XR Series Wireless Arrays XR-1000 Series January 30, 2013...
Page 2
Xirrus, Inc. All other trademarks and brand names are marks of their respective holders. Please see Legal Notices, Warnings, Compliance Statements, and Warranty and License Agreements in the Wireless Array User’s Guide. All rights reserved. This document may not be reproduced or disclosed in whole or in part by any means without the written consent of Xirrus, Inc.
For additional information, see the Wireless Array User’s Guide. This document is intended only for XR-1000 Series Arrays. It does not include the XR-1000H Series. For other XR models, please see the appropriate Quick Installation Guide.
Refer to the Wireless Array User’s Guide. For optimal placement, we recommend that a predictive survey be performed by a qualified Xirrus partner. Keep the unit away from electrical devices or appliances that generate RF noise—at least 3 to 6 feet (1 to 2 meters).
Page 5
Secure the T-Bar Clips to the Ceiling Support Grid Refer to Figure Twist the four T-bar clips onto the metal ceiling support grid at the marked locations and tighten the screw posts to 10-12 lbf.ft (1.38-1.66 kgf.m). Do not overtighten the screw posts. Cut an access hole for the cable in the ceiling tile.
Install the Mounting Plate Refer to Figure Align the Array’s mounting plate and secure it to the four T-bar clips using the nuts provided. Tighten the nuts to 10-12 lbf.ft (1.38-1.66 kgf.m), but do not overtighten. Figure 4. Installing the Mounting Plate If you wish to secure the Array to the mounting plate, slide open the attachment and feed a zip tie through it.
Figure 5 Figure All XR Array models have integrated splitters, so external splitters are not used. See the PoGE Installation Guide for details on the Xirrus-supplied injector modules and Array compatibility. Power: These Arrays are only powered through the port. Only Xirrus-supplied Gigabit POE power injectors may be used.
Page 8
Attach the Wireless Array to the Mounting Plate Refer to Figure Align the keyed slot in the center of the Array with the key post on the mounting plate. Key Post Alignment Hole Figure 6. Attaching the Array to the Mounting Plate Turn the Wireless Array to the right to lock the unit into place—similar to the assembly of a smoke detector.
Page 9
Refer to Figure NOTE: If you are a Xirrus Cloud customer, your Arrays are completely managed by XMS Cloud, and you may skip all of the remaining steps (8 to 10). In fact, you will not be able to access CLI or the Web Management Interface under normal operating circumstances.
Page 10
Click on Express Setup. Refer to Figure Figure 8. Express Setup Window When a newly deployed Array boots up, it automatically contacts Xirrus with its serial number and MAC address and obtains its license key. Any unlicensed Array will auto-...
Page 11
license in this way after it boots up, if it has Internet connectivity. You should see the key in the License Key field. In the Admin Settings section, change both the default admin username and password to improve Array security. Enter New Admin User and New Admin Password, then Confirm Admin Password.
Securing Low Level Access to the Array Management of the Xirrus Array is done via WMI or CLI. The Array also has a lower level interface: XBL (Xirrus Boot Loader), which allows access to more primitive commands. You won’t normally use XBL unless instructed to do so by Xirrus Customer Support. For proper security, you should replace the default XBL login username and password with your own, as instructed below.
Page 13
Procedure for Securing Low Level Array Access Use the following steps to replace the default XBL username and password. These steps use CLI commands. To access CLI via the WMI, click CLI under the Tools section on the left. If Xircon access at the XBL level is to be allowed, use the following three commands to change the XBL username and password from the default values of admin/admin.
Page 14
Drawings Small Mounting Plate For Arrays in Series XR-1000, XR-2000, XR-4000 .09 2.16 6.00 .46 11.56 1.45 36.96 .82 20.76 .20 5.13 .62 15.63 5.18 4.64 6(&7,21 $-$ 4.20 106.68 & 4.20 106.68 & .33 8.29 Figure 9. Drawing of Small Mounting Plate...
