AQT DN 10-32
Shut off / Отключение
Δp
= 1 bar
max
Code No.: 003Z0240
Setting / Настройка
≠
100%
h
Locking / Блокировка
2 | © Danfoss | 2017.08
0 %
∞
10%
h+ 2 mm
(DN 10-20)
①
h+ 4 mm
(DN 25-32)
③
1.5 mm
Δp
= 16 bar
max
4.5 lbf ft
(6 Nm)
4.5 lbf ft
(6 Nm)
Code No.: 003Z1230
3 Nm
②
④
3mm
3mm
VI.A7.I1.00
