Manual Digital optical transmitter for USB signals Distributed by: Reliant EMC LLC, 3311 Lewis Ave, Signal Hill CA 90755, 4089165750, www.reliantemc.com...
Date optoUSB-3.0 20.02.19 Page: 2 Manual Table of contents 1 Disclaimer of Warranty/Exclusion of Liability......................3 2 Special Regulations and Notes...........................3 2.1 Safety.................................3 2.2 Product Care and Maintenance.........................3 2.3 Cleaning................................3 2.4 Installation Instructions.............................4 3 Regulations and References............................4 3.1 Properties................................4 3.2 Regulations and References..........................5 3.3 Charging the Batteries (Battery Pack or Integrated into the Device)..............6...
Date optoUSB-3.0 20.02.19 Manual Page 3 1 Disclaimer of Warranty/Exclusion of Liability Under the Following Circumstances the Warranty and Liability is Excluded: § Usage not according to the intended purpose and misapplication • Non-observance of the safety instructions • Manipulation and modification of the devices •...
Date optoUSB-3.0 20.02.19 Page: 4 Manual 2.4 Installation Instructions Risk of Fire or Damage Do not open the devices. Opening the devices is only allowed with the necessary guidance and previous authorization from . Non-observance can lead to fire or damage of the device.
Date optoUSB-3.0 20.02.19 Manual Page 5 discharge is avoided. 3.2 Regulations and References Protect the batteries from heat (e.g. long times of exposure to direct sunlight) and fire. Do not immerse the batteries into fluids. Otherwise there is a risk of explosions.
Page 6
Date optoUSB-3.0 20.02.19 Page: 6 Manual Place the battery pack or the device to charge onto a stable and skid proof surface. • Turn off the device off (see appropriate chapter for operation and operating controls). • Connect the charger with the battery pack or the device using the designated screw connector (see appropriate •...
Page 7
Date optoUSB-3.0 20.02.19 Manual Page 7 4 Environmentally Friendly Disposal 4.1 Disposal of Devices All devices must be disposed according to the environmental regulations in force. Important Notice For Disposal of Devices Used equipment must be collected separately and disposed in an environmentally friendly •...
5 Characteristics and field of application The digital optical system optoUSB-3.0 can be used to optically transmit USB signals with a data rate of up to 5 Gbit/s correlating to USB3.0 standard. Because of the optical transmission, the system is very robust against EMS (electromagnetic susceptibility).
Page 9
Date optoUSB-3.0 20.02.19 Manual Page 9 7 Housing and connectors / pushbuttons Fig. 7.1: Front side of the USB3.0 transceivers – HUB side on the left, PC side on the right Fig. 7.1 shows the front side of the transceivers with connectors and push buttons: transceiver HUB side only: power push button with control LED (Pwr On/Off) •...
Page 10
Date optoUSB-3.0 20.02.19 Page: 10 Manual Fig. 7.2 shows the rear side of the transceiver (PC side, left) and the transceiver (Hub side, right) with connectors and control LEDs. Fig. 7.2: Rear side of the devices – PC side on the left, HUB side on the right Description of transceiver 1 ( PC side ): USB3.0 type B connector to connect the PC side transceiver with a USB 3.0 cable to a PC.
The measurements can be extended by using the optional battery pack BP84 or an optional shielded power supply certified by mk-messtechnik. The external supply can be connected to the system any time (parallel). The connection to the internal battery is decoupled with a diode.
20.02.19 Page: 12 Manual Only use the battery pack and connector cables from mk-messtechnik! Others might lead to a damage of the system! The USB cable should be as short as possible and of high quality (rf shielding) to avoid rf coupling.
Page 13
Date optoUSB-3.0 20.02.19 Manual Page 13 devices. Distributed by: Reliant EMC LLC, 3311 Lewis Ave, Signal Hill CA 90755, 4089165750, www.reliantemc.com...
Date optoUSB-3.0 20.02.19 Page: 14 Manual Trouble shooting The following trouble shooting list is provided to assist you while having problems. It might let you use the system again without a long down time: Error Possible reasons Solution No or erroneous transmission...
Date optoUSB-3.0 20.02.19 Manual Page 15 Accessories / Options Part Order number Comment Optical fiber LWL-2-xm x = length in m, simplex External batteries BP-84-5f 8,4V/4Ah Connector cable for BP-84 SC-30-5m5m Length approx. 30cm Charger with connector plugs CH-1m-5m Standard charger...
Page 16
Datasheet Datasheet Field of applica on and characteris cs The optoUSB-3.0 system can be used for the op cal transmission of USB-signals up to a data rate of 5Gbit/s according to USB3.0 standard. It can be used to transmit USB- signals over long distances (up to 50m) or to handle ground poten al problems.
