Philips Aquagenic Quadra HQ7405 Service Manual

Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
Features
- Main shaver
- Constant motor voltage
- Electronic push on/off
- Washable
Safety information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
Published by Philips Domestic Appliances and Personal Care
05/04
TECHNICAL INFORMATION
- Input voltage
- Motor voltage
- Shaving heads
- SAP coding
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- Think by assembly on right placing of the trimmer.
REPAIR INSTRUCTION
- Remove shaving unit, to prevent damages during repairing.
- Remove screws A1 (2x), open trimmer for screw.
- Take cover from housing (trimmer must be closed).
- Remove bracket (14 and 21).
- The PCB-board can now be removed out of the housing.
- Remove the connecting strip from the motor by
dis soldering.
- Remove screws B1 (2 x), now the motor and hairchamber
can be removed out of the housing.
- Detach the motor springs (17) from the gearwheel unit
with a small screwdriver.
OPTIONAL (accessories)
- No specific issues
Printed in the Netherlands © Copyright reserved
Shaver
HQ7405
AQUAGENIC
QUADRA
: 100-240 V, 50/60 Hz
: 6.2 V
: HQ6 - 4822 690 10214
: HQ7405
Subject to modification
