- Page 1 USER GUIDE POWERTAP INFINITY fishman.com...
- Page 2 PowerTap Infinity. Additional information and support can be found at www.fishman.com PowerTap Infinity As part of the new Fishman Acoustic PowerTap™ series, the PowerTap Infinity pairs our world class Matrix undersaddle pickup with a specially designed, bridge plate-mounted body-sensing pickup. The result delivers a new world of percus- sive performance elements and tactile dynamics for guitarists of all styles.
- Page 3 Controls Plug In • Connect the PowerTap Infinity to your amplifier or PA with a ¼-inch instrument cable. To conserve battery life, remove the instrument cable from the guitar when the system is not in use.
- Page 4 Controls Volume • For the cleanest noise-free sound, set the volume as high as possible without causing your amp or mixer to distort Tone • This innovative one-knob tone control lets you adjust between the natural undersaddle sound with no EQ (flat) and a variable “Scooped” tone with emphasized bass &...
- Page 5 Body Sensor Controls The PowerTap Infinity may be used in mono or stereo output simply by choosing the appropriate cable. For a blended mono output use a standard instrument cable. Turn the thumbwheel control toward the neck to blend the body sensor in with the Matrix pickup signal.
-
Page 6: Additional Controls
Additional Controls Voicing Switch This switch, located on the underside of the control module, selects how the Matrix pickup is voiced. The switch position away from the soundhole provides a subtle bass boost and extended low end for added punch. The switch position towards the soundhole yields a flatter response. -
Page 7: Battery Replacement
Installation by a qualified professional is strongly recommended. Should you have any problems, please check with your installer or refer to the online installation guide for this product. Technical support, troubleshooting tips and installation information can be found at http://www.fishman.com/support/... - Page 8 Dual Source – Acoustic Amp stereo Y cable...
- Page 9 Dual Source – PA stereo breakout cable (included) mono 1/4” cables Tap pickup and magnetic pickup to front of house...
- Page 10 Fishman at their sole discretion. Fishman may also choose to replace this product or part of this product with a substitute, in lieu of repair, in exchange for quoted labor charges. This warranty applies only if the Product is sold and delivered within the U.S.
- Page 11 United States. Product repaired after the first year warranty period at the Fishman factory will be returned at customer expense. Prod- uct returned to Fishman that is not covered by the terms of this warranty will be serviced only after payment is arranged.
- Page 12 Fishman and Fishman Transducers are trademarks or tradenames of Fishman Transducers Inc. 513-300-298 r0...
