- Page 1 USER GUIDE POWERTAP EARTH fishman.com...
- Page 2 PowerTap Earth. Additional information and support can be found at www.fishman.com PowerTap Earth As part of the new Fishman Acoustic PowerTap™ series, the PowerTap Earth pickup system combines the easy installation, superior performance, and warm, transparent sound of our Rare Earth Humbucker with a new soundboard Tap body sensor.
- Page 3 In these cases, raise the bass side of the pickup with a shim. The PowerTap Earth is voiced specifically for bronze or phosphor bronze strings. If nickel electric guitar strings are used with the PowerTap Earth, the lower wound strings will overpower the higher plain strings.
-
Page 4: Battery Replacement
Battery Replacement Remove the pickup from the instrument and carefully pry out the batteries with a small flat-head jeweler’s screwdriver. When you replace the batteries, observe the correct polarity. Plus (+) and minus (-) polarity marks are molded into the shell of the battery clip. -
Page 5: Battery Information
Battery Information Two LR-44 1.5 Volt silver oxide: Eveready #357 ANSI-WS15 1EC-SR44 The battery holder will also accept a single CR11108 3-Volt lithium battery: Duracell DL1/3N Eveready 2L76 Sanyo CR 1/3N... - Page 6 Stereo/Mono Output Options The PowerTap Earth may be used in mono or stereo output simply by choosing the appropriate cable. For a blended mono output use a standard instrument cable. Turn the thumbwheel control toward the bass strings to blend the body sensor in with the magnetic pickup signal.
- Page 7 Blend Function - Tap Pickup Rotate counter clockwise for full magnetic pickup. Rotate clockwise to blend-in the Tap body sensor.
- Page 8 Dual Source – Acoustic Amp stereo Y cable...
- Page 9 Dual Source – PA stereo breakout cable (included) mono 1/4” cables Tap pickup and magnetic pickup to front of house...
- Page 10 Fishman at their sole discretion. Fishman may also choose to replace this product or part of this product with a substitute, in lieu of repair, in exchange for quoted labor charges. This warranty applies only if the Product is sold and delivered within the U.S.
- Page 11 United States. Product repaired after the first year warranty period at the Fishman factory will be returned at customer expense. Prod- uct returned to Fishman that is not covered by the terms of this warranty will be serviced only after payment is arranged.
- Page 12 Fishman and Fishman Transducers are trademarks or tradenames of Fishman Transducers Inc. 513-300-256 r0...
