Single Hole Kitchen Faucet Installation Manual
All installations should be performed by a licensed professional
Product Model Number:
Please nd and write your product number down on the provided space above for future reference.
Product model number can be found on the box provided with your product.
All of our single hole kitchen faucets are installed using the same
procedure. Design, sizes, and styles may vary. The model illustrated
in this manual is for illustrative and demonstrative purposes only.
Some kitchen faucets come with a soap/ lotion dispenser.
Both installation procedures are outlined in this manual.
www.dyconnfaucet.com
Advertisement
Related Manuals for Dyconn TB001-A17
Summary of Contents for Dyconn TB001-A17
- Page 1 Single Hole Kitchen Faucet Installation Manual All installations should be performed by a licensed professional Product Model Number: Please nd and write your product number down on the provided space above for future reference. Product model number can be found on the box provided with your product. All of our single hole kitchen faucets are installed using the same procedure.
- Page 3 SINGLE HOLE KITCHEN FAUCET PARTS AND ACCESSORIES Model Shown: Pull Down Faucet (TB001-A17) You may need the following tools/materials Valve Hoses Pliers Screw Driver Silicone Wrench Plumbers Tape (included)
- Page 4 Kitchen Faucet Installation Instructions Diagram 1 Step 1: Unscrew the shank (1) from the faucet (if it is connected) and place it to the side, along with the rubber gasket (2), washer (3) and mounting nut (4). Diagram 2 Step 2: The short water line is HOT water, while the longer water line is COLD.
- Page 5 Kitchen Faucet Installation Instructions Diagram 3 Step 3: Re-install the shank (1) and base (2), if provided, and proceed to install the faucet through the deck mounting hole. Attach the gasket (3), washer (4) and mounting nut (5) onto the shank. Diagram 4 Step 4: After the faucet is properly positioned, thoroughly tighten the screws on the...
- Page 6 Kitchen Faucet Installation Instructions Diagram 5 Screw Step 5: If a weight is provided as a component of your faucet’s assembly, disassemble it with use of a Phillips screwdriver. Once the weight is separated, attach the weight (1) onto the pull-out hose (2) at a desired location. Note: The weight should NOT make contact with the faucet line hoses when the faucet head is pulled out.
- Page 7 Kitchen Faucet Installation Instructions Diagram 7 Step 7: Apply plumber’s tape onto the threading of each water valve. Connect both water hoses onto the respective water valves and securely tighten each mounting nut. Turn your water valves on. Diagram 8 Step 8: seconds.
- Page 8 Soap/ Lotion Dispenser Installation Instructions If your product comes with a soap/ lotion dispenser, use the following instructions below to install your product. Note that not all of our faucet products come with a soap/ lotion dispenser. Soap/ lotion dispensers can be purchased separately. Diagram 1 Step 1: Remove soap canister (1), gasket (2) and mounting nut (3) from the soap...
-
Page 9: Manufacturer Limited Warranty
Dyconn Faucet as defective will be repaired or replaced (with a product of equal value) at the company's discretion. If Dyconn Faucet is not able to replace or repair the product, Dyconn Faucet may elect to refund the original purchase price to the original purchaser in exchange for the product's return.
