9. TECHNICAL SPECIFICATIONS
Description
Width
Depth at the base
Height
Net and gross weight
Line voltage
Running voltage
Absorption
Tool min diameter hole
Tool max diameter hole
10. DEMOLITION AND WASTE DISPOSAL
According to International regulations, this unit has been classified as AEE
(electric and electronic device, whose correct operation depends on electric
currents and electromagnetic fields) and as a consequence, at the end of its
lifetime, it can not be treated as normal waste material but it must be disposed
separately, complying with the Directive 2002/96/CE.
C.I.E. DENTALFARM
Via Susa, 9/a - 10138 TORINO - ITALY
TECHNICAL-COMMERCIAL SERVICE
AFTER-SALE SERVICE
011/ 4346366
FAX
info@dentalfarm.it
E-mail:
www.dentalfarm.it
Website:
420 mm (600 mm with splash guards)
205 mm (290 mm with splash guards)
250 mm (280 mm with splash guards)
9,0 kg – 10,3 kg
230 v AC – 50/60 Hz
230 v AC
500 W
5.0 mm
11,0 mm
s.r.l.
(+39) 011/4346588
011/4346632
POLISHING UNIT
SHINE
INSTRUCTION AND MAINTENANCE MANUAL
A5201 SHINE – lotto/batch 10/06
