ZURN AquaSense ZER-TM Series Installation, Operation, Maintenance And Parts Manual
Automatic sensor-operated gear driven type flushometer for water closets and urinals
Hide thumbs
Also See for AquaSense ZER-TM Series:
Advertisement
Quick Links
Water Closet Models:
ZER6000AV-ONE-TM
ZER6000AV-HET-TM
ZER6000AV-WS1-TM
ZER6000AV-DF-TM
Power Options:
Battery (Standard)
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
All goods sold hereunder are warranted to be free from defects in material and factory workmanship for a period of three years from the date of purchase.
Decorative finishes warranted for one year. We will replace at no costs goods that prove defective provided we are notified in writing of such defect and the
goods are returned to us prepaid at Sanford, NC, with evidence that they have been properly maintained and used in accordance with instructions. We shall
not be responsible for any labor charges or any loss, injury or damages whatsoever, including incidental or consequential damages. The sole and exclusive
remedy shall be limited to the replacement of the defective goods. Before installation and use, the purchaser shall determine the suitability of the product for his
intended use and the purchaser assumes all risk and liability whatever in connection therewith. Where permitted by law, the implied warranty of merchantability
is expressly excluded. If the products sold hereunder are "consumer products," the implied warranty of merchantability is limited to a period of three years and
shall be limited solely to the replacement of the defective goods. All weights stated in our catalogs and lists are approximate and are not guaranteed.
NOTICE: READ ENTIRE MANUAL PRIOR TO INSTALLING PRODUCT
AquaSense
ZER-TM Series
Automatic Sensor-Operated Gear
Driven Type Flushometer for Water
Closets and Urinals
Installation, Operation, Maintenance
and Parts Manual
1.1 gpf
1.28 gpf
1.6 gpf
1.1/1.6 gpf
LIMITED WARRANTY
®
Urinal Models:
ZER6003AV-ULF-TM
ZER6003AV-EWS-TM 0.5 gpf
ZER6003AV-WS1-TM
0.125 gpf
1.0 gpf
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ZURN AquaSense ZER-TM Series
Summary of Contents for ZURN AquaSense ZER-TM Series
- Page 1 AquaSense ® ZER-TM Series Automatic Sensor-Operated Gear Driven Type Flushometer for Water Closets and Urinals Installation, Operation, Maintenance and Parts Manual Water Closet Models: Urinal Models: ZER6000AV-ONE-TM 1.1 gpf ZER6003AV-ULF-TM 0.125 gpf ZER6000AV-HET-TM 1.28 gpf ZER6003AV-EWS-TM 0.5 gpf ZER6000AV-WS1-TM 1.6 gpf ZER6003AV-WS1-TM 1.0 gpf ZER6000AV-DF-TM...
- Page 2 ZER-TM Series Flush Valve Package Contents ZER6000AV-TM ZER6003AV-TM Cast Wall Escutcheon Cast Wall Escutcheon Sweat Kit Sweat Kit Stop Valve Stop Valve Valve Valve Assembly Assembly Vandal Cover Vandal Cover Vacuum Breaker Vacuum Breaker Magic Magic Magnet Magnet ⁄ ” Vacuum ⁄...
-
Page 3: Specifications
• Installer is responsible for ensuring the product is installed and conforms to all plumbing codes and ordinances. • Do not convert or modify this Zurn product yourself. All warranties will be voided. • Water supply lines must be sized according to building designer in order to provide adequate water supply for each fixture. - Page 4 Sweat Solder Adapter Installation Instructions - STEP 1 NOTE: Before installation, turn off water supplies to existing fixture and remove flushometer if replacing an existing device. STEP 1.1 STEP 1.2 Measure distance from finished wall to the center line of the fixture Slide threaded sweat solder adapter onto water supply pipe until spud.
- Page 5 Flush Valve Installation - STEP 3 STEP 3.1 STEP 3.2 Prior to attaching flush valve to control stop(A) inspect and verify Lubricate O-ring with water and carefully insert flush valve tailpiece that the O-ring (C) is located within the O-ring groove at the tailpiece. into the control stop valve to ensure O-ring remains seated.
- Page 6 Battery Installation - STEP 4 STEP 4.1 STEP 4.2 Use the 3/32” Allen Wrench to loosen the internal set screw Remove the valve head by turning it counter-clockwise and lifting counter-clockwise until it stops. Screw will retract into the shell. gently.
- Page 7 Sensor Angle Adjustment (when necessary) STEP 1 Turn off control stop using a flat head screw driver turning clockwise (See Figure 16). Then, use the electronic override button to flush the water out of the flush valve. Electronic STEP 2 Override Mark down Locking ring original position relative to valve body Button...
- Page 8 STEP 2 Place the Zurn MagicMagnet (supplied) on top flat surface (see ® Figure 18). Once magnet is inplace, the blue LED illuminate continuously on for 5 seconds.
-
Page 9: Care And Cleaning Instruction
The Dual Flush model must be paired with a fixture with a flush volume range that includes 1.1 to 1.6 gallons per flush. For a list of recommended bowls, please refer to our website, www.zurn.com, or speak with your local Zurn rep. - Page 10 [24 / 48 / 72] hours after no usage trap exchange timing. (default is OFF). For further assistance with troubleshooting, visit http://www.zurn.com/ FV669 Rev. B 10/14/2019 Page 9...
- Page 11 ZER-TM Series Repair Kits Part Identification Valve Body Vacuum Breaker Duckbill Vacuum Breaker Tube Vacuum Breaker Tube Nut Spud Nut Spud Friction Washer Spud Sleeve Spud Escutcheon Tailpiece 10. Snap Ring 11. Tailpiece O-Ring 12. Locking Nut 13. Stop Body 14.
- Page 12 ZURN INDUSTRIES, LLC 511 W. Freshwater Way, Milwaukee, WI U.S.A. 53204 · Ph. 1-855-ONE-ZURN, Fax 919-775-3541 In Canada: ZURN INDUSTRIES LIMITED 7900 Goreway Drive, Unit 10, Brampton, Ontario L6T 5W6, Ph. 905-405-8272, Fax 905-405-1292 ZURN.COM Rev. B Date: 10/14/2019 C.N. No. SAN008625 Prod.
