- Page 1 DRZH User Guide English (3–8) Appendix English (34)
-
Page 2: Box Contents
User Guide (English) Introduction Thank you for purchasing the DRZH. At Rane, performance and reliability mean as much to us as they do to you. That’s why we design our equipment with only one thing in mind—to make your performance the best it can be. - Page 3 Inputs Zonetech Zone Amplifier Zone Zone Zone Zone Note: Use a shielded Ethernet cable (Cat5e or Cat6) to connect the RJ45 port on the rear panel to the main audio processing unit (e.g., a Rane Zonetech, HAL3s, or Terminal 1010x).
-
Page 4: Installation
Run a shielded Ethernet cable (Cat5e or Cat6) from the audio processing unit to the electrical box, and then connect it to the RJ45 port on DRZH's rear panel. DRZH can be located up to 300 meters (984 feet) from the processing unit. - Page 5 Rear Panel Panel Display: This screen shows the setting that the knob on DRZH is currently adjusting. Push the knob to select the next setting. Knob: Turn this knob to adjust the setting currently shown in the display. Push the knob to select the next setting.
-
Page 6: Operation
Operation By default, the display on DRZH will show the volume setting for the current room (zone): Volume. To adjust the volume, turn the knob. You can access and adjust other settings, as well, depending on the system DRZH is connected to. -
Page 7: Troubleshooting
• Make sure all cables and other connected devices are properly and securely connected. • Make sure you are using DRZH as described in this user guide. • Make sure your other devices or media are working properly. • If you believe DRZH is not working properly, check the following for your problem and solution. -
Page 8: Technical Specifications
Appendix (English) Technical Specifications Display 1.1” x 0.6” / 26.7 x 15.5 mm (width x height) 1.2” / 30.9 mm (diagonal) 128 x 64 pixel resolution Monochrome, white on black Connectors (1) Ethernet/RJ45 port Power Connection: Ethernet/RJ45 port Voltage: 24 V Consumption: 1.2 W Dimensions 3.0”... - Page 9 Rane is a trademark of inMusic Brands, Inc., registered in the U.S. and other countries. All other product names, company names, trademarks, or trade names are those of their respective owners.
- Page 11 Manual Version 1.0...
