- Page 1 Installation Manual Effective October 2000...
-
Page 2: Table Of Contents
Corner Shelf (EVSSC) Low-Profile Shelf (EVSSL) Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will In accordance with the manufacturer's policy of continual product improvement, the product presented in not be responsible for any damage or bodily harm caused by alterations in accordance with national or this document is subject to change without notice or obligation. -
Page 3: Panels
5. Press fit the top cap down onto the top of the Corner Post. 6. Reattach the panel tops caps. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 4: Corner Connections - Variable Height (Evpvp2, Evpvp3, Evpvp4)
Corner Post. 6. Reattach the panel tops caps. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 5: Corner Connections - Corner Post Extension (Evpcep2, Evpcep3, Evpcep4)
9. Attach the Corner Post top cap. 10. Reattach the panel top caps. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 6: Inline Connection - Equal Height (Evpic)
(4) 1/2" flat head screws. 5. Reattach the panel top caps. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 7: Inline Connection - Variable Height (Evpvc)
1/2" flat head screws. 6. Reattach the panel top caps. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 8: Notched Top Cap
3. Snap off and discard the center piece. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 9: Inline Connection - Panel Extension Module (Evpiec)
– panel – post – etc. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 10: End-Of-Run Post Kit (Evper)
Press the extrusion onto the slotted post. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 11: End-Of-Run Post Kit - Wall Mount Application
13. Slide the panel onto the trim kit/Wall Mount. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 12: Electrical
Always determine that harness is electrically connected to only one power supply. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 13: Power Distribution Housing (Evepd)
3. Replace the raceway cover. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 14: Jumper Cables And Pass-Through Cables (Evecj, Evecp)
Panel Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will In accordance with the manufacturer's policy of continual product improvement, the product presented in not be responsible for any damage or bodily harm caused by alterations in accordance with national or this document is subject to change without notice or obligation. -
Page 15: Directional Floor Power Entry (Eveefd)
Installation Manual. Always determine that harness is electrically connected to only one power supply. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 16: Reversible Floor Power Entry (Eveefr)
Installation Manual. Always determine that harness is electrically connected to only one power supply. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 17: Ceiling Power Entry (Eveec)
Installation Manual. Always determine that harness is electrically connected to only one power supply. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 18: Duplex Receptacle (Everd)
4. Replace the raceway cover. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... - Page 19 Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will In accordance with the manufacturer's policy of continual product improvement, the product presented in not be responsible for any damage or bodily harm caused by alterations in accordance with national or this document is subject to change without notice or obligation.
-
Page 20: Worksurfaces
Proceed with the installation of the worksurfaces. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 21: Corner Bracket (Evhcb)
3. Set bracket securely in panel slots with rubber mallet. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 22: Cantilever (Evhc)
3. Pivot downward and latch in remainder of metal bracket. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 23: Support Leg (Evhs)
Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 24: Worksurface Supporting Pedestals (Evsbbf, Evsff)
Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 25: Overhead Flipper Door Storage Unit (Evsof)
6. Secure by driving supplied screws through the top ledge into the metal top. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 26: Corner Shelf (Evssc)
7. Align both shelves and secure by driving a self-drilling screw through the flat bracket to the adjacent shelf. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will... -
Page 27: Low-Profile Shelf (Evssl)
4. Secure shelf by driving supplied screws through the end bracket and into bottom of shelf. Evolve Customer Support available at 856/552-4000, 888/827-2500, from 8:30 Eastern through 6 Eastern time, or fax at 856/552-4001. Note: Any alterations to listed components will void the manufacturer's warranty. The manufacturer will...
