FreeWheel Setup Instructions

Folding wheelchair adaptor

Knob

Tube

Shim

Folding Wheelchair Adaptor: Set-Up Instructions

Tubing

Hitch

Horizontal

Tubing

NOTE: Video instructions under VIDEOS at

www.gofreewheel.com. Maximum personal

body weight for Adaptor is 250 Lbs.

STEP 1: Getting Started

A. Separate tubing

B. Slide HITCH on to one side of tubing. Slide

tubing back together.

C. Open Knobs and remove Tube Shims.

STEP 2: Securing Adaptor to Your

Wheelchair

A. Clip Tube Shim onto horizontal tubing. Tube

Shims are not required on 1-18"tubing. If you

have 7/8" tubing contact us about custom tube

shims.

B. Slide Adaptor tubing to width of wheelchair

and close clamps over tube shims on

wheelchair horizontal tubing.

C. Secure clamps by rotating knob into slot and

tightening.

D. Move hitch so it is perfectly centered between

horizontal tubing.

Table of Contents

Do you have a question about the FreeWheel and is the answer not in the manual?

Page 1 ® Folding Wheelchair Adaptor: Set-Up Instructions Knob Tubing NOTE: Video instructions under VIDEOS at www.gofreewheel.com. Maximum personal body weight for Adaptor is 250 Lbs. STEP 1: Getting Started A. Separate tubing B. Slide HITCH on to one side of tubing. Slide Hitch Tube tubing back together.
Page 2 PNT, LLC does not accept any liability or responsibility for any type of injury or damage to an individual or property, resulting from the use of the FreeWheel Wheelchair Attachment and ADAPTOR for Folding Wheelchair, that is considered in excess of normal use including, but not limited to use with any electric assist product, speeds in excess of what an individual can...
