Section 1 - Index; Section 2 - Parts List; Section 3 - Tools Required; Section 4 - Assembly - Summit Classic Swiftree Manual

1
INDEX
2
PARTS LIST
SWIFTREE BOX CONTENTS
PN DESCRIPTION
UPPER LADDER SECTION
LOWER LADDER SECTION
STAND OFF BRACKETS
HARDWARE PACKET
SAFETY / INSTRUCTIONAL DVD
18013 WRITTEN INSTRUCTIONS
3
TOOLS REQUIRED
Tools
• 7/16" Wrench / Socket with Ratchet
4
ASSEMBLY
SWIFTREE SECTION ASSEMBLY
Step 1. Position the ladder column as shown in figure
1. The triangle shaped rungs are welded on the side
facing the user. The stand off bracket should be
positioned so that it is on the side that faces the tree.
Step 2. Insert the 1.5" bolt through the column section
as shown in figure 2.
Step 3. Place the stand-off bracket over the protruding
bolt and securely tighten the lock nut as shown in
figure 3.
Step 4. Repeat for the other two ladder sections.
PG 2
GENERAL WARNINGS AND PRECAUTIONS, STAND WEIGHT LIMITS

SECTION 1 - INDEX

SECTION 2 - PARTS LIST

SECTION 3 - TOOLS REQUIRED

SECTION 4 - ASSEMBLY

SECTION 5 - INSTALLATION AND USE
SECTION 6 - MAINTENANCE AND CARE
SECTION 7 - LIMITED WARRANTY
QTY
2
1
3
1
1
1
Please call 256-353-0634 or visit http://www.summitstands.com/contactus/
if you have any questions, if you need replacement parts, if you have any missing
parts or if the included DVD does not play.
HARDWARE PACKET CONTENTS
PN DESCRIPTION
1 1/2", 1/4x20 BOLT
LOCK NUT, 1/4x20
Use
Stand off bracket bolts
1.5" Bolt
1
PG 1
PG 2
PG 2
PG 2
PG 2 - 3
PG 4 - 5
PG 6
PG 6
QTY
3
3
www.summitstands.com
