Extreme Tools EX3204TC Manual

Professional Tools and Equipment
PROFESSIONAL STEEL CABINET MANUAL
EX3204TC DELUXE TOOL CART
Extreme Tools , Inc.
®
740 Frontenac Road
Naperville, IL 60563
Office: 630 369-9303
Fax: 815 254-1930
The keys are taped to the
inside of the first drawer.
1. Replacement keys may be ordered, the code
which appears on the face of the lock is required.
2. Give the information for service parts: part number
and quantity.
1
EX3204TC DELUXE TOOL CART
PARTS LIST
REF# DESCRIPTION PART#
__________________________________________
1 Gas Strut 303082
2 Tray Liner 362711
3 Drawer Liner 362712
4 Drawer 107418
5 Drawer 107417
6 Lock 304005
7 Slide(L) 300160L
8 Drawer Pull 301406
9 Drawer 107416
10 Slide(R) 300160R
11 M8x20 Hex Bolt 321027
12 Washer 324255
13 Swivel Caster 302000
14 Bottom Tray 107419
15 Detent 314089
16 M8x16 Philips Head Bolt 321027
17 Rubber Bumper 314003
QTY
2 pcs.
1 pc.
4 pcs.
1 pc.
1 pc.
1 pc.
4 pcs.
4 pcs.
2 pcs.
4 pcs.
16 pcs.
16 pcs.
4 pcs.
1 pc.
8 pcs.
16 pcs.
3 pcs.
