Folding Wheelchair Adaptor: Set-Up Instructions
C
A
A
C
STEP 1: Getting Started
A. Separate tubing
B. Slide HITCH on to one side of tubing. Slide tubing
back together.
C. Open Knobs and remove Tube Shims.
B
STEP 2: Securing Adaptor to Your
Wheelchair
A. Clip Tube Shims onto horizontal tubing. Do NOT
use Tube Shims if tubing 1-1/8" in diameter.
B
B. Slide center bar to width of wheelchair and close
clamps over wheelchair tubing.
C. Secure clamps by lifting knob into slot and
tightening.
D. Move hitch so it is perfectly centered between
D
tubes.
Advertisement
Table of Contents
Related Manuals for FreeWheel Folding Wheelchair Adaptor
Summary of Contents for FreeWheel Folding Wheelchair Adaptor
- Page 1 Folding Wheelchair Adaptor: Set-Up Instructions STEP 1: Getting Started A. Separate tubing B. Slide HITCH on to one side of tubing. Slide tubing back together. C. Open Knobs and remove Tube Shims. STEP 2: Securing Adaptor to Your Wheelchair A. Clip Tube Shims onto horizontal tubing. Do NOT use Tube Shims if tubing 1-1/8”...
- Page 2 FreeWheel frame. C. If your toes hit the wheel, loosen clamps and move Adaptor forward on the horizontal bars. Please refer to the FreeWheel Set-up Guide to fine tune any adjustments. For more information or questions, contact us at: Email: info@seatingdynamics.com.au...
