Wheelchair Attachment RACK
1. Socket and Slider/Lock
1. 6 O-Rings, 4 Zip-Ties, 2 Foam Strips, 2 Sockets, 2 Sliders/Locks, 2 Retaining Screws
2. 2 Ball Fittings, 2 Washers, 2 Buttonhead Screws
3. 1 Block, 2 Socket Head Cap Screws
Phillips Screw Driver, 5/32" allen wrench, wheel bearing grease
1. Do not overload your RACK. Manufacturer maximum weight specifications is 25 lbs.
2. To make it easy to insert the Ball Fitting into the Socket, it helps to lightly dab wheel bearing
grease on each Ball Fitting (can be found at any auto parts store).
3. If the width between your vertical tubes is over 13-3/4" please contact us for an additional
part.
For additional information or questions please go to our website or email us at:
WWW.GOFREEWHEEL.COM or INFO@GOFREEWHEEL.COM
Installation Guide
2. Width Adjustment
Parts Included
Tools Needed
When Using Your RACK
***
OVER
***
TM
3. Block Centered
Advertisement
Table of Contents
Related Manuals for FreeWheel RACK
Summary of Contents for FreeWheel RACK
- Page 1 Phillips Screw Driver, 5/32” allen wrench, wheel bearing grease When Using Your RACK 1. Do not overload your RACK. Manufacturer maximum weight specifications is 25 lbs. 2. To make it easy to insert the Ball Fitting into the Socket, it helps to lightly dab wheel bearing grease on each Ball Fitting (can be found at any auto parts store).
- Page 2 STEP 1 Slider/Lock Zip-Ties and Foam Backing Retaining Screw 11” Bottom of foam strip 11” from 3 - O-Rings floor withOUT FreeWheel on STEP 3 STEP 2 Washer Center Block at top of Buttonhead Screw FreeWheel Ball Fitting...
