K2
B
C
B
C
S
S
1 - 2
