- Page 1 CENPAC Mounting instructions CENPAC 3.x CENPAC 5.x www.centrosolar.co.uk www.centrosolar.com...
-
Page 3: Table Of Contents
Content Implementation 1.1 Notes on these instructions 1.2 Description of the mounting system CENPAC components Installation 3.1 Constructions 3.2 Preliminary planning for mounting the installation 3.3 Rules relating to individual rafter configuration Mounting process Commissioning the system Guarantees and warranties Disclaimer... -
Page 5: Implementation
This reliable complete system combines the benefits of sible. There is no liability on the part of Centrosolar AG for a customized PV installation with the possibilities of an the structural suitability of the mounting construction. -
Page 6: Cenpac Components
2 CENPAC components Parts list for the various individual constructions The CENPAC contains all the components needed for installing the respective constructions. Individual components of the delivery will remain unused depending on which construction is chosen. Number in parts Article No. Article 1X******* PV module S ****54 Excellent... - Page 7 Number in parts Article No. Article 200003300A Powerstocc 3.6 Excellent/Powerstocc 5.5 Excellent 417522001 Adapter set H+S 417522007 Adapter set LC4 411530600 Draka solar cable 1 x 6 mm², 100 m 3E2000001 Cable retainer EDGECLIP 5...
-
Page 8: Installation
3 Installation 3.1 Constructions CENPAC 3.x 4 x 4 modules 2 x 8 modules Overall dimensions: Generator field Overall dimensions: Generator field dimensions: dimensions: 9732 x 4,214 mm 7,932 x 3,214 mm 5766 x 7,280 mm 3966 x 6,280 mm (width x height) (width x height) (width x height) -
Page 9: Preliminary Planning For Mounting The Installation
3.3, please field. The permissible cantilever may be between 50 and contact your local Centrosolar office. 400 mm. During the preliminary mounting planning, the cantilever is defined by the overhang of the module sup- 3.3 Rules relating to individual rafter... -
Page 10: Mounting Process
4 Mounting process Select the first rafter from the left for mounting the first roof hook using the rafter configuration plan and taking account of the margins and the maximum cantilevers to be observed. Remove the roof tiles above the rafter to be al- located. - Page 11 The roof hook is to be positioned in such a way that at least two holes run on the base of the roof hook around the centre to the rafter. The roof hook is fastened to the rafter using the wooden screws supplied.
- Page 12 The next step involves fastening the 2-C groove profiles to the roof hook. The mounting of the 2-C groove profiles takes place from below (the eaves) towards the ridge. The longer 1,681 mm 2-C groove profiles are mounted in the lowest row. The mounting of the shorter 2-C groove profile with 1,533 mm will also take place.
- Page 13 After the hammer head screw has been inserted into the 2-C groove profile, it will be rotated 90° once more until the hammer head plate engag- es its profile. For more efficient adjustment of the 2-C groove profiles, you should initially only tighten the hammer head screws hand-tight.
- Page 14 The module support profiles are mounted from below (the eaves) starting towards the ridge. The overhang of the module support profiles may not exceed the outer 2-C groove profiles by over 400 mm. The connections of the 2-C groove profiles are established with the module support profiles via clamping jaws .
- Page 15 The one-sided overhang of the module support over the outer 2-C groove profiles (cantilever) is permitted up to 400 mm. The fastening of the further clamping jaws takes place analogous to the mounting of the previous clamping jaws. max. 400 mm 14 - Adjusting the cantilever There are two distance gauges included in the delivery of your mounting system that serve...
- Page 16 The mounting of all further module supports take place in the same way. The horizontal connection of the module sup- port profiles takes place via connecting links. The connecting link is to be inserted half way into the mounting profile and screwed in. Differences in height in the roof space should be compensated by adjusting the 2-C groove profiles so that undesired tension in the module...
- Page 17 The returning string lead should be laid near the module support before inserting the PV modules into the mounting system. The fasten- ing of the string lead can take place using the EDGECLIPs 5 on the profiles. All modules for the CENPAC are connected in a single string in series.
- Page 18 Pulling in the module into the profile slot of the low module support profile represents the com- pletion. 20c - Mounting the PV module Place the next module as described before in a distance of ca. 400 mm for the first module into the module supports .
- Page 19 For information on the installation and cabling and registering your CENPAC, please refer to the document "Instal- lation information" and the documentation enclosed with the individual components. You can contact your local Centrosolar office at any time should any questions on the installation arise.
-
Page 20: Commissioning The System
5 Commissioning the system Please observe This list is only for your information. It is not necessarily Commissioning the photovoltaic system is part of the ex- complete. pert and proper construction and installation. This may only be carried out following a careful visual examination Please also observe DIN EN 62446 (VDE 0126-23): Net- and a professional electrical inspection. -
Page 21: Guarantees And Warranties
Guaran- overall system. CENTROSOLAR AG cannot monitor the tees and warranty claims shall be excluded if: adherence to the advice and guidelines in these mounting instructions. - Page 22 Notes:...
