}Never insert or allow objects to fall into the openings of the appliance.
}When disconnecting the appliance from the mains, never pull on the mains cable or on the appliance itself.
}Do not wind the mains cable around the appliance.
}Keep the mains cable and appliance away from hot surfaces.
}Make sure that the mains cable is not twisted or kinked when charging or storing.
}Do not use disposable batteries. Batteries should only be replaced at authorised service centres.
General user information
Information about using the operation manual
}Before using the appliance for the first time, you must read and understand the operation manual completely.
}Consider the operation manual as part of the product and store it in a safe and accessible place.
}Include this operation manual if passing the appliance on to a third party.
}In case of conflicts with national safety specifications or instructions, the national requirements must be followed.
Explanation of symbols and notes
DANGER
Danger of electric shock which may result in serious physical injury or death.
DANGER
Danger of explosion which may result in serious physical injury or death.
WARNING
Warning of possible physical injury or a health risk.
CAUTION
Information about danger of material damage.
Note with useful information and tips.
}Action to be taken by owner.
1. Carry out these actions in the sequence described.
Product description
Description of parts (Fig. 1)
A Blade set
B On/off switch
C Charging indicator
D Charging stand
E Charging stand socket
F Oil for blade set
G Cleaning brush
H Attachment comb
I Plug-in transformer
J Appliance plug
Technical data
Hand-held appliance
Drive unit: DC motor
Battery: NiMH battery
Operating time: up to 100 minutes
Dimensions (LxWxH): 141 x 32 x 29 mm
Weight: approx. 132 g
Emission sound pressure level: max. 60 dB(A) @ 25 cm
Vibration: < 2,5 m/s2
Charging stand
Dimensions
with accessories (LxWxH): 72 x 96 x 58 mm
Weight: approx. 61 g
Plug-in transformer
Type adapter 6000
Power consumption: max. 12 W
Operating voltage: 100 – 240 V / 50 – 60 Hz
The appliance is safety insulated and radio screened. It meets
the requirements of EU Electromagnetic Compatibility Directive
2004/108/EC and Machinery Directive 2006/42/EC.
Operation
Preparation
Keep the packaging material for safe storage or transport later.
}Check that the contents are complete.
}Check all the parts for possible transport damage.
Safety
Handle with care! Damage due to incorrect power supply.
Only operate the appliance with an alternating current and with the voltage stated on the nameplate.
Charging the battery
Before the appliance is used for the first time, it should be charged for approx. 2 hours!
1. Connect the appliance plug (J) on the plug-in transformer to the charging stand socket (E) (Fig. 2ⓐ).
Battery overcharging is prevented thanks to intelligent charge management.
2. Connect the plug-in transformer to the mains socket (Fig. 2ⓐ).
3. Switch off the appliance using the on/off switch (Fig. 3ⓐ).
4. Place the appliance on the charging station (Fig. 2)
·· During charging, the charging indicator (C) flashes at evenly spaced intervals. When the battery is fully charged, the charging indicator flashes at a different rate (10
on / 1 off).
·· After the appliance has been removed from the charging stand, the display goes out (power saving mode).
·· It takes no more than 120 minutes for the appliance to charge to full capacity.
Battery operation
1. Switch on the appliance using the on/off switch and switch off after use (Fig. 3ⓐ/ⓐ).
