- Page 1 Gas pressure spring ≤ 28 kg Instructions for Use Only in connection with Prevista Dry WC element 8521.32, for ceramic ≤ 28 kg Model Year built: 8570.51 from 03/2019 en_INT...
- Page 2 Gas pressure spring ≤ 28 kg 2 from 10...
-
Page 3: Table Of Contents
Table of contents Table of contents About these instructions for use Target groups Labelling of notes About this translated version Product information Intended use 2.1.1 Areas of use Handling Assembly 3.1.1 Replace gas pressure spring 3.1.2 Preparing gas pressure spring for disposal Disposal Gas pressure spring ≤... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
About these instructions for use About this translated version This instruction for use contains important information about the choice of product or system, assembly and commissioning as well as intended use and, if required, maintenance measures. The information about the products, their properties and application technology are based on the current standards in Europe (e.g. -
Page 6: Product Information
Product information 2 Product information Intended use 2.1.1 Areas of use The gas pressure spring is exclusively suitable for the height-adjustable Prevista Dry WC element (model 8521.32). The gas pressure spring is used to lift and lower WC ceramic up to 28 kg. Gas pressure spring ≤... -
Page 7: Handling
Handling 3 Handling Assembly 3.1.1 Replace gas pressure spring The model replaces the built-in gas pressure spring in the case of a defect. NOTICE! Damage to the cover plate! If the upper edge of the finished floor is higher than planned, there is a risk that the cover plate will touch. -
Page 8: Preparing Gas Pressure Spring For Disposal
– Do not cut off the ends. – Cover the borehole. – Under no circumstances use a lathe. Please contact your Viega Service Center if you have any questions. Gas pressure spring ≤ 28 kg 8 from 10... - Page 9 Handling Draining gas and oil The gas pressure spring must be disposed off unpressurised and without oil; to this end, drill two holes in the container at two points. Open up the gas pressure spring. The drilling points X1 and X2 vary depending on the diameter of piston rod and cylinder.
-
Page 10: Disposal
Handling Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Gas pressure spring ≤ 28 kg 10 from 10...
