Technical specifications :
Power supply:
Operating frequency:
Operating temperature:
Protection class:
Operating range:
Device characteristics:
!!!
R
PORTOS drive control system
230V 50 Hz
433,92 MHz
between -10˚C and +50˚C
IP44
150 m in an open area
25 m inside buildings
PPKR-313/2
OWNER'S MANUAL
PPKR-313/2
UP
STOP
DOWN
Radio equipment operating at 433 MHz
may cause reception interference.
The range of the radio signal is
architecturally and statutorily limited.
Advertisement
Related Manuals for Portos PPKR-313/2
Summary of Contents for Portos PPKR-313/2
- Page 1 PORTOS drive control system OWNER'S MANUAL PPKR-313/2 Technical specifications : Power supply: 230V 50 Hz Operating frequency: 433,92 MHz Operating temperature: between -10˚C and +50˚C Protection class: IP44 Operating range: 150 m in an open area 25 m inside buildings...
- Page 2 1. Switching between support and no support modes The switch can be operated in two modes: Support mode Pressing and releasing the UP or DOWN button activates the programmed motor function (opening or closing the roller shutter). The motor will run until it completely closes or opens the roller shutter.
- Page 3 2. Assigning a remote. To assign a given remote / transmitter to the PPKR-313/2 receiver, perform the following actions: 1.On the selected switch, press the UP + DOWN buttons and hold them for 3 seconds (the LED starts flashing). 2.On the switch, press the STOP button (the LED is steady on).
- Page 4 4. Removing all assigned remotes/transmitters. In order to remove all assigned remotes/transmitters from the PPKR-313/2 receiver, perform the following actions: 1.On the switch, press the DOWN + STOP buttons and hold them for 6 seconds (the LED is steady on).
