REVELL MAGIC GLOW User Manual page 8

• Never use a charger for NiCd/NiMH
batteries!
• Always ensure that the charging
process takes place on a fireproof
surface in a fire-resistant environment.
• Do not leave the battery unsupervised
during the charging process.
• Never disassemble or alter the battery
contacts. Do not damage or puncture
the battery cells. There is a risk of
explosion!
• The LiPo battery must be kept out of
reach of children.
• When disposing of batteries, they must
be discharged or their capacity must
be fully depleted. Cover exposed
terminals with adhesive tape in order
to prevent short-circuiting!
Maintenance and care:
• Please only use a clean, damp cloth
to wipe off the model.
• Protect the model and batteries from
direct sunlight and/or direct heat.
• Never allow the remote control and
charging unit to come into contact
with water, because the electronics
will be damaged as a result.
1A Counter-rotating rotor blades
1B Stabiliser
1C Canopy
2 REMOTE CONTROL
2A Control for thrust
2B ON/OFF button
2C Antenna
2D Control for forward/backward flight
and clockwise/anticlockwise rotation
3 INSERTING BATTERIES (REMOTE CONTROL)
3A Unscrew and remove the cover.
3B Insert 4 x 1.5 V AA batteries and pay attention to the polarity,
as shown in the battery compartment.
3C Close the battery cover and secure with the screw.
14
Technical changes and differences in
color reserved!
Required batteries for the model:
Power supply:
Rated output: 1 x DC 3,7 V / 0,45 Wh
Rechargeable LiPo battery (included)
Capacity: 120 mAh
Battery requirement for the
remote control:
Power supply:
DC 6 V Batteries:
4 x 1.5 V "AA"
(not included)
1 MODEL
1D ON/OFF button
1E Charge socket
2E Trim buttons for
clockwise/anticlockwise rotation
2F Charging station
2G Power LED
2H Battery compartment cover
4 CHARGING THE MODEL
Attention: The battery and motor must cool down for 15 to 30 minutes before
charging and after every flight. Otherwise they can be damaged. The charging process
must be constantly monitored. Always ensure that the charging process takes place on
a fireproof surface in a fire-resistant environment.
• Switch off the remote control and model.
• Carefully place the helicopter with the fuselage facing downwards on the remote
control. In the process, make sure that the circuit board contacts are guided into the
slot on the remote control 4A.
• The charging process begins when the blue charge LED in the helicopter illuminates
4B.
• The charging process has been completed when the USB plug lights up.
• Remove the helicopter from the remote control after the charging process.
The model can fly for approx. 5-7 minutes after a charge time of approx.
40 minutes.
5 START PREPARATION
The control for thrust 2A must point down before the remote control is switched on
5A. Then briefly press the ON/OFF button on the remote control 5B and the Power
LED 2G begins to blink red. Now set the ON/OFF switch 1D on the underside of the
helicopter to the «ON» position 5C. Place the helicopter on the ground so that its tail
points toward you. After a few seconds for initialisation, the Power LED on the remote
control illuminates red. Now the helicopter is ready to start. After the flight, first switch
off the helicopter, then the remote control. Press and hold the ON/OFF button on the
remote control for approximately 3 seconds to switch it off.
6 TRIM ADJUSTMENT OF THE CONTROL
The correct trim is a basic requirement for fault-free flying behavior of the model.
6A
If the helicopter begins to auto-
matically rotate clockwise quickly
or slowly ...
If the helicopter begins to automati-
cally rotate clockwise quickly or slowly,
continue to tap the left/right trim
buttons for rotation 2E until the heli-
copter no longer rotates automatically.
Do not simply actuate the trim buttons
continuously.
6B
If the helicopter begins to auto-
matically rotate anti-clockwise
quickly or slowly ...
If the helicopter begins to automati-
cally rotate anti-clockwise quickly or
slowly, continue to tap the left/right
trim buttons for rotation 2E until the
helicopter no longer rotates automati-
cally.Do not simply actuate the trim
buttons continuously.
